The 701 Contour Battery Master Switch offers a number of unique features. The highlights being the patented contour lock system, allowing it to be a stand alone unit, or locked together with other switches. The 701 also features a control knob which cannot be removed whilst in the ON or OFF position, however, can be removed by switching to an anti-clockwise 45 deg position. The control knob also features an interchangeable labelling system allowing a full range of applications. The 701 also features removable side plates on 4 sides for access of up to 1/0 cables plus a rear cover insulating the rear terminals against any short circuits. This ensures the switch meets ABYC requirements. The 701 can be either surface or recess mounted.

• Continuous Rating: 275 Amps DC
• Intermittent Rating: 455 Amps DC
• Cranking Rating: 1250 Amps DC
• Voltage Rating: 48 Volts DC
• Operation: On/Off
• Mounting: Recessed or Surface
• Ignition protected
• Termination Stud Size:
  2 x 10 mm (3/8 inch)
• Dimensions: 69 x 69 x 75h mm
  (2.75 x 2.75 x 3h inches)
• Tin plated copper studs and nuts

Due to the increased load requirements and large increases in the cost of copper battery cable, the MD range of battery switches allows you to install the battery switch very close to the battery, reducing cable lengths to starter motor. They are also ideal for remote isolation of bow thrusters.

701-S Mini battery selector switch. The 701-S is the most compact selector switch available on the market. Housed in the same dimensions as the 701, and includes the same removable side plates and back cover. While BEP Marine foremost recommends isolated battery systems as outlined with our distribution clusters, the 701-S offers a simple economical way of separating two batteries.

701-S Specifications:

• Continuous Rating: 200 Amps DC
• Intermittent Rating: 300 Amps DC
• Cranking Rating: 1000 Amps DC
• Voltage Rating: 48 Volts DC
• Operation: Selector 1-2-Both_off
• Mounting: Recessed or surface
• Termination Stud Size: 3 x 5/16 in
• Tin Plated copper studs and nuts
• Ignition Protected
• Dimensions: 69 x 69 x 75H mm (2.75 x 2.75 x 3H")

BEP 702-2S Distribution Studs

Dual Distribution Stud Module, 2 x 3/8 in

The 702-2S was designed specifically for transom areas for connecting battery cables from outboards. It also has many other applications where heavy duty positive and negative connections need to be terminated.

The Digital Voltage Sensing Relay (DVSR) allows the charging of a second battery bank from any single charging source. When the voltage on the charged bank rises sufficiently, the DVSR engages allowing the 2nd battery bank to charge. When charging stops and voltage falls, the DVSR automatically isolates the battery banks, ensuring that engine start batteries are kept fully charged. Digital circuitry provides superior reliability and extremely low power consumption. Digital enhancements have introduced remote sensing circuitry that allows an optional connection from the ignition switch to provide the same functionality as single sense VSR and zero power consumption when engine is off. Another benefit is a zero stand by current draw when remote sensing circuit is utilized with a storage mode switch fitted (switch in open position).

• Safely charge two or more independent battery banks from one charge source such as an alternator or battery charger
• Charges engine starting batteries before combining auxiliary bank for charging
• Protects start batteries from becoming flattened by domestic loads
• Isolates electronics from harmful electrical surges from starter motors
• Simple to install 3 wire connection leaves alternator wiring intact
• No volt drop vs diode isolators
• Ignition protected
• Surface or panel mountable
• Replaces previous models 710-125A and 710-125A-DS
• Multi voltage, auto selects between 12 and 24V DC operation
• Digital circuits provide very low power consumption and enhanced performance
• Remote status LED output option

BEP Battery Distribution Cluster for Single Engine with Two Battery Banks

The 714-140A-DVSR uses a dual sensing DVSR (710-140A). This system ensures that you will always have a fully charged reserve battery. When the switch is in position one, battery one becomes the sensing battery for the VSR. Battery two, which is in isolation, is charged through the VSR when the engine is running to ensure that it is always fully charged. When the switch is in position two, battery two becomes the sensing battery and battery one is charged through the VSR. The fact that there is always a fully charged battery in reserve is a huge safety benefit.

BEP Battery Distribution Cluster for Single Engine with Two Dedicated Battery Banks

Horizontal unit to be used in single outboard with a dual battery bank, single alternator with a dual battery bank or in a twin alternator with a dual battery bank.

BEP Battery Distribution Cluster for Twin Engine with Two Battery Banks

The 715-S allows you to switch the house loads between port and starboard batteries. You can also use the selector switch to parallel the batteries .

BEP Battery Distribution Cluster for Twin Engine with Two Battery Banks

Vertical unit to be used in single outboard with a dual battery bank, single alternator with a dual battery bank, or in a twin alternator with a dual battery bank.

BEP Marine Limited 716-H-140A-DVSR Horizontal Battery Distribution Cluster for Single Engine with Two Battery Banks

• No more flat start batteries
• Electronics protection from harmful engine start spikes
• The 716 cluster is for use on charging systems up to 150A
• The 716 cluster replaces battery isolator systems
• Two battery banks

The 716-H-140A-DVSR is an ideal replacement for a battery selector switch. Just remove the selector switch and connect the existing wires to a 716 cluster, no extra wires are required for a fully automatic battery management system. To be used in a single outboard dual battery bank system or in a single alternator inboard engine dual battery bank system.

The 720 Heavy Duty Battery Switch follows the successful release of the 701 switch in 1999. It fits into the same contour lock system as used on the battery distribution system. Rated at 600 amps continuous and 2500 amps cranking. It is well suited to larger vessels. As with the 701, the 720 can be recessed or surface mounted. The 720 uses the same style of self cleaning sliding contact as used in the 701 and utilises the same label sheet as 701.

720 Specifications:

• Continuous Rating: 600 Amps DC
• Intermittent Rating: 800 Amps DC
• Cranking Rating: 2500 Amps DC
• Voltage Rating: 48 Volts DC
• Operation: On / Off
• Mounting: Recessed or Surface
• Termination Stud Size: 2 x 12 mm (1/2 inch)
• Dimensions: 102 x 102 x 90h mm (4 x 4 x 3.5h inches)
• Tin plated copper studs and nuts
• Ignition protected
• Termination Stud Size: 2 x 12 mm (1/2 inch)

• Wiring Instr for wiring a 720-MDO as a 720-MD

Due to the increased load requirements and large increases in the cost of copper
battery cable, the MD range of battery switches allows you to install the battery
switch very close to the battery, reducing cable lengths to starter motor. They are
also ideal for remote isolation of bow thrusters.

The 721 Battery Selector Switch is our heavy duty selector switch. Housed in the same module as the 720, it includes the same removable plates and back cover. While BEP Marine recommends isolated battery systems as outlined with our distribution clusters, the 721 offers a simple economical way of separating two batteries. Please note selector switches will not separate electronics from harmful engine starting spikes.

• Continuous Rating: 350Amps DC between common B1 or B2
• Continuous Rating: 500 Amps DC between common B1 + B2
• Intermittent Rating: 500 Amps DC
• Cranking Rating: 1500 Amps DC
• Voltage Rating: 48 Volts DC
• Operation: Selector-Battery 1-2-Both-off
• Mounting: Recessed or surface
• Termination Stud Size: 3 x 10mm(3/8 in)
• Tin plated copper studs and nuts
• Dimensions: 102 x 102 x 90H (4 x 4 x3.5H")
• Ignition protected

BEP Z Bar 18 Way Buss Bar

• Easily extend Z-Bars by placing on end or back-to-back
• Clean installation-all cables can be run from one side of the Z-bar
• Innovative clear covers insulate and protect on three sides and offer easy access

This patent-pending, space saving buss bar range is a completely new concept for marine cable termination. Offering almost unlimited installation flexibility, the high and low level bars can be bussed together with Z-Link or used as separate positive/negative bars. Pro Installer Z-Bars are available in (10) way and (18) way 200 Amp Z-Bar models for a variety of onboard applications.

BEP Z Bar 10 Way Buss Bar

• Easily extend Z-Bars by placing on end or back-to-back
• Clean installation-all cables can be run from one side of the Z-bar
• Innovative clear covers insulate and protect on three sides and offer easy access

This patent-pending, space saving buss bar range is a completely new concept for marine cable termination. Offering almost unlimited installation flexibility, the high and low level bars can be bussed together with Z-Link or used as separate positive/negative bars. Pro Installer Z-Bars are available in (10) way and (18) way 200 Amp Z-Bar models for a variety of onboard applications.

BEP Class T Fuse Holder

• Radiused ends improve cable routing options
• Class-T: 225-400 Amp, 450-600 Amp models available

Providing high-capacity fusing, fast response and very high interrupt ratings (ANL up to 6,000 Amps, Class-T up to 20,000 Amps), these fuse holders are ideal for protecting today’s demanding onboard power electronics technology including inverters and battery chargers. They also protect wiring from short circuits. Pro Installer fuse holders’ durable construction allow fuses to run at maximum load.

BEP Class T Fuse Holder

• Radiused ends improve cable routing options
• Class-T: 225-400 Amp, 450-600 Amp models available

Providing high-capacity fusing, fast response and very high interrupt ratings (ANL up to 6,000 Amps, Class-T up to 20,000 Amps), these fuse holders are ideal for protecting today’s demanding onboard power electronics technology including inverters and battery chargers. They also protect wiring from short circuits. Pro Installer fuse holders’ durable construction allow fuses to run at maximum load.

BEP DC Color Systems Monitor (DCSM)

excluding Shunt

• 8 Generic, user configurable inputs
• Programmable high/low audio /visual alarms for volts, amps and tank levels
• Backlit keypad and dimmable screen
• Can be panel or surface mounted
• 2.8 in Colour QVGA LCD
• Input voltage 8-32VDC
• Backlit keypad
• Monitors charge/discharge amps for two banks
• Monitors capacity remaining in A/h and %
• Monitors battery condition
• Monitors tank fluid level
• Monitors circuit status

DC Systems Monitor (DCSM) Designed and manufactured by BEP, these state of the art full colour monitors are made to meet the systems monitoring requirements of today’s modern vessel and recreational vehicle. Complex and DC electrical installations on board are becoming more common place. Additionally the increase in tank monitoring requirements for fuel, fresh, grey and black water, accurate monitoring of these systems is essential. The DCSM display features clear, extra large type face. This allows for more detailed on-screen information and increased clarity. The screen has back lighting for easy night time viewing.

BEP Smart Battery Hub Twin Engine

• Remotely operated magnetic latching switches
• Remotely operated emergency parallel switches
• Configurable dual direction voltage sensitive switches
• Battery Voltage Monitoring
• House battery State of Charge Monitoring
• 2 x additional sensor inputs
• Safety manual override for all battery switches
• 12 or 24 volt systems
• Parallel two units together for 4, 5 and even 6 engine installations

BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS) and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing.

BEP Smart Battery Hub Triple Engine

• Remotely operated magnetic latching switches
• Remotely operated emergency parallel switches
• Configurable dual direction voltage sensitive switches
• Battery Voltage Monitoring
• House battery State of Charge Monitoring
• 2 x additional sensor inputs
• Safety manual override for all battery switches
• 12 or 24 volt systems
• Parallel two units together for 4, 5 and even 6 engine installations

BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS) and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing.

BEP Temperature Sensor for Smart Battery Hub

BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS) and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing.

6 Way spray proof switch panel

Features:

• Compact Panel size
• Sprayproof inline fuse holders with fuses are included with all compact models
• 20A rated switches
• Waterproof to IP56
• Dimensions:LxWxH is 3.75x4.25"x2.9 in (95x107x75 mm) D

Size (HxWxD): 200x239x65
Label Sheet: Set - 5
Buss Bars: Yes x 2 (Earth & Neutral).
Volts: 230V or 110V

Meter: Analogue volts.

Circuit Breakers:
Single pole
1 x 5amp
3 x 10amp
3 x 15amp
1 x 20amp
Double Pole
1 x 25amp
1 x 20amp

Includes lock out control and reverse polarity indicator.

Product Details: Features:

• Marine Grade powder coated aluminium
• Airpax circuit breaker
• Stylish Contour Design facia
• Green LED backlit labels
• Red LED indicates systems on
• Panels meet ABYC standards

Product Details: Features:

• Marine Grade powder coated aluminium
• Airpax circuit breaker
• Stylish Contour Design facia
• Green LED backlit labels
• Red LED indicates systems on
• Panels meet ABYC standards

Product Details: Features:

• Marine Grade powder coated aluminium
• Airpax circuit breakers
• Stylish Contour Design fascia
• Green LED backlit labels
• Red LED indicates systems on
• Panels meet ABYC standards
