WL510 High Power WiFi Access System
Part #: ZDIGWL510

Two part solution with Hi gain (0.9M) 2.4GHz wifi antenna, mounting base, 10m low loss LM400 cable and black box amplifier and modem. Simple USB connection. 1W erp. Offers 4-6 mile range capability. With external 12/24v DC power adaptor.

The interface allows you to choose which hotspot you want to access, enter WEP/WAP passwords and view signal strength and diagnostics.

Power output from the device can also be adjusted. The interface is password protected to prevent unauthorized access and a tabbed menu for easy operation. Easy web interface to connect via RJ45 patch cable to your PC and login through a browser.

Features:

• Access the internet through WiFi hotspots with a range of up to 4-6nm

• Controlled via a simple web interface - no complicated drivers to install

• Connects via ethernet to onboard PC or router

• Supplies complete with high gain (15dBi) external antenna and 10m coax cable assembly

• 12VDC operation

HSC100 High Performance Fluxgate Sensor

Accurate compass heading data remains a fundamental parameter for marine navigation and the HSC100 uses fluxgate technology to deliver heading data for on board systems. Typical applications include enabling course up and true motion type displays on chart plotters, radar overlay onto electronic charts and stabilisation of radars when used for MARPA/ARPA target tracking. Integrated instrument systems can also benefit from having compass information to calculate real time tidal set and drift when interfaced with a log and GPS.

Features:

• High speed (10Hz) NMEA electronic fluxgate compass sensor

• Ideal for use with radar overlay and MARPA target tracking systems

• Industry standard NMEA 0183 HDG output

• Gimbaled to 45 degrees

• 12/24V DC operation with minimal power consumption

• Waterproof to IPx7 and suitable for external mounting on steel hulled vessels

• Automatic calibration routine and manual compass offset feature

• Additional AD10 heading output for interface with Furuno systems

• LED status indicator

• 15m interconnect cable

NMEA to Wireless Wi-Fi Adapter - 4800 Baud

This innovative and cost effective wireless device creates its own 802.11b+g wireless access point which any other wireless device can connect to, such as a Smart Phone, Netbook or Laptop.

Connect it to any device or system that has an NMEA 0183 output and it will automatically read the data and transmit it wirelessly to another wireless device. The NMEA 0183 data is transferred using TCP/IP protocol to a suitably compatible application on the wireless device.

A number of Marine Navigation software packages support TCP/IP data transfer including;

• SeaPro (PC)

• Rose Point Coastal Explorer (PC)

• MacENC (Macs)

• iNavX (iPhone/iPad)

NMEA to Wireless Wi-Fi Adapter - 38,400 Baud

This innovative and cost effective wireless device creates its own 802.11b+g wireless access point which any other wireless device can connect to, such as a Smart Phone, Netbook or Laptop.

Connect it to any device or system that has an NMEA 0183 output and it will automatically read the data and transmit it wirelessly to another wireless device. The NMEA 0183 data is transferred using TCP/IP protocol to a suitably compatible application on the wireless device.

A number of Marine Navigation software packages support TCP/IP data transfer including;

• SeaPro (PC)

• Rose Point Coastal Explorer (PC)

• MacENC (Macs)

• iNavX (iPhone/iPad)

• Wireless NMEA Data server (38400 baud)

• Reads NMEA 0183 data and transmits it wirelessly over 802.11b+g

• Can be fitted to any AIS unit or NMEA Multiplexer that is outputting/inputting NMEA 0183 data at 38400 baud

• Supports Bi-Directional communication but must be at the same 38400 baud rate

• Creates an 802.11b+g wireless access point and then transmits data via TCP/IP link

• Fully compatible with popular iNavX navigation application for Apple mobile devices

• Easy to install IP54 black box solution

ANT200 Smart AIS Antenna

Perfect "all in one" AIS Smart Antenna solution for small boats, particularly RIBs, Sports boats and small yachts where dry space to mount black box AIS units is limited. Simply connect 12v or 24v power and the ANT200 will start transmitting data on all AIS targets within a 10 mile* radius of your boat. Ideal for use with existing AIS compatible chart plotters such as the latest Garmin, Raymarine, Navico, Standard Horizon and Furuno units.

Connect the NMEA0183 (4800 baud) output of your GPS to the ANT200 and it will automatically multiplex (merge) the slower GPS data with the high speed AIS data and transmit everything on one high speed NMEA output (38,400 baud) - perfect for connection to a chart plotter with only one NMEA input.

• Multiplexed NMEA input for single NMEA GPS+AIS data output at 38,400 baud

• Simple to install "all in one" smart antenna solution

• Integral 1" x 14 TPI thread for fixing to standard VHF mounts

• 15m Power/Data cable

• High performance dual channel AIS receiver for use with existing plotter and radar systems

• High Speed NMEA output (38,400 baud)

AISPRO200 AIS Receiver

Great entry level AIS receiver for use with PC navigation software and chart plotters such as the latest Garmin, Raymarine, Navico, Standard Horizon and Furuno units. Connected to an existing VHF antenna (via a splitter) or dedicated AIS antenna, you can receive all AIS targets within 20 miles of your boat

Simple plug and play USB connection to a PC. Uses standard drivers built-in to Windows XP/Vista/7 and is automatically mapped to an available "virtual" com port, that your PC software can read. Also compatible with Mac OS X and all LINUX Kernels since V2.4.20.

This Pro version of the AIS200 also has the NMEA0183 input and output capability of the normal version and so you can supply AIS data to a PC (via USB) and a Dedicated plotter (via NMEA) for larger installations.

Connect the NMEA (4800 baud) output of your GPS to the AIS200PRO and it will automatically multiplex (merge) the slower GPS data with the high speed AIS data and transmit everything on the high speed NMEA output (38,400 baud) - perfect for connection to a chart plotter with only one NMEA input.

• High performance dual channel AIS receiver for use with existing plotter and radar systems

• USB Interface for simple Plug and Play connection to a PC

• High Speed NMEA output (38,400 baud)

• Requires VHF antenna (or dedicated AIS antenna available as optional accessory)

• Multiplexed NMEA input for single NMEA GPS+AIS data output at 38,400 baud

• Small black box solution 150mm x 150mm x 37.5mm (L x W x D)

• Supplied with mounting brackets, 0.75m Power/Data cable, 0.75m USB cable and instruction manual

AIT1000 Class B Transponder w/GPS Antenna

** This product includes a $35.00 programming fee, as the FCC requires all
units sold in the US to be programmed by a qualified technician. Please
submit the form below for programming at time of purchase. A copy of the
MMSI registration or FCC Ship Station License is required along with the
vessel master or owner’s signature on the completed programming form. **

Click to download form.

AIS100 Receiver

This value priced, entry level AIS receiver is Digital Yacht’s most cost effective solution for adding AIS to your boat. Featuring the same dual channel receiver as the AIS200 range, but without the multiplexer, there is no compromise on performance and the AIS100 will outperform all other, inferior, single channel receivers.

For use with existing AIS compatible chart plotters, such as the latest Garmin, Raymarine, Navico, Standard Horizon and Furuno units. Connected to an existing VHF antenna (via a splitter) or to a dedicated AIS antenna, you can receive all AIS targets within 20 miles of your boat.

• Low cost entry level AIS receiver

• High performance dual-channel AIS receiver for use with existing plotter and radar systems

• High Speed NMEA output (38,400 baud)

• Requires VHF antenna or dedicated AIS antenna (available as optional accessory)

• Easy to install IP54 black box solution

AISnet AIS Base Station

AISnet is a new AIS receiver for use as an AIS base station at home or in the office. Utilising the same high performance dual channel AIS receiver as the rest of the Digital Yacht range, AISnet also features an ethernet socket so that you can connect it to your broadband router and send AIS data to an on-line AIS tracking service.

There are now a large number of internet based web sites which offer a view of AIS equipped vessels on a background chart allowing users to check the position and identity of ships and yachts. If your home/office is close to the coast and you would like to contribute your data to one of these sites, simply register with the company and they will give you an IP address and Port number.

Using the setup program that Digital Yacht supply, it takes seconds to program the IP address and Port in to AISnet, which will immediately start sending your local AIS data seamlessly across the internet to be displayed on the site.

It is also possible to view the data, that AISnet is collecting, locally on your PC using the free SmarterTrack Lite software that Digital Yacht include with every AISnet. Simply plug the USB connector into your PC and the AIS data will appear on your PC and still be transmitted over the internet.

AISnet is supplied with a universal UK/Euro/US mains adaptor that provides a regulated 12v supply from 240v/110v AC mains.

KEY FEATURES

• AIS base station for Home of Office use

• Integrated ethernet network controller for supplying AIS data to online AIS websites

• High performance dual channel AIS receiver

• Simple configuration via free setup program

• USB Interface for simple Plug and Play connection to a PC

• Requires VHF antenna or dedicated AIS antenna (available as optional accessory) or splitter

• Universal Mains power supply included

• Simple "fit and forget" black box solution

AIS100 Receiver (USB)

This value priced, entry level AIS receiver is Digital Yacht’s most cost effective solution for adding AIS to your PC. Featuring the same dual channel receiver as the AIS200 Pro, but without the NMEA 0183 output and multiplexer, there is no compromise on performance and the AIS100 will out perform all other, inferior, single channel receivers.

For use with any AIS compatible PC navigation software, such as the latest SmarterTrack, MaxSea, Nobeltec, SeaPro and RosePoint applications. Connected to an existing VHF antenna (via a splitter) or to a dedicated AIS antenna, you can receive all AIS targets within 20 miles of your boat.

• Low cost entry level AIS receiver

• High performance dual-channel AIS receiver for use with AIS compatible PC navigation software


• USB Interface for simple Plug and Play connection to a PC

• Requires VHF antenna or dedicated AIS antenna (available as optional accessory)

• Easy to install IP54 black box solution

iAIS Wireless Receiver

The world’s first wireless AIS receiver that links wirelessly with the latest iPhone, iPad and iTouch devices. Consisting of a high performance dual channel AIS receiver, an integrated 802.11b+g wireless access point plus a free app downloadable from the Apple App Store, the iAIS brings AIS data to a whole new generation of mobile devices.

iAIS also multiplexes any other NMEA data that is available on board the boat - for instance GPS, depth, speed and wind etc. All of this data is combined with the AIS data into a single wireless feed, that becomes available on any compatible application. By using the boat’s own GPS, even an iTouch or iPad that does not have an internal GPS can now be used for navigation and superior performance will also be seen on an iPhone, which some users have complained suffers from jitter or poor lock-on with its internal GPS.

As well as sending data wirelessly, the iAIS also has an NMEA0183 and USB interface so that you can output data to a PC (via USB) and a dedicated plotter (via NMEA) for larger installations.

The free iAIS app is available from the App store and is a simple AIS display program. For more advanced use, Digital Yacht recommends the iNavX app (www.inavx.com). Compatible with Navionic’s charts, iNavX provides a complete set of navigation functions that turns your Apple device into a full function electronic chart plotter. It supports waypoints, routes and tidal data and is beautifully simple to use. It even overlays GRIB weather data. iNAVx sell and support this app directly.

SmarterChart 500 AIS Combo

The SmarterChart 500 AIS Combo from Digital Yacht is the world’s first 5" chart plotter to feature a built-in AIS receiver. Coupled with an internal 50 channel GPS receiver, it effortlessly plots your position on the electronic chart and overlays all AIS targets within 20 miles of your boat.

Sharing the same 5" sunlight viewable 320 x 240 pixel (65,000 Color) LCD display as the other Smarter Chart 500 plotters, it is fully compatible with C-Map MAX electronic charts, providing unprecedented value and detail. Supporting advanced features such as free downloadable weather overlays and forecasts, 3D perspective view, photos, tidal heights and currents, as well as the powerful Guardian Alarm which checks your route for potential charted dangers.

AIS target range, like VHF range is dependent upon a number of installation factors such as; antenna gain, antenna height and size of ground plane. Ranges in excess of 20 miles should be possible if all of these factors are perfect.

• World’s First 5" Chart Plotter with built-in AIS

• Full C-Map MAX chart compatibility (single C-Card slot)

• Ultra fast chart redraw, pan and zooming

• Can be connected to 12v or 24v DC supply

• IP56 rated water resistant 320 x 240 pixel sunlight viewable LCD

• Worldwide built in electronic charts showing C-Map detail down to a level of two nautical miles.

• High sensitivity, dual channel AIS receiver - BNC connector for antenna

• 50 Channel internal GPS (external GPS available as option)

• Flush, bracket and helm pod mounting options

• Fully compatible with C-Map PC Planner and User Cards

• Requires connection to existing VHF/AIS antenna (available as option)

BOATraNET
ZDIGBNET

BOATraNET is a truly unique and innovative product that "e-nables" your existing navigation system and creates a dynamic, local intranet for your boat. Imagine having your own automatic website that shows visitors to your boat, all of the most important navigational information and gives them access to the photos, documents and music that you want them to share and enjoy.
BOATraNET integrates with the boat’s existing navigation system (Raymarine, Garmin, Furuno, Navico, etc.) via NMEA 0183 and automatically creates animated instrument and navigational displays (web pages) of your data.
It creates a wireless "hotspot" that works with iPhones, iPads, iPod Touch, Android Devices, Smart Phones, Laptops, Windows, LINUX and Mac OS X PCs. Anyone onboard can connect, enter the password you give them, and then using the wireless device’s own web browser (no special app required) view the data, even when out at sea without an internet connection.
BOATraNET incorporates a Navionics based chart plotter (with optional embedded Silver Charts), that shows you where you are on the chart, a music player that can play music on your boat’s hifi or stream music to your wireless devices, plus photo and document viewers that you control from your wireless device’s web browser. Connect BOATraNET to one of Digital Yacht’s long range wifi adaptors and when you are in the marina, you can easily connect to the marina’s "hot spot" and share the long range wifi connection, with everyone connected to BOATraNET.
BOATraNET is fully expandable and more functions, features and accessories are planned to be rolled out over the coming months. Software updates, Data and Media files can easily be transferred via USB memory sticks.

KEY FEATURES:

• World’s first wireless navigation server for boats

• Creates dynamic HTML 5 compliant web pages that can be accessed by anyone on the boat

• New and exciting method for family and friends to access data and media whilst onboard

• Can be accessed by any wireless device with a modern browser - no special apps required

• Works everywhere at sea - no internet connection required

• Optional long range wifi adaptor for shared internet connection in marinas

• 12/24v DC, ultra rugged, fanless hardware that consumes just 1.5A

• Compact - measures just 29.5cm x 22.5cm x 6.2cm

• 2 x NMEA 0183 Ports

• Easy mounting and installation

• All units include a worldwide Base Map

• Can be supplied with optional Navionics Silver continental chart coverage of your region

• iPhones, iPads and iTouch units with iOS 3.x or higher

• Macs running Safari V5 or higher

• PCs running Google Chrome

• Google Android V2.3 Devices

BOATraNET
ZDIGBNET-US

BOATraNET is a truly unique and innovative product that "e-nables" your existing navigation system and creates a dynamic, local intranet for your boat. Imagine having your own automatic website that shows visitors to your boat, all of the most important navigational information and gives them access to the photos, documents and music that you want them to share and enjoy.
BOATraNET integrates with the boat’s existing navigation system (Raymarine, Garmin, Furuno, Navico, etc.) via NMEA 0183 and automatically creates animated instrument and navigational displays (web pages) of your data.
It creates a wireless "hotspot" that works with iPhones, iPads, iPod Touch, Android Devices, Smart Phones, Laptops, Windows, LINUX and Mac OS X PCs. Anyone onboard can connect, enter the password you give them, and then using the wireless device’s own web browser (no special app required) view the data, even when out at sea without an internet connection.
BOATraNET incorporates a Navionics based chart plotter (with optional embedded Silver Charts), that shows you where you are on the chart, a music player that can play music on your boat’s hifi or stream music to your wireless devices, plus photo and document viewers that you control from your wireless device’s web browser. Connect BOATraNET to one of Digital Yacht’s long range wifi adaptors and when you are in the marina, you can easily connect to the marina’s "hot spot" and share the long range wifi connection, with everyone connected to BOATraNET.
BOATraNET is fully expandable and more functions, features and accessories are planned to be rolled out over the coming months. Software updates, Data and Media files can easily be transferred via USB memory sticks.

KEY FEATURES:

• World’s first wireless navigation server for boats

• Creates dynamic HTML 5 compliant web pages that can be accessed by anyone on the boat

• New and exciting method for family and friends to access data and media whilst onboard

• Can be accessed by any wireless device with a modern browser - no special apps required

• Works everywhere at sea - no internet connection required

• Optional long range wifi adaptor for shared internet connection in marinas

• 12/24v DC, ultra rugged, fanless hardware that consumes just 1.5A

• Compact - measures just 29.5cm x 22.5cm x 6.2cm

• 2 x NMEA 0183 Ports

• Easy mounting and installation

• All units include a worldwide Base Map

• Can be supplied with optional Navionics Silver continental chart coverage of your region

• iPhones, iPads and iTouch units with iOS 3.x or higher

• Macs running Safari V5 or higher

• PCs running Google Chrome

• Google Android V2.3 Devices

This innovative and cost effective wireless device creates its own 802.11b+g wireless access point which any other wireless device can connect to, such as a Smart Phone, Netbook or Laptop.

Connect it to any device or system that has an NMEA 0183 output and it will automatically read the data and transmit it wirelessly to another wireless device. The NMEA 0183 data is transferred using TCP/IP protocol to a suitably compatible application on the wireless device.

A number of Marine Navigation software packages support TCP/IP data transfer including;

• SeaPro (PC)
• Rose Point Coastal Explorer (PC)
• MacENC (Macs)
• iNavX (iPhone/iPad)

KEY FEATURES:

• Wireless NMEA Data server (4800 baud)
• Reads NMEA 0183 data and transmits it wirelessly over 802.11b+g
• Can be fitted to any GPS or Instrument system that is outputting/inputting NMEA 0183 data at 4800 baud
• Supports Bi-Directional communication but must be at the same 4800 baud rate
• Creates an 802.11b+g wireless access point and then transmits data via TCP/IP link
• Fully compatible with popular iNavX navigation application for Apple mobile devices
• Easy to install IP54 black box solution

The new WL510 allows boat owners to extend the range of their Boatranet System to wi-fi hot spots so that their on board internet devices or equipment can connect to the internet. With internet connectivity on board you can download the latest weather or chart updates as well as having a mobile office on board. Most harbours and ports have either free or subscription based services available

The system has a compact, DC powered below deck mounted 1W booster/modem and external, hi-gain (12dBm) antenna with 10m (33ft) low loss LMR400 coax interconnect cable. The antenna measures 0.9m (2.95ft) and can be supplied with desk, mast and industry standard 1" x 14 TPI mountings.
Even though your system already has wi-fi access, you can take advantage of the superior range (and speed) that this system will offer.

Wi-Fi range depends on many local factors but Digital Yacht have seen ranges of up to 4-6 miles with this low cost system. In general, using an internal wi-Fi adaptor on Boatranet, you?ll have similar range to a normal PC. So if you plan to access the internet whilst on board the WL510 could be the solution for you.

• Ideal solution for permanent installation and new builds
• Simple Plug and Play connection
• 1W wifi modem and high gain (12dBm) omni-directional antenna
• Industry standard 1" x 14 TPI thread mount


This innovative and cost effective wireless device creates its own 802.11b+g wireless access point which any other wireless device can connect to, such as a Smart Phone, Netbook or Laptop.

Connect it to any device or system that has an NMEA 0183 output and it will automatically read the data and transmit it wirelessly to another wireless device. The NMEA 0183 data is transferred using TCP/IP protocol to a suitably compatible application on the wireless device.

A number of Marine Navigation software packages support TCP/IP data transfer including;

• SeaPro (PC)
• Rose Point Coastal Explorer (PC)
• MacENC (Macs)
• iNavX (iPhone/iPad)

KEY FEATURES:

• High Speed Wireless NMEA Data server (38400 baud)
• Reads NMEA 0183 data and transmits it wirelessly over 802.11b+g
• Can be fitted to an AIS unit or NMEA Multiplexer that is outputting/inputting NMEA 0183 data at 38400 baud
• Supports Bi-Directional communication but must be at the same 38400 baud rate
• Free iAIS App for iPhone, iTouch or iPad
• Creates an 802.11b+g wireless access point and then transmits data via TCP/IP link
• Fully compatible with popular iNavX navigation application for Apple mobile devices
• Easy to install IP54 black box solution

• World’s first wireless navigation server for boats
• Creates dynamic HTML 5 compliant web pages that can be accessed by anyone on the boat
• New and exciting method for family and friends to access data and media whilst onboard
• Can be accessed by any wireless device with a modern browser - no special apps required
• Works everywhere at sea - no internet connection required
• Optional long range wifi adaptor for shared internet connection in marinas
• 12/24v DC, ultra rugged, fanless hardware that consumes just 1.5A
• Compact - measures just 29.5cm x 22.5cm x 6.2cm
• 2 x NMEA 0183 Ports
• NMEA 2000 Gateway
• Easy mounting and installation

BOATraNET is a truly unique and innovative product that "e-nables" your existing navigation system and creates a dynamic, local intranet for your boat. Imagine having your own automatic website that shows visitors to your boat, all of the most important navigational information and gives them access to the photos, documents and music that you want them to share and enjoy.

BOATraNET integrates with the boat’s existing navigation system (Raymarine, Garmin, Furuno, Navico, etc.) via NMEA 0183/2000 and automatically creates animated instrument and navigational displays (web pages) of your data.

It creates a wireless "hotspot" that works with iPhones, iPads, iPod Touch, Android Devices, Smart Phones, Laptops, Windows, LINUX and Mac OS X PCs. Anyone onboard can connect, enter the password you give them, and then using the wireless device’s own web browser (no special app required) view the data, even when out at sea without an internet connection.

BOATraNET incorporates a Navionics based chart plotter, that shows you where you are on the chart, a music player that can play music on your boat’s hifi or stream music to your wireless devices, plus photo and document viewers that you control from your wireless device?s web browser. Connect BOATraNET to one of Digital Yacht’s long range WiFi adaptors and when you are in the marina, you can easily connect to the marina’s "hot spot" and share the long range wifi connection, with everyone connected to BOATraNET.

BOATraNET is fully expandable and more functions, features and accessories are planned to be rolled out over the coming months. Software updates, Data and Media files can easily be transferred via USB memory sticks.

• World?s first wireless navigation server for boats
• Creates dynamic HTML 5 compliant web pages that can be accessed by anyone on the boat
• New and exciting method for family and friends to access data and media whilst onboard
• Can be accessed by any wireless device with a modern browser ? no special apps required
• Works everywhere at sea ? no internet connection required
• Optional long range wifi adaptor for shared internet connection in marinas
• 12/24v DC, ultra rugged, fanless hardware that consumes just 1.5A
• Compact - measures just 29.5cm x 22.5cm x 6.2cm
• 2 x NMEA 0183 Ports
• Optional NMEA 2000 Gateway
• Easy mounting and installation

BOATraNET is a truly unique and innovative product that ?e-nables? your existing navigation system and creates a dynamic, local intranet for your boat. Imagine having your own automatic website that shows visitors to your boat, all of the most important navigational information and gives them access to the photos, documents and music that you want them to share and enjoy.

BOATraNET integrates with the boat?s existing navigation system (Raymarine, Garmin, Furuno, Navico, etc.) via NMEA 0183/2000 and automatically creates animated instrument and navigational displays (web pages) of your data.

It creates a wireless ?hotspot? that works with iPhones, iPads, iPod Touch, Android Devices, Smart Phones, Laptops, Windows, LINUX and Mac OS X PCs. Anyone onboard can connect, enter the password you give them, and then using the wireless device?s own web browser (no special app required) view the data, even when out at sea without an internet connection.

BOATraNET incorporates a Navionics based chart plotter, that shows you where you are on the chart, a music player that can play music on your boat?s hifi or stream music to your wireless devices, plus photo and document viewers that you control from your wireless device?s web browser. Connect BOATraNET to one of Digital Yacht?s long range WiFi adaptors and when you are in the marina, you can easily connect to the marina?s ?hot spot? and share the long range wifi connection, with everyone connected to BOATraNET.

BOATraNET is fully expandable and more functions, features and accessories are planned to be rolled out over the coming months. Software updates, Data and Media files can easily be transferred via USB memory sticks.

UPC Number: 738435472511

Accurate compass heading data remains a fundamental parameter for marine navigation and the HSC100 uses fluxgate technology to deliver heading data for on board systems.  Typical applications include enabling course up and true motion type displays on chart plotters, radar overlay onto electronic charts and stabilisation of radars when used for MARPA/ARPA target tracking.  Integrated instrument systems can also benefit from having compass information to calculate real time tidal set and drift when interfaced with a log and GPS.

HSC FEATURES

• High speed (10Hz) NMEA electronic fluxgate compass sensor
• Ideal for use with radar overlay and MARPA target tracking systems
• Industry standard NMEA 0183 HDG output
• Gimbaled to 45 degrees
• 12/24V DC operation with minimal power consumption
• Waterproof to IPx7 and suitable for external mounting on steel hulled vessels
• Automatic calibration routine and manual compass offset feature
• Additional AD10 heading output for interface with Furuno systems
• LED status indicator
• 15m interconnect cable

Most low cost heading sensors only output data at 1Hz (once per second) but the HSC100 outputs at 10Hz which is required for MARPA target tracking and accurate radar overlays.

The HSC100 is waterproof so it can be mounted externally on steel hulled vessels.  It also features an automatic calibration routine to compensate for the effects of nearby magnetic influences.  This involves turning the boat through 1.5 circles at a constant angular velocity whilst in calibration mode.  Once completed, typical accuracies are within 0.5 degrees

SPECS

TYPE OF COMPASS - 2 axis tilt compensated floating core fluxgate. Gimballed to 45 degrees
DATA OUTPUT - NMEA 0183  4800 BAUD and Furuno AD10
INDICATOR - 3 state LED shows compass status
POWER - 8-30v DC Typical 25mA Reverse polarity protected
DIMENSIONS - 68 x 30mm 0.12kg without cable - Supplied with 15m cable

The Digital Yacht Class B AIS VHF Antenna splitter is designed to simplify installation of the Digital Yacht range of Class B Automatic Identification Systems (AIS).

The unit removes the need for a separate VHF antenna for an AIS transponder and allows a single antenna to be shared with a VHF radio. This is the only VHF antenna splitter suitable for use with two transmitting devices.

Features:

Simplifies installation
Use a single VHF antenna for both AIS and VHF operation. Save installation cost and time.

Failsafe operation
Guarantees priority to VHF voice & DSC radio operation, even if the splitter power supply fails.

FM Antenna connection
Additional output for FM radio antenna connection.

Compatible with Class B AIS Transponders
The only antenna splitter suitable for use with Class B transponders. Compatible with all Class B AIS transponders.

LED Status indication
Simple LED indicators show when VHF voice radio or AIS is transmitting or receiving.

Connecting leads provided
Includes RF leads for connection with AIS transponder, VHF radio, and a power lead


The CLA1000 from Digital Deep Sea is a fully approved, Class A transponder that meets all of the IMO requirements. Built to the most demanding of standards, the CLA1000 is MED Wheel Marked and comes with a global 2 year warranty.

Normally fitted to larger vessels that are mandated to fit a Class A Transponder due to their size or number of passengers, many smaller non-mandated vessels can also benefit from fitting a Class A transponder. With 12W transmit power, compared to 2W for Class B, many off shore sail boats would benefit from being visible at greater ranges, whilst the faster (up to every 2 seconds) update rate of the Class A transmissions, compared to every 30 seconds with Class B, will definitely benefit the larger power boats that can go a long distance in 30 seconds.

Two other important benefits of Class A Transponders are that they take priority over Class B transponders in areas of high AIS traffic (transmission slot allocation is guaranteed for Class A transponders) and they are always displayed on the Class A transponders and ECDIS systems on board large commercial vessels.

• Fully approved and MED Wheel Marked Class A Transponder
• Ultra Compact Design
• Easy soft key and rotary encoder operation
• Built-in GPS with easy to fit 1" x 14tpi mount GPS antenna
• Pilot Plug for easy PC connection
• Remote break out box for on-board interfacing
• Supplied with configuration software and SmarterTrack Lite AIS software

Digital Yacht has developed a new AIS receiver appropriately named AISnet which has been designed specifically for use as an AIS shore-side base station.

AISnet utilises the same well proved digital, dual channel receiver utilised across the whole Digital Yacht AIS range. With AIS transmissions on two VHF frequencies, the use of a dual channel receiver greatly improves target acquisition capability. It requires connection to a VHF antenna and an internet connection through a router or broadband modem. It also has a USB output for a local PC and is supplied with AISLite software so targets can be viewed.

There are now a large number of internet based web sites which offer a view of AIS equipped vessels on a background chart allowing users to check the position and identity of ships and yachts.  AISnet is designed to provide a feed for these sites. Some of these sites make a charge to users to view data and often provide free access to those who support the service with a receiver feed.

Once installed, the user utilises the configuration software supplied to set up the AISnet receiver for the relevant AIS tracking website and AIS data received by the unit will be seamlessly relayed across the internet.

• Dual channel AIS receiver for outstanding sensitivity
• USB (PC) and network RJ45 style output suitable for connection to internet/router/network
• Supplied with network configuration software and AISLite PC tracking software
• AC adaptor included
• Requires connection to VHF antenna

This value priced, entry level AIS receiver is Digital Yacht?s most cost effective solution for adding AIS to your boat. Featuring the same dual channel receiver as the AIS200 range, but without the multiplexer, there is no compromise on performance and the AIS100 will outperform all other, inferior, single channel receivers.

For use with existing AIS compatible chart plotters, such as the latest Garmin, Raymarine, Navico, Standard Horizon and Furuno units. Connected to an existing VHF antenna (via a splitter) or to a dedicated AIS antenna, you can receive all AIS targets within 20 miles of your boat.

• Low cost entry level AIS receiver
• High performance dual-channel AIS receiver for use with existing plotter and radar systems
• High Speed NMEA output (38,400 baud)
• Requires VHF antenna or dedicated AIS antenna (available as optional accessory)
• Easy to install IP54 black box solution

Perfect "all in one" AIS Smart Antenna solution for small boats, particularly RIBs, Sports boats and small yachts where dry space to mount black box AIS units is limited. Simply connect 12v or 24v power and the ANT200 will start transmitting data on all AIS targets within a 10 mile* radius of your boat. Ideal for use with existing AIS compatible chart plotters such as the latest Garmin, Raymarine, Navico, Standard Horizon and Furuno units.

Connect the NMEA0183 (4800 baud) output of your GPS to the ANT200 and it will automatically multiplex (merge) the slower GPS data with the high speed AIS data and transmit everything on one high speed NMEA output (38,400 baud) - perfect for connection to a chart plotter with only one NMEA input.

• Multiplexed NMEA input for single NMEA GPS+AIS data output at 38,400 baud
• Simple to install "all in one" smart antenna solution
• Integral 1" x 14 TPI thread for fixing to standard VHF mounts
• 15m Power/Data cable
• High performance dual channel AIS receiver for use with existing plotter and radar systems
• High Speed NMEA output (38,400 baud)

* NOTE - In much the same way as hand held VHFs do not give you the range of fixed mount VHFs (no antenna ground plane), the ANT200 does not have the same range as the AIS200/400 black box AIS units. If maximum AIS range is your highest priority then one of the other Digital Yacht receivers should be used, but for small boats with the aerial mounted at deck level, 10 miles is a good range for AIS and the ANT200 is recommended.


The new WL500 allows boat owners to connect to wi-fi hot spots so that their on board PC?s or equipment can connect to the internet. With internet connectivity on board you can download the latest weather or chart updates as well as having a mobile office on board. Most harbours and ports have either free or subscription based services available

The system has a compact, DC powered below deck mounted 500mW booster/modem and external, hi-gain (12dBm) antenna with 10m (33ft) low loss LMR400 coax interconnect cable. The antenna measures 0.9m (2.95ft) and can be supplied with desk, mast and industry standard 1? x 14TPI mountings.

The WL500 modem connects to an on board PC through a regular USB connection with a plug ?n? play driver disk supplied for Windows XP/Vista/7, Mac OS X 10.3 (and higher) and LINUX* operating systems. It supports 802.11b/g protocols as well as WEP and WPA encryption.

Even if your system already has wi-fi access, this can be disabled and you can take advantage of the superior range (and speed) that this system will offer.

Wi-Fi range depends on many local factors but Digital Yacht have seen ranges of up to 4-6 miles with this low cost system. In general, using an internal wi-fi adaptor typically found on a notebook, you?ll be lucky to find the signal at the end of the dock so if you plan to access the internet whilst on board the WL500 could be the solution for you.

• Ideal solution for permanent installation and new builds
• Simple Plug and Play USB connection
• 500mW wifi modem and high gain (12dBm) omni-directional antenna
• Industry standard 1" x 14 TPI thread mount
• Supplied with 5m USB cable - can be extended with optional 5m USB Active Extender
• External Modem requires connection to boats 12v DC supply
• Windows XP/Vista/7 compatible
• Mac OS X and LINUX* compatible

* The WL500 has not been tested with all LINUX distributions but all of the latest Debian based distributions should include the necessary drivers



This compact all-in-one system features a 30mW modem built in to a hi-gain (8dBm) antenna with a 5m (16ft) USB cable. The antenna measures 60cm (2ft) and should boost your Wifi range to over 0.5 mile in perfect conditions.

Designed for quick and easy installation with four suction cups, the WL50 is an ideal temporary mount WiFi solution for boats, caravans, RVs, etc.

Simple "plug and play" connection to a PC with 5m USB cable and comes with all software and drivers for Windows XP, Windows Vista, Mac OS X 10.3 (and higher) and LINUX*

• Ideal solution for temporary installation
• Simple Plug and Play USB connection
• 30mW wifi modem and high gain (8dBm) omni-directional antenna
• 4 x Suction Cup mount
• USB Bus Powered
• Windows XP/Vista/7 compatible
• Mac OS X and LINUX* compatible

 * The WL50 has not been tested with all LINUX distributions but all of the latest Debian based distributions should include the necessary drivers

The new WL400 allows boat owners to connect to wi-fi hot spots so that their on board PC?s or equipment can connect to the internet.  With internet connectivity on board you can download the latest weather or chart updates as well as having a mobile office on board. Most harbours and ports have either free or subscription based services available

The all-in-one system features a 200mW booster/modem encapsulated in the base of a hi-gain (12dBm) antenna with a 5m (16ft) USB cable.  The antenna measures 1m (3ft) and has an industry standard 1? x 14TPI mountings.

The WL400 connects to an on board PC through a regular USB connection with a plug ?n? play driver disk supplied for Windows XP/Vista/7, Mac OS X 10.3 (and higher) and LINUX* operating systems.  It supports 802.11b/g protocols as well as WEP and WPA encryption.

Even if your system already has wi-fi access, this can be disabled and you can take advantage of the superior range (and speed) that this system will offer.

Wi-Fi range depends on many local factors but Digital Yacht have seen ranges of up to 3-4 miles with this low cost system.  In general, using an internal wi-fi adaptor typically found on a notebook, you?ll be lucky to find the signal at the end of the dock so if you plan to access the internet whilst on board the WL400 could be the solution for you.

• Ideal solution for semi-permanent installation
• Simple Plug and Play USB connection
• 200mW wifi modem and high gain (12dBm) omni-directional antenna
• Industry standard 1" x 14 TPI thread mount (mount not included)
• Integrated 5m USB cable - can be extended with optional 5m USB Active Extender
• USB Bus Powered
• Windows XP/Vista/7 compatible
• Mac OS X and LINUX* compatible

* The WL400 has not been tested with all LINUX distributions but all of the latest Debian based distributions should include the necessary drivers

AIT2000 Class B
Part #: ZDIGAIT2000

Features:

• Ultra-compact Class B transponder has three outputs; NMEA 0183, NMEA 2000 and USB connection, allowing it to work with every AIS compatible chart plotter or software package on the market

• Remote silence switch option

• Built-in high performance 50 channel GPS receiver (ideal also as a backup GPS)

AIS200N2 Tri-Output AIS Receiver
A Tri-Output AIS receiver with NMEA0183, NMEA2000 and USB outputs to suit virtually any installation.

For more complex systems based around the NMEA 2000 data standard, look to the AIS200N2. This unit provides both traditional NMEA 0183, USB (for PC) and NMEA 2000 data connections and also features a multiplexer so that traditional data such as depth, position, speed and wind, which is available in NMEA 0183 format, can be converted to NMEA 2000 within the unit. The NMEA 2000 data standard offers faster, more complex networking capabilities and cross platform compatibility with a universal plug ’n’ play type cabling system. The unit ships with a premade NMEA 2000 cable assembly, terminated with a standard connector so there’s no need for an additional drop cable. Like all Digital Yacht AIS receivers, the unit is a true, dual channel parallel type design using digital processing for the best possible target acquisition.

Features::
