The Furuno LH-3000 is a high-performance 30 watt loud hailer with an intercom function. The LH-3000 is designed for a wide variety of ships, requiring high quality onboard and ship-to-ship communications under almost all circumstances.

Solidly built and waterproof, the LH-3000 contains a high quality built-in speaker and a microphone. On its front panel, there are easy-to-see states indicators. By generating voice or eight internationally acknowledged warning signals from the horns, the LH-3000 notifies nearby vessels of your presence and status regardless of visibility conditions.

The LH-3000 can also function as an intercom, when connected to optional intercom speakers. Up to four intercoms can be connected for two-way communication between the bridge and one or all intercom stations.

The LH-3000 can be connected to various equipment to enable useful functions. When connected to an external alarm unit, the LH-3000 can function as a security alarm. An auxiliary audio input allows transmission of music or other external audio signals (from CD player, radio, etc.) to the intercom speakers and external horns.

Standard Features:

• 30 Watt Forward and Aft Station Hailer Output Ports (20 Watt Hardware Selectable)

• LED indicators alert you to equipment status

• Backlit keypad for nighttime operation

• Smartly designed and intuitive front panel for ease of operation.

• Built-in High Quality Speaker for Intercom and Hailer Listen capability

• Alarm Siren Capability

• External Speaker Output

• Six Automatic International Hailer Warning Signals Consisting of:

  • UNWY - Vessel Underway in reduced visibility

  • SAIL - Vessel Under Sail in reduced visibility

  • TOW - Vessel Under Tow in reduced visibility

  • STOP - Stationary Vessel in reduced visibility

  • ANCH - Vessel at Anchor in reduced visibility

  • AGND- Vessel Aground in reduced Visibility



• Manually Controlled "YELP" and "On/Off" Hailer Warning Signals

• Four Remote Intercom Stations allow two-way communication between Master and Individual Remote stations or all remote stations simultaneously

• Auxiliary audio input allows transmission of music or other external audio signals (from cassette player, CD player, radio, etc.) to the intercom speakers, external horns or both

• Waterproof Frontal Area to IPX5 and USCG CFR-46 (Not waterproof from rear panel)

• Cosmetic "Family-Look" to FM3000 and other Furuno Products

• Removable screw terminal connectors on rear panel provide easy removal, installation, and system testing

• Gimbal Base Mount is included; bezel allows flush mount with provided cut-out template

• 12VDC(+/-20%), 5 Amps Max, 280 mA in standby

• 1 carton, 12"x12"x8", 8lbs

• The LH3000 is not supplied with a power cable

• The LH3000 requires hardwiring external components that are not supplied by Furuno. These external components consist of Hailer Horns, Intercom Speakers, External Audio Inputs, etc.

Power, versatility and quality performance are standard features of Furunos FS1503 150 Watt , P-P Single Sideband (SSB) Radiotelephone. This rugged, splash-proof 150 Watt (max) radio is ideal for commercial fishing operations, extended cruising or any situation requiring long-range communication capabilities.

The FCC type-approved FS1503 incorporates the most advanced technology available and is built to withstand demanding marine conditions. Its also simple to use, thanks to a choice of rotary control or touchkey frequency/channel selection. Instant access to international calling, and distress frequency 2182kHz is available at the touch of a single button.

Optional remote Station RB500

The optional RB500 allows operation of the radiotelephone at a remote location. Key functions include intercom, instant selection of 2182kHz, squelch on/off, Tx hi/low control. The FS1503 has one port for connecting RB500 or DB500 Distribution Box. The DB500 allows the connection of up to four Remote Stations.

Standard Features

• 150 Watt PEP SSB Transmitter, J3E, H3E, J3C, J2B Emission

• Transmitter Frequency Range of 1.6 to 27.5 MHz

• Receiver Frequency Range of 0.1 to 29.9 MHz

• All SSB, TELEX and ITU Marine Channels Pre-Programmed in Memory

• 199 User Programmable Channels

• Instant Selection of 2182 kHz

• SOLAS Compliant Two-Tone Alarm Generator

• Frequency Selection via Keypad or Rotary Encoder

• Receiver Scanning by Channel or Frequency

• Large, Back-lit Monochrome LCD Function Display

• Receiver Input Noise Blanker and Squelch Circuits

• Automatic Tuning Antenna Coupler

• 35lbs., 1 Carton

• 12 VDC only, +30, -10%

• 2 Amps in Receive, 30 Amps in Maximum Transmit

FS1503EM
The latest addition to Furuno’s HF Radio line that has won the prestigious NMEA award for SSB/GMDSS for the past two years in a row, the FS1503EM is a 150 Watt, P-P Single Sideband (SSB) Radiotelephone. This rugged, splash-proof 150 Watt (max) radio is ideal for commercial fishing operations, extended cruising or any situation requiring long-range communication capabilities. The FS1503EM is 100% Sail-Mail/E-Mail compatible right out of the box, and is capable of full Marine HF Weather Fax reception.

The FCC type-approved FS1503EM incorporates the most advanced technology available and is built to withstand demanding marine conditions. Its also simple to use, thanks to a choice of rotary control or touchkey frequency/channel selection. Instant access to international calling, and distress frequency 2182kHz is available at the touch of a single button.

Optional remote Station RB500

The optional RB500 allows operation of the radiotelephone at a remote location. Key functions include intercom, instant selection of 2182Khz, squelch on/off, and TX hi/low control.

The FS1503EM has one RS232 port to connect an email modem. If RB500 remote stations are desired, it will be necessary to connect an optional DB500 distribution box to that port. The DB500 can then accommodate up to three RB500 remotes plus the email modem.

Standard Features

• NEW - Low Cost/High Quality Truly Marinized HF Transceiver

• 100% Duty Cycle@150W

• INCLUDED: Remote Control Capability and Integrated Narrowband Filter at ALL AT NO ADDITIONAL COST - Competitive Advantage!

• INCLUDED: Fully Automatic, High Quality, Computerized Antenna Coupler with 10 Meter Control Cable ALL AT NO ADDITION COST - Competitive Advantage!

• Integrated Fan within Isolated Cavity Keeps Humid Cooling Air Away From Sensitive Electronics

• Dedicated RF Gain Control Rotary Knob - Competitive Advantage!

• Easy Front Panel "Clarifier" Control via Rotary Knob - Competitive Advantage!

• Fully Compatible with SCS Pactor IIe and SCS Pactor II PRO HF Modems

• 100% "Sailmail" Compatibility

• 100% "Airmail" PC Software Compatibility with Radio Control (Requires SCS PACTOR IIpro)

• Single Rear Panel, Positive Locking Connection to Remote SCS Modem (w/Modem Supply Power Provided)

• FREE - Open Transmitter for Full Transmit From 1.8 - 27.5MHz (Ham license require when TX is used in non- marine bands)

• Receiver open for .1-30MHz

• Direct Keypad or Rotary Knob Channel Entry

• 20% Smaller "Foot Print" Than Leading Competitor - Competitive Advantage!

• All ITU and USA Channels

• Programmed In Memory

• Multiple Scan/Sweep Modes and Included 2182 Watch Alarm

• Ruggedized Aluminum Chassis With Unique "Low Noise" Compartmentalized RF Section Design

• 199 User Channels and Alphanumeric Channel Name Capabilities

• 12VDC Operation with 2 Year Warranty

The FM4000 Radiotelephone is a rugged, reliable 1 Watt and 25 Watt radio with built-in DSC functionality built to withstand the harshest conditions that may be encountered at sea. Its compact, waterproof case design allows a simplified installation on any steering console, helm or flybridge. Dedicated control buttons and a rapidly operated rotary channel selector offer easy access to all U.S. and international marine VHF channels. Instant Channel 16 access, up-to-date marine weather reports on 10 different channels and other advanced features are at your fingertips.

With the optional Remote Second-Station Control Microphone, available in either black or white finish, you can control all available functions of the FM4000 VHF Radio (except DSC operation) from a remote location such as a deck or flybridge. The remote mic also has a one-touch Channel 16/9 Key and can double as a handy intercom system, allowing you to talk with the FM4000 transceiver.

Features:

• 25 W or 1 W RF Output Power

• Built-in DSC meets Class D ITU-R M493-11/EN 301 025 requirement

• 30 W PA, FOG, Bells and Whistles with Listen Back

• Audio tone control

• Waterproof speaker microphone provides clear reception and transmission

• Easy channel selection with large rotary control

• Quick access to channel 16/9 Key

• Features a large alpha numeric keypad

• Optional voice scrambler provides private communications with other radios equipped with scramblers

Furuno’s PG500R is a rate compensated heading sensor that incorporates innovative electromagnetic compass technology for highly accurate and stable readouts of your ship’s heading. These sophisticated components are contained within a rugged, compact case that protects against the elements at sea. Unique design elements make the PG500R virtually maintenance-free and easy to install.

The PG500R heading sensor detects terrestrial magnetism and produces compass data that can be utilized in NMEA0183 and Furuno AD10 formats. Typical applications include true radar echo trail and true motion, auto pilots, video plotters, scanning sonars and more.

Standard Features:

• Offers a high level of accuracy and stability - 1.0

• Automatic compensation for deviation and heeling error, with proper GPS input

• Compact, waterproof case allows for simple installation

• PG500R can be used with the ARP10 or ARP11 auto-plotter

• 12, 24 or 32 VDC

We are excited to introduce our second generation Satellite Compass, the SC50, which utilizes Furunos advanced GPS Kinematic technology. Satellite Compass performance is not affected by ships speed, latitude, geomagnetism, etc. This hybrid integration of GPS receiver technology and a 3-axis solid-state rate sensor provide accurate and steady heading information, even when bridges or tall buildings block satellite signals. Unlike conventional magnetic and gyro compasses, accuracy is not affected by G-force or velocity. Furthermore, when compared to other GPS based compass systems incorporating only two antennas, our addition of a third GPS antenna provides enhanced accuracy while reducing the negative effects of pitch, roll, and yaw.

The SC50 offers highly accurate GPS WAAS Data for SOG, COG, ROT, and L/L. Multiple, programmable hi-speed heading data outputs allow you to send this information where you need it, and our unique Analog Pitch and Roll Output can be used to enhance your Furuno Sonar System.

This Satellite Compass is ideal as an alternative to a traditionally expensive and high-maintenance gyrocompass for non-compulsory vessels, as well as being the perfect back up solution to a gyro for a compulsory vessel. The SC50 offers a wide range of applications for providing fast, stable, precision heading information to numerous devices, including: Radar/ARPA, Satellite Communications & TV systems, Autopilots (based upon I/F type), AIS, ECDIS, Scanning Sonar, Chart Plotters, etc.

Standard Features

• Newly designed processor unit, providing enhanced accuracy and performance

• Multiple, programmable hi-speed heading data outputs in IEC 61121-1/2(NMEA0183/HS)

• Highly Accurate GPS WAAS Data - SOG, COG, ROT, and L/L

• Unique Analog Pitch and Roll Output for Furuno Sonar Systems

• Heading information for Radar/ARPA, AIS, ECDIS, Scanning Sonar and Chart Plotter

• Typical heading accuracy of 0.8 degrees for SC50

• Tri-antenna system reduces effect of pitching, rolling and yawing

• Short settling time of 3-4 minutes

• Clear 4.5 inch backlit Silver Bright LCD

• Heading output in NMEA 0183, IEC 61162-1 and AD-10 (25ms update)

• Four display modes: Compass Rose, Steering, Nav Data, Heading Mode

• Follow-up rate of 25 degrees/second

• Works as normal GPS navigator

• 12 discrete channels

• No mechanical parts such as gimbals or rotating meter, making compass free from routine maintenance

• IMO MSC.116(73) Type Approved as a verified THD -Transmitting Heading Device

FI505

Our professionally designed instrument series is designed to meet the needs of sail boaters and power boaters alike. These units utilize NMEA2000 to communicate with other units. It’s single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves or part of your new NavNet 3D helm, this addition will be both useful and enhance the beauty of your helm.

The FI505 provides a digital compass readout with an off-the-course needle to help you keep steering on an accurate course.

FI505 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• Dual Digital/Analog format display

• Displays Current Heading, Locked Heading, Average Heading, and Course Over Ground (COG)

The SC30 Satellite Compass provides highly accurate attitude information for navigation equipment such as radar, plotter, autopilot, fish finder and sonar It can be used for a wide variety of applications on any type of vessel.

The SC30 comes with a compact GPS antenna and built-in processor. This all-in-one system delivers incredibly accurate heading and roll & pitch information as well as heaving information, GPS position, SOG (Speed Over Ground), COG (Course Over Ground) and ROT (Rate Of Turn) data.

Employing a two-antenna system with a 3-axis gyro and acceleration sensors, the SC30 enables high-speed response capability. Advanced digital signal processing techniques compute accurate heading based on sensor data. NMEA2000 interface is standard for simple installation, while the optional interface unit IF-NMEASC is available for conventional NMEA0183, AD10 and contact closure.

Revolutionary 2-antenna and rate sensor system

In order to calculate roll & pitch data, a satellite compass requires two vectors. The new SC30 employs a 2-antenna system that calculates a single vector while a 3-axis rate gyro and acceleration sensors add the 2nd vector. This configuration enables the SC30 to calculate highly accurate roll and pitch data without using a third sensor. The SC30 employs the LAMBDA algorithm developed by Prof. Teussen, Delft University of Technology, The Netherlands.

Standard Features:

• Stylish design to complement the appearance of recreational boats

• All-in-on system for simple, space-saving installation

• Heading accuracy of 0.5 degrees rms

• Short start-up time of 3 minutes

• Excellent follow-up rate of 45 degrees/second exceeds requirement for high speed craft

• Free from regular maintenance

• NMEA2000 interface standard

FI503

Our professionally designed instrument series is designed to meet the needs of sail boaters and power boaters alike. These units utilize NMEA2000 to communicate with other units. It’s single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves or part of your new NavNet 3D helm, this addition will be both useful and enhance the beauty of your helm.

The FI503 displays the most important data while navigating, such as depth and speed log functions in a horizontal 3 way split screen.

FI503 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• Dual Digital/Analog format display

• Displays Depth, Speed, Wind Angle, Wind Direction, Timer, Water Temp, Air Temp, Air Pressure, Dewpoint, Chill, Battery Voltage, Time, Date, Heading, Nav Data, Engine, Rudder Angle

FI50DSW - Depth/Speed/Wind

Our professionally designed FI50 instrument series is designed to meet the needs of sail boaters and power boaters alike. The FI50DSW package offers a solution to boaters looking for an economical solution to display wind speed and direction, vessel speed through water, water depth and water temperature, as well as providing an excellent NMEA2000 backbone for future expandability.

The FI50DSW package consists of two displays, a wind sensor, thru-hull transducer and NMEA2000 junction box. All units in the package utilize NMEA2000 to communicate with each other and with other NMEA2000 devices. Single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves, as a part of your new NavNet 3D helm, or as a NMEA2000 backbone for you to expand upon, the FI50DSW will be a functional and beautiful addition to your helm.

The FI5001 is an analog Wind Transducer capable of detecting wind angle accuracy of better than +/-10 degrees and wind speed accuracy of better than +/-5% (20 kt). Apparent wind direction is displayed on the FI501 Display in both digital and analog format.

The new DST-800PSF Retractable Smart Sensor offers depth, speed and temperature functions in one compact thru-hull fitting. Only one hole in the boats hull makes this multisensor attractive to both boat builders and boat owners alike. Depth, water temperature and speed through water are shown on the FI503 Display in a horizontal 3 way split screen.

The FI5002 is an NMEA2000 Junction Box that features 2 NMEA2000 backbone ports, as well as 6 NMEA2000 ports. Its power requirements are less than 2A on a 12VDC system.

FI50 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• FI501: Dual Digital/Analog format displays Wind Angle and Speed

• FI503: Displays Depth, Speed, Wind Angle, Wind Direction, Timer, Water Temp, Air Temp, Air Pressure, Dewpoint, Chill, Battery Voltage, Time, Date, Heading, Nav Data, Engine, Rudder Angle



• Detects wind angle accuracy of better than +/-10 degrees

• Detects wind speed accuracy of better than +/-5% (20 kt)

• Power requirement of less than 40 mA on a 12VDC system

• 30 Meter cable included



• 2 NMEA2000 backbone ports

• 6 NMEA2000 ports

• Less than 2A power requirement on a 12VDC system



FI504

Our professionally designed instrument series is designed to meet the needs of sail boaters and power boaters alike. These units utilize NMEA2000 to communicate with other units. It’s single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves or part of your new NavNet 3D helm, this addition will be both useful and enhance the beauty of your helm.

The FI504 features a large segmented LCD which allows for easy monitoring of all of the data available in the network with alphanumeric digits.

FI504 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• Dual Digital/Analog format display

• Displays Depth, Speed, Wind Angle, Wind Direction, Timer, Water Temp, Air Temp, Air Pressure, Dewpoint, Chill, Rudder

RD33

The RD33 is a navigational data organizer that allows the operator to select the perfect way to display data from interfaced equipment such as GPS, chartplotter, radar, fish finder, autopilot, instruments and other sensors including engine information. The high contrast, color 4.3" LCD may be installed in a compact space, remote from its sources. The screen is impressively bright, remarkably crisp and easy to read. Various display modes are available including Speedometer, Highway and Text. The text mode presents up to six of the most necessary types of data. The display layout can be customized for your specific needs.

This versatile product can also be added to a NavNet 3D system, displaying a variety of navigation data from the CAN bus network.

The RD33 accepts a wide variety of navigation data and displays them in numerical and graphic formats. You may freely select and arrange which data is displayed on the screen. Furthermore, seven patterns of customized display set tings can be stored in the memory to give speedy access and convenience while onboard.

The RD33 features a visually appealing fresh new look, combining easy access with user functionality. Thanks to the bright, high-resolution LCD, the RD33 provides an easy-to-read display to monitor information from remote equipment, through an intuitive graphical user interface.

Features:

• 4.3" Sunlight Viewable color LCD (Brightness: 700 cd)

• Enhanced data legibility thanks to large characters and high resolution display

• Customizable display format from Full-screen to a 6-way split screen presentation

• Supports both CAN bus and NMEA0183 interfaces

• Two independent CAN bus input and output ports incorporated for daisy chain networking

• Internal NMEA0183/CAN bus conversion capability available

• Simultaneous alarm monitoring capabilities for Water Temp, Depth, Speed, Arrival, Anchor, XTE, Trip, Odometer, Timer and Countdown Timer, Roll & Pitch, Wind Speed, Wind Direction, and Battery

FI506

Our professionally designed instrument series is designed to meet the needs of sail boaters and power boaters alike. These units utilize NMEA2000 to communicate with other units. It’s single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves or part of your new NavNet 3D helm, this addition will be both useful and enhance the beauty of your helm.

The FI506 connects to your autopilot to provide precise Rudder Angle information.

FI506 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• Dual Digital/Analog format display

• Displays precise Rudder Angle

FI501

Our professionally designed instrument series is designed to meet the needs of sail boaters and power boaters alike. These units utilize NMEA2000 to communicate with other units. It’s single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves or part of your new NavNet 3D helm, this addition will be both useful and enhance the beauty of your helm.

The apparent wind direction is displayed on the FI501 in both digital and analog format when connected to the wind sensor or other wind measurement system.

FI501 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• Dual Digital/Analog format display

• Displays Wind Angle and Speed

FI502

Our professionally designed instrument series is designed to meet the needs of sail boaters and power boaters alike. These units utilize NMEA2000 to communicate with other units. It’s single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves or part of your new NavNet 3D helm, this addition will be both useful and enhance the beauty of your helm.

The FI502 is a repeater display of the FI501 for more detailed and precise wind measurement of the bearing between 20 and 60 degrees. It is designed for professional sail boaters.

FI502 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• Dual Digital/Analog format display

• Displays Wind Angle and Speed

FI50BW - Basic Wind
Our professionally designed FI50 instrument series is designed to meet the needs of sail boaters and power boaters alike. The FI50BW package offers a solution to boaters looking for an economical solution to display wind speed and direction.

The FI50BW package consists of the FI5001 Wind Sensor and FI501 Wind Display. The units utilize NMEA2000 to communicate with each other and with other NMEA2000 devices. Single-wire installation and full compatibility with other navigation equipment facilitates an easy plug-and-play installation. Whether you use these instruments by themselves or as a part of your new NavNet 3D helm, the FI50BW will be a functional and beautiful addition to your helm.

The FI5001 is an analog Wind Transducer capable of detecting wind angle accuracy of better than +/-10 degrees and wind speed accuracy of better than +/-5% (20 kt). Apparent wind direction is displayed on the FI501 Display in both digital and analog format.

FI501 Features:

• Easy to read, high contrast backlit LCD

• Automatic backlight sensor minimizes power consumption

• "Plug and Play" system utilizing NMEA2000 protocol

• Easy installation with hole-saw flush mount

• Ideal for mast or bulkhead mounting

• Waterproof to IP56 standard

• Dual Digital/Analog format display

• Displays Wind Angle and Speed



The new DST-800PSF Retractable Smart Sensor offers depth, speed and temperature functions in one compact thruhull fitting. Only one hole in the boats hull makes this multisensor attractive to both boat builders and boat owners alike. The DST-800PSF is a NMEA2000 device. The wide fore-aft, fan shaped beam is able to find bottom even when installed on high deadrise hulls or on sailboats.

Features:

The new DST-800PWF Transom Mount Smart Sensor offers depth, speed and temperature functions in one compact fitting.
The DST-800PWF is a NMEA2000 device. The 11 degree beam is able to find bottom even when installed on high deadrise hulls or on sailboats.

Features:

The new DT-800PSF Retractable Smart Sensor offers depth and temperature functions in one compact thruhull fitting. Only one hole in the boats hull makes this multisensor attractive to both boat builders and boat owners alike. The DT-800PSF is a NMEA2000 device. The 12x beam is able to find bottom even when installed on high deadrise hulls or on sailboats.

Features:

Furuno’s BBWGPS WAAS/GPS Receiver Antenna makes any NavNet product capable of receiving WAAS and GPS information. Now there is no need to have a separate unit to get your WAAS/GPS fix. This WAAS/GPS Receiver Antenna has everything you need built-in, and it delivers accuracy better then 3 meters by decoding GPS correction signals from the WAAS (Wide Area Augmentation System).

In addition to its WAAS capability, the antenna has a compact 12-channel GPS Receiver that provides accurate and reliable position fixing. Simply connect the antenna to any NavNet display and you can display WAAS/GPS information on one display or the entire NavNet network.

Standard Features

• WAAS (Wide Area Augmentation System) Receiver

• 12 Channel, All-in-View Parallel Tracking GPS Receiver

• Up to 900 Knot Tracking Velocity

• 90 Second Cold Start Acquisition, 20 Second Warm State Acquisition

• 3M Accuracy or higher (95% of the time, SA off)

• WAAS On/Off Selectable *

• 5 Lbs., 1 Carton

• 12 VDC at 100 mA

1. *For more information on WAAS, please check the USCG Navigational Center web site:

   www.navcen.uscg.gov

ARP11

The ARP11 is a 10-target auto plotter designed for use with NavNet and NavNet vx2, as well as the FR8002 Radar series.

The ARP automatically tracks automatically or manually acquired radar targets and calculates their courses and speeds, indicating them by vectors. Since the data generated by the auto plotter are based on what radar targets are selected, the radar must always be optimally tuned for use with the ARP to ensure required targets will not be lost or unwanted targets such as sea returns and noise will not be acquired and tracked.

The plotting accuracy and response of this ARP meets IMO standards. Tracking accuracy is affected by the following:

• Tracking accuracy is affected by course change. One to two minutes is required to restore vectors to full accuracy after an abrupt course change. (The actual amount depends on gyrocompass specifications.)

• The amount of tracking delay is inversely proportional to the relative speed of the target. Delay is on the order of 15-30 seconds for high relative speed; 30-60 seconds for low relative speed.

Furuno Speed/Temp Sensor Pigtail made for Furuno’s FCV1150

• 1 x 6-Pin(F)

• 2 meters

FA30

The FA30 Automatic Identification System (AIS) Receiver provides real-time information about AIS-equipped vessels to your NavNet vx2, AIS-ready chart plotter, navigation software or radar. The information is graphically presented allowing you to monitor and avoid AIS equipped vessels in your area. The information that the FA30 receives includes the vessel name and call sign, position, course, speed over ground, and other useful information. Since AIS targets can be received even if they are not within line of sight, the FA30 enhances situational awareness in congested waterways, limited visibility or heavy sea conditions, and gives the navigator much more information about AIS equipped vessels.

The FA30 has an Ethernet and a serial port. This provides simple and easy connection by Ethernet to Navnet VX2 and NavNet 3D systems, MaxSea NavNet Navigation software, and the MaxSea AIS viewer PC software that is included with the FA30. AIS capable radar, chart plotters and Non-Navnet versions of MaxSea are interfaced through the FA-30 serial port. The FA-30 will work with virtually any marine VHF antenna. An optional VHF signal splitter is offered to allow the FA-30 to work with an existing VHF radio antenna installation.

Standard Features:

• Enhances safe navigation by receiving critical navigation information from local AIS-equipped vessels

• Vastly improves situational awareness in any weather conditions including dense fog, darkness, and congested waterways

• Dual parallel channel, Full Duplex receiver design receives AIS contact messages up to 100% more frequently than Multiplexing receivers

• High sensitivity, synthesized receiver automatically switches between international and local AIS channels

• Optional amplified VHF splitter allows the use of a single antenna for VHF radio and AIS Receiver

• Network output to NavNet 3D/vx2 and PCs for added redundancy and installation flexibility

• Serial Output for integration with various radar and chart plotter systems

• AIS Viewer Software included for on-board PC or land based installations

• Bulkhead mounting and low power, flexible DC input voltage design for simplified installations

• Receives dual frequencies from 156.025MHz to 162.025MHz

• Static Data:

  • MMSI (Maritime Mobile Service Identity)

  • IMO number

  • Ship’s name

  • Call sign

  • Length and beam

  • Type of ship

  • Location of position-fixing antenna on the ship


• Dynamic Data:

  • Coordinated universal time (UTC)

  • Course over ground (COG)

  • Speed over ground (SOG)

  • Heading

  • Navigation status*


• Voyage Related Data:

  • Ship’s draft*

  • Hazardous cargo

  • Destination and ETA*

  • Safety-related messages


• Alert:

  • LED display

  • Serial data output

FA50

The Furuno FA50 is a Class B AIS (Automatic Identification System) capable of exchanging navigation and ship data between own ship and other ships or coastal stations. It complies with IMO MSC. 140(76) Annex 3, A.694, ITU-R M.1371-2 and DSC ITU-R M.825-3 It also complies with IEC 60945 (EMC and environmental conditions).

The FA50 consists of a transponder unit with GPS antenna. A VHF antenna is required and should be supplied separately. Also included is AIS viewer software from MaxSea, which allows basic display of AIS targets on a PC. The transponder contains a VHF transmitter, two TDMA receivers on two parallel VHF channels, interface, communication processor, and internal GPS receiver. The internal GPS is a 12-channel all-in-view receiver with differential capability. It also gives position, COG and SOG.

Static data:

• MMSI (Maritime Mobile Service Identity)

• Call sign & Ship’s name

• Type of ship

• Location of position-fixing antenna on the ship

• Ship’s position with accuracy indication and integrity status

• Universal Time Coordinated (UTC)

• Course over ground (COG)

• Speed over ground (SOG)

• Heading

• Hazardous cargo (type)

• Short safety-related messages, pre-set messages

NAVpilot 700

Kick back, relax and let NAVpilot steer you to your destination!
FURUNO’s NAVpilot is a revolutionary autopilot with a sunlight viewable display designed for a variety of vessels. It utilizes a self-learning and adaptive software algorithm, and plays the ultimate role in course-keeping capability. NAVpilot dynamically adjusts essential parameters during navigation, such as vessel speed, trim, draught, tide and wind effects, dead band, weather and more. These parameters are stored in the system memory and continuously optimized.

Self-learning and adaptive software

From the first dock-side setup through the last voyage you made, NAVpilot continues to learn your vessel’s steering characteristics. This allows dynamic adjustments to the boat’s steering for vessel speed, trim, draft, tide and wind effects. These characteristics are stored in the processor’s memory where they are continuously optimized to make the NAVpilot more versatile.

SAFE HELM and POWER ASSIST features provide Efficient and Effective Helm Steering Control

The optional SAFE HELM and POWER ASSIST features provide a unique interface to the vessel’s hydraulic hand steering system, providing unrivaled comfort and control of steering directly from any manual helm on the vessel. These two modes greatly reduce steering effort and enhance the safety of your autopilot.

The POWER ASSIST mode incorporates the SAFE HELM concept and provides speed-based, power assisted steering, which greatly reduces manual helm effort in maneuvering situations. POWER ASSIST is a unique helm-activated assisted steering feature that can augment or replace separate electric and power-robbing, engine-driven power steering systems on many vessels. POWER ASSIST reduces steering system complexity and costs while increasing economy.

SAFE HELM and POWER ASSIST modes will require the optional FPS8 Power Steering Module and an appropriate HRP Pumpset, along with a system software update.

FishHunter mode

FishHunter mode is a unique feature of FURUNO’s NAVpilot series. Find a fish target with your FURUNO sonar/sounder or bird target with your FURUNO radar and feed it to the NAVpilot. The NAVpilot will activate the FishHunter mode to perform square, zigzag, circle, orbit, spiral or figure-eight maneuvers around the specified target at a user selected distance. This feature can also be used for Man Overboard (MOB).

Furuno’s new NAVpilot series is designed to match the NavNet 3D, FI-50 Instrument series and other navigation equipment. The "Plug and Play" CAN bus interface allows for easy installation and exceptional interface ability.

Features:

NAVpilot 711

Kick back, relax and let NAVpilot steer you to your destination!
FURUNO’s NAVpilot is a revolutionary autopilot with a sunlight viewable display designed for a variety of vessels. It utilizes a self-learning and adaptive software algorithm, and plays the ultimate role in course-keeping capability. NAVpilot dynamically adjusts essential parameters during navigation, such as vessel speed, trim, draught, tide and wind effects, dead band, weather and more. These parameters are stored in the system memory and continuously optimized.

Self-learning and adaptive software

From the first dock-side setup through the last voyage you made, NAVpilot continues to learn your vessel’s steering characteristics. This allows dynamic adjustments to the boat’s steering for vessel speed, trim, draft, tide and wind effects. These characteristics are stored in the processor’s memory where they are continuously optimized to make the NAVpilot more versatile.

SAFE HELM and POWER ASSIST features provide Efficient and Effective Helm Steering Control

The optional SAFE HELM and POWER ASSIST features provide a unique interface to the vessel’s hydraulic hand steering system, providing unrivaled comfort and control of steering directly from any manual helm on the vessel. These two modes greatly reduce steering effort and enhance the safety of your autopilot.

The POWER ASSIST mode incorporates the SAFE HELM concept and provides speed-based, power assisted steering, which greatly reduces manual helm effort in maneuvering situations. POWER ASSIST is a unique helm-activated assisted steering feature that can augment or replace separate electric and power-robbing, engine-driven power steering systems on many vessels. POWER ASSIST reduces steering system complexity and costs while increasing economy.

SAFE HELM and POWER ASSIST modes will require the optional FPS8 Power Steering Module and an appropriate HRP Pumpset, along with a system software update.

FishHunter mode

FishHunter mode is a unique feature of FURUNO’s NAVpilot series. Find a fish target with your FURUNO sonar/sounder or bird target with your FURUNO radar and feed it to the NAVpilot. The NAVpilot will activate the FishHunter mode to perform square, zigzag, circle, orbit, spiral or figure-eight maneuvers around the specified target at a user selected distance. This feature can also be used for Man Overboard (MOB).

Furuno’s new NAVpilot series is designed to match the NavNet 3D, FI-50 Instrument series and other navigation equipment. The "Plug and Play" CAN bus interface allows for easy installation and exceptional interface ability.

Features:

NAVpilot 720

Kick back, relax and let NAVpilot steer you to your destination!
FURUNO’s NAVpilot is a revolutionary autopilot with a sunlight viewable display designed for a variety of vessels. It utilizes a self-learning and adaptive software algorithm, and plays the ultimate role in course-keeping capability. NAVpilot dynamically adjusts essential parameters during navigation, such as vessel speed, trim, draught, tide and wind effects, dead band, weather and more. These parameters are stored in the system memory and continuously optimized.

Self-learning and adaptive software

From the first dock-side setup through the last voyage you made, NAVpilot continues to learn your vessel’s steering characteristics. This allows dynamic adjustments to the boat’s steering for vessel speed, trim, draft, tide and wind effects. These characteristics are stored in the processor’s memory where they are continuously optimized to make the NAVpilot more versatile.

SAFE HELM and POWER ASSIST features provide Efficient and Effective Helm Steering Control

The optional SAFE HELM and POWER ASSIST features provide a unique interface to the vessel’s hydraulic hand steering system, providing unrivaled comfort and control of steering directly from any manual helm on the vessel. These two modes greatly reduce steering effort and enhance the safety of your autopilot.

The POWER ASSIST mode incorporates the SAFE HELM concept and provides speed-based, power assisted steering, which greatly reduces manual helm effort in maneuvering situations. POWER ASSIST is a unique helm-activated assisted steering feature that can augment or replace separate electric and power-robbing, engine-driven power steering systems on many vessels. POWER ASSIST reduces steering system complexity and costs while increasing economy.

SAFE HELM and POWER ASSIST modes will require the optional FPS8 Power Steering Module and an appropriate HRP Pumpset, along with a system software update.

FishHunter mode

FishHunter mode is a unique feature of FURUNO’s NAVpilot series. Find a fish target with your FURUNO sonar/sounder or bird target with your FURUNO radar and feed it to the NAVpilot. The NAVpilot will activate the FishHunter mode to perform square, zigzag, circle, orbit, spiral or figure-eight maneuvers around the specified target at a user selected distance. This feature can also be used for Man Overboard (MOB).

Furuno’s new NAVpilot series is designed to match the NavNet 3D, FI-50 Instrument series and other navigation equipment. The "Plug and Play" CAN bus interface allows for easy installation and exceptional interface ability.

Features:

Furuno’s new FAX30 can turn any NavNet display or PC into a Weatherfax and Navtex receiver. This waterproof "Black Box" unit connects directly to a NavNet display or an Ethernet hub with a single Ethernet cable. If it is connected to an Ethernet hub that has multiple 10.4" NavNet displays attached, each of those displays will have access to the FAX30. In addition, the FAX30 has the capability of being connected to a standard PC with Ethernet card.

The unit itself receives valuable weather images and navigational information. When connected to a 10.4" NavNet display, the image and information is displayed directly on screen, with softkey menu options for ease of use. On a PC, the images and information are displayed by simply using your Web Browser. There is no complicated proprietary software to install or learn. You can even print all of the information using your PC and printer!

Combine the new FAX30 with NavNet’s true color Radar and you have the ultimate in weather tracking. Now you can navigate more safely even during uncertain conditions.

• Cost effective paperless weatherfax and Navtex receiver

• Connect directly to a 10.4" NavNet display or through an Ethernet hub

• Connect to a generic PC equipped with Ethernet

• Selectable display colors: 8 gray tones, monochrome, blue shades, pink and black, red and blue

• User friendly softkey menu operation on NavNet display

• Web browser navigation on generic PC, no proprietary software required

• Print images and messages from generic PC and printer

• Store a maximum of 12 weatherfax images (depending on file size)

• Navtex messages can be retrieved in a table listing of up to 130 stored files

• Stored images/messages can be shown at any time

• 320 user programmed channels

• Noise rejection for clear image

• Thumbnail view for easy selection of stored images

• Phase and synchronization adjustments even after completed reception

• Fax Frequency Range:

  LF - 80 kHz to 160 kHz

  MF/HF - 2 MHz to 25 MHz

• Navtex
  Frequency Range:

  490 kHz or 518 kHz

• 1,000 channels

• Fax Mode of Reception:

  F3C, J3C

• Navtex Mode of Reception: F1B

• Waterproof- IEC 60529

• 8 lbs., 1 Carton


• 12-24 VDC, 15 W Max.

DFF1

Furuno’s DFF1 is a new network sounder featuring Furuno Digital Filter (FDF) Technology designed for use with NavNet and NavNet vx2. This new digital Network Sounder can turn any NavNet display into a powerful, dual-frequency digital fish finder. The compact network sounder unit connects directly to a NavNet display or an Ethernet hub with a single Ethernet cable. If it is connected to an Ethernet hub that has multiple displays attached, each of those displays will have access to the Network Sounder.

The sounder itself has a selectable 600W or 1kW output power. You may choose LF (50kHz), HF (200kHz) or both at the touch of a key and obtain detailed echoes of bottom structure and fish using range scales of up to 5,000 ft. And because the Network Sounder is used on a NavNet display, you will also be able to use its Radar and Chart Plotter features depending on which unit you have.

Standard Features:

• Works with NavNet and NavNet vx2

• Dual-Frequency 50/200 kHz

• New DSP (Digital Signal Processing) Filter makes the picture clearer and easier to discriminate between baitfish and larger target species

• DSP technology helps adjust gain and output power as well as suppresses main bang (echoes just below transducer)

• 8/16/64 Color Echo Presentations

• 8 Range Scales to 2,500 feet

• Selectable output power of 600W or 1kW

• Audio and visual alarms for water depth, fish echoes and water temperature*

• Wide variety of transducer options

• Selectable automatic cruising or fishing modes to suit your style of boating

• Automatic function for detecting fish and bottom in both shallow and deep water

• White line feature helps discriminate fish lying near the bottom

Dff3

Furuno’s DFF3 is a new network sounder featuring FDF (Furuno Digital Filter) signal processing technology. The DFF3 is designed for use with NavNet, NavNet vx2 and NavNet 3D. This new digital Network Sounder can turn any NavNet display into a powerful, dual-frequency digital fish finder. The compact network sounder unit connects directly to a NavNet display or an Ethernet hub with a single Ethernet cable. If it is connected to an Ethernet hub that has multiple displays attached, each of those displays will have access to the Network Sounder.

The sounder itself has a selectable 1, 2 or 3kW output power. You may choose any two operating frequencies from 28 to 200kHz with FFS (Furuno Free Synthesis) technology. With the powerful DFF3, you can obtain detailed echoes of bottom structure and fish using range scales of up to 3,000 meters (nearly 10,000 feet). And because the Network Sounder is used on a NavNet display, you will also be able to use its Radar and Chart Plotter features depending on which unit you have.

The DFF3 is a direct replacement for the BBFF3 network sounder.

• Utilizes FDF (Furuno Digital Filter) signal processing technology

• Output power 1 to 3 kW

• Furuno Free Synthesizer (FFS) allows for selectable operating frequency of 28 to 200 kHz

• Dual frequency, alternate transmission

• Works with NavNet1, NavNet vx2 and NavNet 3D with no software update required

• Compatible with Airmar transducer ID technology

• Heaving compensation with use of the SC-30/50/110

• Variable Transmission Rate for different depth ranges allows for more detailed observation of bottom

• Dedicated 6-pin temperature sensor port available

• WAGO connection for ease of installation

The FCV585 is a dual frequency (50 kHz and 200 kHz) Color LCD Sounder featuring Furuno’s DSP technology. The FCV585 displays underwater conditions in 8, 16 or 64 colors on a super-bright 8.4" LCD screen.

You’ve probably heard about digital fish finders, but aren’t quite sure what the difference is. The main difference is the filtering capabilities and auto adjustments. Our new DSP (Digital Signal Processing) technology helps adjust gain, STC Clutter and output power, as well as suppress main bang (the echoes just below the transducer.) It also makes the picture clearer and easier to decipher. But even the best digital filter wont help unless you start with a solid basis, such as Furunos renowned fish finder technology.

The FCV585’s waterproof construction allows it to be installed on any bridge. Audio and visual alarms alert you whenever preset limits are met for water depth, water temperature and fish echoes. Selectable display modes include High or Low Frequency, Dual Frequency, Zoom, Nav Data, A-Scope, Marker Zoom, Bottom Zoom or Bottom-Lock. Furuno’s TLL (Target Lat/Lon) output allows you to interface the FCV585 with your Furuno chart plotter so you can mark any spot you desire and save it as a waypoint, enabling you to return to it whenever you desire.

Standard Features:

• Dual-Frequency 50/200 kHz

• New DSP Filter makes the picture clearer and easier to discriminate between baitfish and larger target species

• 8/16/64 Color Echo Presentations

• Hands free adjustments of gain, STC & output power through digital filtering

• 8 Range Scales to 2,500 feet

• High output power of 600W or 1kW

• Audio and visual alarms for water depth, fish echoes and water temperature*

• Wide variety of transducer options

• Bright, 8.4" color LCD gives excellent readability even in broad daylight

• Waterproof construction permits installation on open bridge

• Selectable automatic cruising or fishing modes to suit your style of boating

• Automatic function for detecting fish and bottom in both shallow and deep water

• User-programmable nav data display provides analog and digital nav data*

• Alarms: Bottom, Fish (bottom lock and normal), Speed, Water Temperature and Arrival (Speed, arrival and water temperature alarms require appropriate sensor)

• White line feature helps discriminate fish lying near the bottom

• Destination waypoint feature provides range, bearing, and time-to-go to destination waypoint (up to 20 waypoints)

• 12-24 VDC

• 1.5 to 0.5 A

The FCV620 is a dual frequency (50 kHz and 200 kHz) Color LCD Sounder featuring Furuno’s DSP technology that displays underwater conditions in 8, 16 or 64 colors on a super-bright 5.6" LCD screen.

You’ve probably heard about digital fish finders, but aren’t quite sure what the difference is. The main difference is the filtering capabilities and auto adjustments. Our new DSP (Digital Signal Processing) technology helps adjust gain, STC Clutter and output power, as well as suppress main bang (the echoes just below the transducer.) It also makes the picture clearer and easier to decipher. But even the best digital filter wont help unless you start with a solid basis, such as Furunos renowned fish finder technology.

The FCV620’s waterproof construction allows it to be installed on any bridge. Audio and visual alarms alert you whenever preset limits are met for water depth, water temperature and fish echoes. Selectable display modes include High or Low Frequency, Dual Frequency, Zoom, Nav Data, A-Scope, Marker Zoom, Bottom Zoom or Bottom-Lock. Furuno’s TLL (Target Lat/Lon) output allows you to interface the FCV620 with your Furuno chart plotter so you can mark any spot you desire and save it as a waypoint, enabling you to return to it whenever you desire.

Standard Features:

• Dual-Frequency 50/200 kHz

• New DSP Filter makes the picture clearer and easier to discriminate between baitfish and larger target species

• 8/16/64 Color Echo Presentations

• Hands free adjustments of gain, STC & output power through digital filtering

• 8 Range Scales to 2,500 feet

• High output power of 600W

• Audio and visual alarms for water depth, fish echoes and water temperature*

• Wide variety of transducer options

• Bright, 5.6" color LCD gives excellent readability even in broad daylight

• Waterproof construction permits installation on open bridge

• Selectable automatic cruising or fishing modes to suit your style of boating

• Automatic function for detecting fish and bottom in both shallow and deep water

• User-programmable nav data display provides analog and digital nav data*

• Alarms: Bottom, Fish (bottom lock and normal), Speed, Water Temperature and Arrival (Speed, arrival and water temperature alarms require appropriate sensor)

• White line feature helps discriminate fish lying near the bottom

• Fast transmission rate of 3,000 PRR (Pulse Repetition Rate) per second for enhanced shallow water detection

• 12-24 VDC

• 1 to 0.5 A

FCV620 Package

Package Includes

• Furuno FCV-620 5.6" Color LCD

• Furuno 525ST-PWD Transom Mount Tri-Ducer

• Dual-Frequency 50/200 kHz

• New DSP Filter makes the picture clearer and easier to discriminate between baitfish and larger target species

• 8/16/64 Color Echo Presentations

• Hands free adjustments of gain, STC & output power through digital filtering

• 8 Range Scales to 2,500 feet

• High output power of 600W

• Audio and visual alarms for water depth, fish echoes and water temperature*

• Wide variety of transducer options

• Bright, 5.6" color LCD gives excellent readability even in broad daylight

• Waterproof construction permits installation on open bridge

• Selectable automatic cruising or fishing modes to suit your style of boating

• Automatic function for detecting fish and bottom in both shallow and deep water

• User-programmable nav data display provides analog and digital nav data*

• Alarms: Bottom, Fish (bottom lock and normal), Speed, Water Temperature and Arrival (Speed, arrival and water temperature alarms require appropriate sensor)

• White line feature helps discriminate fish lying near the bottom

• Fast transmission rate of 3,000 PRR (Pulse Repetition Rate) per second for enhanced shallow water detection

• 12-24 VDC

• 1 to 0.5 A

Furuno FCV-620 Package

Package Includes

• FCV-620 5.6" Color LCD

• Furuno 525STID-MSD Thru-Hull Tri-Ducer

• Dual-Frequency 50/200 kHz

• New DSP Filter makes the picture clearer and easier to discriminate between baitfish and larger target species

• 8/16/64 Color Echo Presentations

• Hands free adjustments of gain, STC & output power through digital filtering

• 8 Range Scales to 2,500 feet

• High output power of 600W

• Audio and visual alarms for water depth, fish echoes and water temperature*

• Wide variety of transducer options

• Bright, 5.6’ color LCD gives excellent readability even in broad daylight

• Waterproof construction permits installation on open bridge

• Selectable automatic cruising or fishing modes to suit your style of boating

• Automatic function for detecting fish and bottom in both shallow and deep water

• User-programmable nav data display provides analog and digital nav data*

• Alarms: Bottom, Fish (bottom lock and normal), Speed, Water Temperature and Arrival (Speed, arrival and water Temperature alarms require appropriate sensor)

• White line feature helps discriminate fish lying near the bottom

• Fast transmission rate of 3,000 PRR (Pulse Repetition Rate) per second for enhanced shallow water detection

• 12-24 VDC

• 1 to 0.5 A

The FCV1150 is a color digital sounder designed for a variety of professional fishing operations. It’s high-brightness 12.1" color LCD with AR coated glass filter provides superior, glare-free viewing even in direct sunlight.

The FCV1150 employs Furuno Free Synthesizer (FFS) technology which permits a wide selection of operating frequencies from 28 to 200kHz. If a Furuno transducer is used, operating frequency is automatically set in the menu, and can be shifted manually at any time. This feature is useful for vessels targeting many different species of fish, and may also be used to eliminate interference that may be caused by nearby ships with transducers operating at the same frequency. Output power is selectable among 1,2 or 3 kW.

A wide variety of display modes and functions are available that provide captains with simple and intuitive information for virtually any fishing requirement including Single (HF/LF), Dual, Single + Zoom, Zoom (Bottom Lock, Bottom Zoom or Marker Zoom), Mix Mode, Nav Data and A-Scope. Additionally, two custom display modes may be programmed by the operator. The FCV1150 can be interfaced with a Furuno Satellite Compass to compensate for heaving caused by the movement of the ocean, providing unwavering, stable detection even in rough seas.

Faster Transmission Rate:
The rate of transmission has been greatly increased by more than 30% compared with current conventional fish finders. As a result, more detailed information about underwater conditions can be gained in the same sounding interval. The FCV1150 also incorporates new transmission technique that automatically switches the echo transmission rate according to the depth of the sounding area. Transmission speed is raised in shallow waters and lowered in deep waters, providing more detailed detection of seabed and targets.

Quick Gain Setting:
The Gain setting for all of the echoes on the screen can be adjusted by rotating the Gain knob. Because all of the visible echoes on the screen are adjusted with the Gain settings, the correct setting for virtually any situation can be quickly and easily determined.

White Edge:
The top of the seabed is displayed in white to show seabed structure. This function also helps to discriminate between bottom fish and seabed.

Standard Features:

• High-brightness 12.1" LCD with AR coated glass filter and anti-polarized sunglass filter

• Postprocessing Gain Control applied to all echoes displayed on the screen

• White Edge bottom discrimination feature

• Heaving compensation available for stable echo presentation even in rough seas

• Furuno Digital Filter (FDF) delivers crystal clear target presentation

• Adjustable operating frequency and selectable output power

• 12-24 VDC, 50W max

• 100/110/220/230 VAC with optional rectifier

The FCV-295 is a new color digital sounder designed for a variety of professional fishing operations. It features a bonded "fogging-free" 10.4" LCD display providing superior viewing even in direct sunlight. You can display echoes in 8, 16, or 64 colors, with color assignment dependent on the strength of the returned echo.

The FURUNO Free Synthesizer (FFS) Transceiver allows a wide selection of operating frequencies. You may choose any two frequencies between 28 and 200 kHz to fit your fishing operation. Output power is selectable from 1, 2 or 3 kW. A wide variety of display modes and functions are available, which provide skippers with simple and intuitive information.

Furuno Digital Filter (FDF)
FURUNO digital filter optimizes the gain to obtain highly defined images of underwater conditions. The FCV-295 can clearly show target fish close to the seabed.The digital filter also eliminates noise to deliver sharp and detailed echo presentation, achieving detection of fishing reef and even individual fish with absolute clarity.

Operating Frequency Adjustment
When FURUNO transducers are connected and set to the FCV-295, the operating frequency range will be registered and shown in the menu. The user can shift the operating frequency freely between the ranges at any time from the menu. With the FURUNO 82B-35R transducer, the operator can select any operating frequency from 66 to 109 kHz. This feature is particularly useful for vessels targeting many different species, or when the fish finders of other ships in the area cause interference.

Faster Transmission Rate For Detailed Detection
The rate of transmission is increased by more than 30% compared to conventional fish finders. As the result, more detailed information about underwater conditions can be gained through the same sounding interval. With the FCV-295’s AUTO transmission function, the rate is automatically raised in shallow waters and lowered in deep waters, which provides for detailed detection of seabed targets.

Standard Features:

• 10.4" ’Fogging-Free’ color LCD provides clear view in any weather conditions

• Post-processing gain control applies to all existing returns on the display

• White Edge function trace the bottom contour with a thin white line

• FURUNO Digital Filter delivers crystal clear target presentation

• FURUNO Free Synthesizer transceiver allows adjustable operating frequency

The LS4100 is a dual frequency fish finder designed for small pleasure craft. It features a waterproof 5 high-definition silver bright LCD screen that offers a remarkably detailed picture of fish and bottom structure. With a resolution of 240 (H) x 320 (V) pixels, it has the highest resolution in its class! The LS4100 offers dual frequency capabilities, both 50 and 200 kHz, and has an outstanding 300 W RMS (2,400 Watt peak-to-peak) output power, making this fish finder the leader in its class.

Basic display modes include single Low Frequency or High Frequency, Dual, Bottom-Lock Expansion, Bottom Zoom, A-scope, Marker Zoom and two Nav Data display modes. Choose from a variety of operating modes, including manual or two auto modes, fishing or cruising. The cruising mode uses a higher clutter refection setting than the fishing mode, making it useful to track the bottom while cruising.

The range can be changed manually or automatically. The LS4100 will redraw the entire echogram so that the contour can be shown seamlessly.

The LS4100 has the unique ability to be a handy navigational organizer when connected to appropriate sensors. It can display a variety of information including: water temperature, wind direction/speed, Lat/Lon, XTE and distance run in a graphical or text format. With the BBWGPS GPS/WAAS receiver connected, the Mini-Navigator feature is capable of storing up to 12 waypoints with a programmable name. Any waypoint can be selected as a destination.

Standard Features

• Waterproof, 5 Inch, Silver Bright Monochrome LCD Display

• Dual Frequency - 50 and 200 kHz

• Targets presented in up to 4 gray tones

• Picture resolution of 240(H) x 320(V) pixels

• 300 Watt RMS (2400 P-P) output power

• Seven depth scales, from 0-10 to 0-640 feet

• Depth offset to 1,500 feet, maximum depth scale of 3,000 feet

• Automatic or Manual Depth Range and Gain Adjustment

• A-Scope for rapid fish detection and species identification

• White Line Mode for enhanced bottom fish detection

• Audible and Visual, Temp, Speed, Fish or Bottom Alarm

• TLL output sends position, temp and depth to Furuno TLL capable plotters

• Multiple Display Modes

  1. Normal, Low Frequency/High Frequency

  2. Dual Frequency

  3. Bottom Lock Expansion

  4. Marker Zoom

  5. Bottom Zoom

  6. A-Scope

  7. Two Customizable Navigation Data Display - Displaying digital and analog graphical info, including: Wind Speed/Direction, Ship’s Speed, Steering Screens and more

• Speed and Temperature input via optional sensor or NMEA data

• Mini Navigator allows storage of up to 12 waypoints, with capability to navigate back to these points using the LS4100’s XTE/Range and Bearing calculation and steering screens

• Two NMEA0183 ports - one bi-directional and one "listen-only"

• 4Lbs., 1 Carton Less Transducer - Single unit

• 20 Lbs., 1 Carton Less Transducers - 6 units per carton

• 12 VDC, 6 Watts

The LS4100 is a dual frequency fish finder designed for small pleasure craft. It features a waterproof 5 high-definition silver bright LCD screen that offers a remarkably detailed picture of fish and bottom structure. With a resolution of 240 (H) x 320 (V) pixels, it has the highest resolution in its class! The LS4100 offers dual frequency capabilities, both 50 and 200 kHz, and has an outstanding 300 W RMS (2,400 Watt peak-to-peak) output power, making this fish finder the leader in its class.

Basic display modes include single Low Frequency or High Frequency, Dual, Bottom-Lock Expansion, Bottom Zoom, A-scope, Marker Zoom and two Nav Data display modes. Choose from a variety of operating modes, including manual or two auto modes, fishing or cruising. The cruising mode uses a higher clutter refection setting than the fishing mode, making it useful to track the bottom while cruising.

The range can be changed manually or automatically. The LS4100 will redraw the entire echogram so that the contour can be shown seamlessly.

The LS4100 has the unique ability to be a handy navigational organizer when connected to appropriate sensors. It can display a variety of information including: water temperature, wind direction/speed, Lat/Lon, XTE and distance run in a graphical or text format. With the BBWGPS GPS/WAAS receiver connected, the Mini-Navigator feature is capable of storing up to 12 waypoints with a programmable name. Any waypoint can be selected as a destination.

The LS4100TM comes standard with a dual frequency (50/200kHz) plastic transom mount transducer. The transducer has built in depth and temperature.

Standard Features

• Waterproof, 5 Inch, Silver Bright Monochrome LCD Display

• Dual Frequency - 50 and 200 kHz

• Plastic Transom Mount Transducer with Depth and Temperature

• Targets presented in up to 4 gray tones

• Picture resolution of 240(H) x 320(V) pixels

• 300 Watt RMS (2400 P-P) output power

• Seven depth scales, from 0-10 to 0-640 feet

• Depth offset to 1,500 feet, maximum depth scale of 3,000 feet

• Automatic or Manual Depth Range and Gain Adjustment

• A-Scope for rapid fish detection and species identification

• White Line Mode for enhanced bottom fish detection

• Audible and Visual, Temp, Speed, Fish or Bottom Alarm

• TLL output sends position, temp and depth to Furuno TLL capable plotters

• Multiple Display Modes

  1. Normal, Low Frequency/High Frequency

  2. Dual Frequency

  3. Bottom Lock Expansion

  4. Marker Zoom

  5. Bottom Zoom

  6. A-Scope

  7. Two Customizable Navigation Data Display - Displaying digital and analog graphical info, including: Wind Speed/Direction, Ship’s Speed, Steering Screens and more

• Speed and Temperature input via optional sensor or NMEA data

• Mini Navigator allows storage of up to 12 waypoints, with capability to navigate back to these points using the LS4100’s XTE/Range and Bearing calculation and steering screens

• Two NMEA0183 ports - one bi-directional and one "listen-only"

• 7Lbs., 1 Carton including TM transducer - Single unit

• 34 Lbs., 1 Carton including TM Transducers - 6 units per carton

• 12 VDC, 6 Watts

The LS4100 is a dual frequency fish finder designed for small pleasure craft. It features a waterproof 5 high-definition silver bright LCD screen that offers a remarkably detailed picture of fish and bottom structure. With a resolution of 240 (H) x 320 (V) pixels, it has the highest resolution in its class! The LS4100 offers dual frequency capabilities, both 50 and 200 kHz, and has an outstanding 300 W RMS (2,400 Watt peak-to-peak) output power, making this fish finder the leader in its class.

Basic display modes include single Low Frequency or High Frequency, Dual, Bottom-Lock Expansion, Bottom Zoom, A-scope, Marker Zoom and two Nav Data display modes. Choose from a variety of operating modes, including manual or two auto modes, fishing or cruising. The cruising mode uses a higher clutter refection setting than the fishing mode, making it useful to track the bottom while cruising.

The range can be changed manually or automatically. The LS4100 will redraw the entire echogram so that the contour can be shown seamlessly.

The LS4100 has the unique ability to be a handy navigational organizer when connected to appropriate sensors. It can display a variety of information including: water temperature, wind direction/speed, Lat/Lon, XTE and distance run in a graphical or text format. With the BBWGPS GPS/WAAS receiver connected, the Mini-Navigator feature is capable of storing up to 12 waypoints with a programmable name. Any waypoint can be selected as a destination.

The LS4100TH includes a dual frequency (50/200kHz) bronze thru-hull transducer. This transducer has built-in depth and temperature.

Standard Features

• Waterproof, 5 Inch, Silver Bright Monochrome LCD Display

• Dual Frequency - 50 and 200 kHz

• Bronze Thru-hull transducer with Depth and Temperature

• Targets presented in up to 4 gray tones

• Picture resolution of 240(H) x 320(V) pixels

• 300 Watt RMS (2400 P-P) output power

• Seven depth scales, from 0-10 to 0-640 feet

• Depth offset to 1,500 feet, maximum depth scale of 3,000 feet

• Automatic or Manual Depth Range and Gain Adjustment

• A-Scope for rapid fish detection and species identification

• White Line Mode for enhanced bottom fish detection

• Audible and Visual, Temp, Speed, Fish or Bottom Alarm

• TLL output sends position, temp and depth to Furuno TLL capable plotters

• Multiple Display Modes

  1. Normal, Low Frequency/High Frequency

  2. Dual Frequency

  3. Bottom Lock Expansion

  4. Marker Zoom

  5. Bottom Zoom

  6. A-Scope

  7. Two Customizable Navigation Data Display - Displaying digital and analog graphical info, including: Wind Speed/Direction, Ship’s Speed, Steering Screens and more

• Speed and Temperature input via optional sensor or NMEA data

• Mini Navigator allows storage of up to 12 waypoints, with capability to navigate back to these points using the LS4100’s XTE/Range and Bearing calculation and steering screens

• Two NMEA0183 ports - one bi-directional and one "listen-only"

• 9Lbs., 1 Carton including TH transducer - Single unit

• 41 Lbs., 1 Carton including TH transducer - 6 units per carton

• 12 VDC, 6 Watts

Furuno’s LS6100 fish finder is compact, waterproof and best of all powerful. It packs 300 Watts (2,400 p-p) of output power for unparalleled fish finding performance.

The LS6100 offers dual frequency capabilities - both 50 and 200kHz - for a two-way view of the world below your boat. This unit is compact enough to fit practically anywhere. Yet it features a 6" silver bright LCD display that offers a remarkably detailed picture of fish and bottom structure.

In addition to it’s fish finding capability, the LS6100 has the unique ability to be a handy navigational organizer when connected to appropriate sensors. It can display a variety of information including: water temperature, wind direction/speed, Lat/Lon, XTE and distance run in a graphical or text format. With the BBGPS or BBWGPS receiver connected, the "Mini-Navigator" feature is capable of storing up to 12 waypoints with programmable names. Any waypoint can be selected as a destination.

Standard Features

• Waterproof, 6 Inch, Silver Brite Monochrome LCD Display

• Targets presented in up to 4 gray tones

• Picture resolution of 240(H) x 320(V) pixels

• 300 Watt RMS (2400 P-P) output power

• Seven depth scales, from 0-10 to 0-640 feet

• Depth offset to 1,500 feet, maximum depth scale of 3,000 feet

• Automatic or Manual Depth Range and Gain Adjustment

• A-Scope for rapid fish detection and species identification

• White Line Mode for enhanced bottom fish detection

• Audible and Visual, Temp, Speed, Fish or Bottom Alarm

• TLL output sends position, temp and depth to Furuno TLL capable plotters

• Multiple Display Modes

  1. Normal, Low Frequency/High Frequency

  2. Dual Frequency

  3. Bottom Lock Expansion

  4. Marker Zoom

  5. Bottom Zoom

  6. A-Scope

  7. Two Customizable Navigation Data Display - Displaying digital and analog graphical info, including: Wind Speed/Direction, Ship’s Speed, Steering Screens and more


• Speed and Temperature input via optional sensor or NMEA data

• Direct connection of BBGPS or BBWGPS antennas for GPS or WAAS fix

• Mini Navigator allows storage of up to 12 waypoints, with capability to navigate back to these points using the LS6100’s XTE/Range and Bearing calculation and steering screens

• Two NMEA0183 ports - one bi-directional and one "listen-only"

• 5Lbs., 1 Carton Less Transducer

• 12 VDC, 10 Watts

Since its release back in 2001, FURUNOs NavNet series has been enjoying unrivalled popularity worldwide for its high reliability, performance and expandability. It has even been voted Best Integrated Navigation System by the National Marine Electronics Association for three consecutive years. Now, NavNet vx2 is ready to carry on the tradition.

NavNet vx2 combines radar, GPS/WAAS chart plotter, fish finder, and network weather facsimile into an all-round navigation network. Its wide range of options fulfils virtually every desire you may have for navigation system.

Radar, GPS, Network fish finder, Network weather facsimile - a multistation integrated navigation network, NavNet vx2 lets you build your navigation system according to your needs. Utilizing state-of-the-art network technology, NavNet vx2 provides you with seamless data sharing and vast future expandability.

The heart of NavNet vx2 is its Ethernet-based network. Up to four displays, together with various navigational sensors, can be interconnected in addition to new MaxSea-NavNet navigational software, which adds even more features to your NavNet vx2 network. Stress-free navigation can be performed from any display unit connected to the onboard network, due to the high-speed transfer of data available.

• All display units are capable of controlling any component connected to the NavNet network

• Perfect for single or multi display installations

• Fully supports C-Map NT MAX charts.

• Utilizes SD cards for chart and memory.

• Fast chart drawing speed.

• Straightforward Plug n Play installation with wizard style set-up.

• AR-coated, high-brightness display unit for improved sunlight viewability.



• Sunlight Viewable VGA (480 x 640) Display

• Front loading Mini-Chart Card port

• Fully compatible with C-Map NT MAX charts

• Simplified installation with new Network Wizard set-up

• Cursor L/L Position Display **

• On-Screen Display of Vessel Position, Heading, etc. *

• Vessel Position Display in L/L or Loran-C TD’s

• North-Up, Course-Up or Automatic Course-Up display modes

• Plotter, Nav Data, Steering Director or Highway display modes

• Up to 8,000 points for ship’s track and marks, 999 waypoints, 35 quick points, 1 MOB, 200 planned routes (max. 35 waypoints/route) and 1 quick route

• Add Multiple Displays by Connecting to NavNet Interface

• Add Network Sounder by Connecting to NavNet Interface

• MOB Key Stroke stores Vessel position and time

• Plotter Range Scales from 0.14 to 6,144 nautical miles

• 16 different mark symbols may be used

• Waypoint entry by L/L position or TD position or target Range and Bearing

• Plotter position interval may be set by Time or Distance Traveled

• TLL position from specific Furuno Radars or Echo sounders

• Full Functioning Infrared Remote Control

• Integral parallel tracking GPS/WAAS receiver

• Up to 900 knot tracking velocity

• 20 seconds for first position fix

• GPS position accuracy of approximately 10 meters, 95% of the time with S/A off

• WAAS position accuracy of approximately 3 meters, 95% of the time with S/A off

• 12 or 24 VDC

Compact in size, waterproof, yet big on power, features and performance, Furunos GP32 is perfect for a wide range of smaller fishing boats and pleasure craft.

This advanced unit, based on the popular GP31, provides accurate and reliable position fixing, thanks to a super sensitive, 12-channel GPS receiver combined with integrated WAAS technology.

The unit has a waterproof display and is built to stand up to tough marine conditions. This durable casing houses an impressive memory, capable of storing up to 1,000 points of ships track, 999 points for marks and waypoints, and 50 routes of up to 30 waypoints each. Vital navigation data is presented on a 4.5-inch diagonal Silver Bright LCD screen with adjustable brilliance. Innovative graphic displays include Nav, Highway, Steering, Track Plotting, and two operator programmable modes, all extremely easy to use.

The GP32, like all Furuno nav receivers, feature Furunos NMEA 0183 programmable interface system for feeding highly accurate nav data to your Furuno radar, chart plotter, autopilot or sounder. It even includes a dedicated RS-232 port for connection to a PC. And of course, it integrates perfectly with Furuno’s NavNet line of Radar/Chart Plotters.

Standard Features

• 12 Channel, Parallel Tracking GPS Receiver with WAAS technology, DGPS Ready

• Up to 900 Knot Tracking Velocity

• 20 Second Warm Start Acquisition

• 1-3M Accuracy (95% of the time with WAAS on and SA off)

• 4.5 Inch Diagonal Monochrome High Contrast Silver Bright LCD Screen

• Waypoint and Route Data Transfer Via PC to another GP32

• 5 Display Modes available

  1. Plotter - 14 Plot Scales from 0.2 - 320 N.M.

  2. NavData - Position Indication in Lat./Long or Loran-C TD’s

  3. Steering - Graphic Vessel Course, Position and Speed Information

  4. Highway - 8 Range Scales from 0.2 - 16 N.M.

  5. Analog or Digital Display Speedometer

  6. Two user customizable displays

• Man Overboard Key

• Waypoint entry by Loran-C TD’s (Highway Mode)

• Alarms for Arrival, XTE, Anchor Watch and High/Low Speed Points

• Memory Capacity: 1000 Points of Vessel Track, 999 Points for Waypoints and Marks, and 50 Routes comprised of up to 30 Waypoints

• Waypoint Comments of up to 16 Characters

• Event Marks Entered using one of Nine Symbols

• 2 Data Ports for both RS422 and RS232

• Feed nav data to radar, chart plotter, autopilot or sounder through NMEA0183 port

• Upload/Download waypoints and routes directly from NavNet display

• Built in Simulator for Showroom Display and Training

• 5Lbs., 1 Carton

• 12 or 24 VDC, 3 Watts

Compact in size, yet big on features and performance, the FURUNO GP33 is the perfect GPS navigator for a wide range of vessels. This advanced unit provides accurate and reliable position fixing, thanks to a super sensitive, 12-channel GPS receiver combined with integrated WAAS technology.

The GP33 displays navigation data in a wide variety of numerical and graphical formats. You may freely select which data you want displayed with easy to use controls. The combination of a high resolution screen and large data fields makes the screen easy to read in almost any condition.

The GP33 has a waterproof display and is built to stand up to tough marine conditions. The durable casing houses an impressive memory, capable of storing up to 3,000 points of ship’s track, 10,000 points for marks and waypoints, and 100 routes of up to 30 waypoints each. Vital navigation data is presented on a 4.3" color LCD.

The GP33 features FURUNO’s CAN bus interface system for feeding highly accurate navigation data to your NavNet 3D, radar, chart plotter, autopilot, fish finder or other navigation equipment. CAN bus is a communication protocol that shares multiple data and signals through a single backbone cable. You can simply connect any CAN bus devices onto the backbone cable to expand your network onboard. With CAN bus, IDs are assigned to all the devices, and the status of each sensor in the network can be detected. All the CAN bus devices can be incorporated into the NMEA2000 network, offering easy plug-and-play installation. NMEA0183 protocol versions are also supported.

Features:

• 4.3" "Sunlight Viewable" color LCD (Brightness: 700 cd)

• Enhanced data legibility thanks to large characters and high resolution visual aid

• Stores up to 10,000 marks/waypoints, 100 routes and 3,000 track points

• 7 display modes available, including 2 user-customized modes

• Supports both NMEA0183 and NMEA 2000 compatible CAN bus interface

• Contact closure capability available on the 10P connector

• SBAS capable for bet ter measurement

The enhanced PB150 Ultrasonic WeatherStation® Instrument features higher-accuracy temperature readings and improved wind speed and direction accuracy. WeatherCaster™ PC Software version 2.0 puts your own personal weatherman on-board the boat, 24 hours a day. The easy-to-use program has multiple screen views and advanced setup features to customize what you want to see. No Computer on board?no problem, just connect the PB150 to a NMEA 0183 display* for up-to-the-minute weather information.

Before Leaving the Dock?Decide if you want to spend your day on the water. Anticipate weather fronts by checking the wind speed and direction, temperature, and barometric pressure. Check the weather history graphs, as the WeatherCaster™ Software can store readings for up to 72 hours.

Underway?Monitor up-to-the-minute weather conditions at your location. See where and when the fish will bite best based on wind conditions and a rising or falling barometer.

Docking?The on-board PC or chart plotter can display true wind data to make docking a vessel in high wind a breeze.

By combining Furuno?s popular RD30 Nav Data Repeater with the PB150 Weather Station, you can now display important weather information in a large, easy-to-read format. As an added bonus, the PB150 has been fitted with an internal compass as well as a state-of-the-art Furuno GPS sensor, allowing you to utilize the PB150 as a backup GPS navigator.

Standard Features:

• True wind speed and direction

• Apparent wind speed and direction

• Barometric pressure

• Air temperature

• Wind chill temperature

• Measures wind speed and direction ultrasonically

• Wind calibration traceable to NIST

• Internal WAAS GPS

• Two-axis solid-state compass

• Three-axis accelerometer provides pitch and roll

• NMEA 0183 output

• WeatherCaster™ Software

• Very easy installation and two-year warranty

• Maintenance-free operation?no moving parts

• Recommended for recreational powerboats

GP330B

The GP-330B is a high performance GPS Receiver designed for any type of vessel. This compact and cost-effective receiver offers extremely accurate position fixes, within 3 meters with the WAAS mode activated.

The GP330B is capable of data output in NMEA2000 format, making it an ideal GPS sensor for use with NavNet 3D systems. The sensor comes with all of the hardware required for deck- or mast-mounting solutions. A 6-meter cable with NMEA2000 connector is supplied as standard.

Standard Features:

• High Accuracy, 14 Parallel Channel Receiver with Twelve Dedicated GPS Channels and Two Dedicated WAAS Channels

• NMEA2000 Certified GPS Antenna Sensor

• Fast Start Up (1 minute Cold Start Time-to-First-Fix)

• Position updated every second

• Unique "Pin-Enabled" Termination Resistor allows simple NMEA2000 Backbone or Drop Wiring configurations

• Space-saving installation

• Ideal position-fixing sensor for NavNet?3D series

• Direct connection to any Furuno DRS

• Low Power Consumption - 12VDC, 175mA (NMEA2000 LEN=3)

Keeping track of weather is easier than ever with Furuno’s BBWX2 Second-Generation Sirius Satellite Weather Receiver for NavNet vx2 and NavNet 3D! Furuno and Sirius have teamed up to bring you live, up-to-date weather information and forecasting to give you peace of mind, no matter when or how you are using your boat. The weather information is obtained from the weather industry’s leading experts and is delivered via digital receiver through Sirius Marine Weather services.

You have the ability to receive high-quality and comprehensive weather information and forecasting that you can overlay onto your C-Map MAX charts (NavNet vx2) or NOAA raster and vector charts (NavNet 3D). You will be provided with premium weather content, such as current weather reports, NOWRad®, nationwide high resolution weather radar imagery and high-resolution Sea Surface Temperature images that can help fishermen locate hot spots. Now you can have your weatherman with you 24/7 with your TRUE color Radar/Chart Plotter and Sirius Marine Weather!

Satellite weather receiver service is available for NavNet vx2 7", 10.4" and Black Box units (C-MAP versions only), as well as all NavNet 3D models. Requires Sirius weather service subscription, sold separately

FEATURES

• Works with all NavNet 3D MFD versions (MFD8, MFD12 and MFDBB)

• Works with all C-MAP by Jeppesen versions of NavNet vx2 (7", 10.4" and Black Box units)

• Up-to-the-minute weather forecasting at sea

• Satellite Sea Surface Temperatures

• Animated NOWRad® weather radar

• Pressure isobars and frontal boundaries

• Squall lines and surface pressure

• Wind forecasts using wind barbs or arrows

• Marine text forecasts

• Lightning strike reports & storm tracking

• Buoy reports

• Wave height forecasts

• Sirius Satellite Radio control (requires Sirius Satellite Radio subscription)

• Onboard 4-Port Ethernet Hub

• Antenna not included

The world of onboard navigation systems has evolved. Furunos dedication to deliver the best marine electronics has led to the most innovative, powerful solution for onboard navigation ever.
Furunos NavNet 3D is a groundbreaking new navigation system that breathes new life into the user interface. Once you start using NavNet 3D, you will be amazed at how a system so powerful can be so simple to use. NavNet 3D comes fully loaded with groundbreaking new features that will expand your navigational horizons.

NavNet 3D uses a cutting-edge technology weve named "Time Zero." Time Zero facilitates instant chart redraw, allowing for zooming in and out, changing chart display modes and other chart handling functions seamlessly and with no lag at all. Time Zero brings you a truly seamless navigation environment you have to experience to believe.

True 3D environment for a more instinctive chart presentation.
NavNet 3D incorporates a whole new dimension into chart presentation with Full Time 3D chart rendering. You can choose a 2D top-down view of the navigation chart for a look and feel that duplicates a traditional chart plotting presentation. Or, you can choose to pan and zoom the chart to any angle at any range scale you choose instantly. There is no 3D mode to change into and no waiting at all, because NavNet 3D operates in this 3D environment full time. This variety of chart presentations helps to improve your situational awareness by giving you unprecedented control over your charting environment.

NavNet 3Ds powerful new graphic engine brings new chart presentation options to the conventional 2D method of chart plotting. Satellite Photo Fusion is a powerful new tool, a hybrid blend of detailed satellite imagery and critical chart data. These new presentation options allow you to visually grasp your exact position in a way that was never before possible.

NavNet 3D incorporates native 3D chart architecture that allows for a full-time 3-dimensional presentation, as opposed to 2D charts that require special effects to appear 3D. There are no special modes; that limit your ability to navigate the way you want. With NavNet 3Ds true 3D environment, you can see all of the information you want with no limitations on what information you wish to view. Plan your routes and enter waypoints directly on your raster or vector native 3D charts. Radar overlay, Sirius Network Weather Receiver, AIS, plus all of your chart symbols and depth soundings; any and all of this information can be displayed at will. This is the beauty of navigating in true 3D. You have full control over the presentation all of the time.

Satellite Photo Fusion.
Satellite photography can be fused with raster or vector chart information. Land areas (zero depth) are completely opaque, so that these areas are displayed as satellite photos on the chart. As the depth increases, the satellite photography becomes more transparent so that you will know where the shallows end and the deeper water starts.

High resolution satellite photography aids in seabed classification so that you will be able to easily identify areas of sand, rock, coral or other obstructions.

Time Zero Technology Makes Chart Redraw A Thing Of The Past
High-speed processing and a powerful graphic engine deliver Time Zero technology instant, seamless chart handling with no lag or loading time. NavNet 3D Time Zero technology redefines the meaning of stress-free operation. Zoom seamlessly and continuously to whatever chart scale you desire. Instead of limiting you to a small handful of chart scales to choose from, Time Zero architecture allows you to zoom in or out to the exact magnification level you like without steps or limitations.

You can freely pan and scroll the chart by simply pressing the scroll pad. This gives you freedom to explore the chart data, allowing you to focus on a specific area ahead of or around your vessel without losing track of your position on the chart. Explore the chart data at your leisure, and then instantly return to your own ship at the touch of a single dedicated button.

FURUNO NavNet 3D Digital Solution sets a new standard.
NavNet 3D operates in a fully digital environment with its highly sensitive digital sensors for radar and fish finder. The operating structure is also digitized, delivering total fusion of hardware and software modules in its operating scheme.

NavNet 3D integrates Ultra High Definition (UHD) Digital Radar that facilitates fully automatic, high-precision Gain, Sea/Rain Clutter and Tuning control for hands-free operation and ultimate performance. UHD offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted appropriate to the pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite. One of the amazing features of Furuno UHD Digital Radar is Real Time dual range radar display, which scans and displays two different radar ranges with no lag at all. This greatly enhances your situational awareness.

You probably know about digital fish finders, but are not quite sure what the term really means. FURUNO Digital Filter fish finders feature advanced filtering capabilities and digital auto tuning which eliminate noise and deliver the ability to spot individual fish with clarity, accuracy and detail.

NavNet 3D ROTOKEY Puts a whole new spin in "User Friendly."
NavNet 3D challenges the conventional menu operating system with a whole new concept, the ROTOKEY on-screen revolving menu key. One turn of the Rotokey gives you instant access to full control of NavNet 3D. The Rotokey is designed as a part of NavNet 3Ds scaleable operating system; a short press of the Rotokey gives you access to a user-selected set of the basic functions that you will use the most, while a longer press of the key displays all of the functions available. Never leave your navigation screen to enter a menu again!

NavNet 3D provides the easiest user interface on the market with a combination of both Rotokey and familiar point-and-click cursor pad controls. The power of the point-and-click interface allows for incredibly simple operation click anywhere on the screen for context-sensitive options for that area. Click on any data box to access detailed information for that function. You can also connect a generic USB mouse to further simplify operation.

One press of the Disp button allows you to easily select the presentation you desire. Five intelligently designed hot-pages are available to you right out of the box, with the ability to save up to ten custom layouts.

The scrolling pad allows independent scrolling and panning capabilities from a dedicated omni-pad. Pan the chart and shift the radar without any screen redraw or lag. You can also control IP cameras without accessing complicated menus or changing your current presentation.

One long press of the 3D key will toggle the chart from 3D to a familiar 2D, top-down perspective. While the chart remains in its native 3D environment, only the perspective shifts there is no special mode required to shift back to 3D perspective.

Chart scaling without limitation

• Pre-loaded with NOAA raster chart library for entire U.S. coastline including Alaska and Hawaii

• TimeZero™ technology facilitates instant chart redraw, allowing zooming in and out, chart panning, changing chart display modes and other chart handling functions seamlessly and with no lag time

• Full Time 3D chart rendering. Choose a 2D top-down view of the navigation chart for a traditional chart plotting presentation, or choose to pan and zoom the chart to any angle at any range scale you choose

• Pan the chart using the scroll pad, and then instantly return to own ship at the touch of a single dedicated key

• Zoom seamlessly and continuously to whatever chart scale you desire - TimeZero™ architecture allows you to seamlessly zoom in or out to the exact magnification level you like without steps or limitations

• No "3D mode" to change into and no waiting - NavNet 3D operates in a 3D environment full-time

• Fuse satellite photography with raster or vector chart information. Land areas (zero depth) are completely opaque, so that these areas are displayed as high-resolution satellite photos on the chart. As the depth increases, the satellite photography becomes more transparent so that you will know where the shallows end and the deeper water starts, while allowing the raster or vector chart to be visible

• More than 12,000 ship’s track points and over 2,000 waypoints

• 200 planned routes, with up to 100 waypoints/route

• Preloaded tides & currents

• Engine monitoring

• Built-in ARPA processor can simultaneously acquire and track up to 30 targets (with appropriate sensor)

• AIS tracking when connected to AIS receiver

• True color depth shading utilizing bathymetric data

• Standard video input and outputs

• Extended Mode feature of Navnet 3D Black Box allows you to connect two monitors and synch the video, or ’split’ the two screens into eight different quarters to display the information you want to see most

• All the NavNet 3D radar sensors incorporate a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected exible installation of multiple NMEA 2000® sensors without the need to run cables to the main processor unit

• Power for NMEA2000 sensors supplied directly from the radar, allowing for flexible installation for multiple NMEA 2000® sensors without the need to run cables to the main processor unit

• NMEA 2000® data is converted and distributed throughout the NavNet 3D Ethernet network

• Simple operation with a combination of both RotoKey™ and a familiar point-and-click cursor pad control

• By turning a rotary knob on the control panel, RotoKey™ will be activated, giving you full access to NavNet 3D controls

• A short press of the RotoKey™ gives you access to a user-selected set of the functions that you select upon installation from Basic, Standard, Full or Custom, while a longer press of the key displays all of the functions available

• The power of the point-and-click interface allows for incredibly simple operation - click anywhere on the screen for context-sensitive options for that area. Click on any data box to access detailed information for that function. A variety of features can be accessed through a familiar left or right click interface

• Highly sensitive digital sensors for radar and fish finder, delivering total fusion of hardware and software

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing esentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls
• Optional Weatherfax/Navtex receiver available
• Control up to 4 AXIS IP cameras

The world of onboard navigation systems has evolved. Furunos dedication to deliver the best marine electronics has led to the most innovative, powerful solution for onboard navigation ever.
Furunos NavNet 3D is a groundbreaking new navigation system that breathes new life into the user interface. Once you start using NavNet 3D, you will be amazed at how a system so powerful can be so simple to use. NavNet 3D comes fully loaded with groundbreaking new features that will expand your navigational horizons.

NavNet 3D uses a cutting-edge technology weve named "Time Zero." Time Zero facilitates instant chart redraw, allowing for zooming in and out, changing chart display modes and other chart handling functions seamlessly and with no lag at all. Time Zero brings you a truly seamless navigation environment you have to experience to believe.

True 3D environment for a more instinctive chart presentation.
NavNet 3D incorporates a whole new dimension into chart presentation with Full Time 3D chart rendering. You can choose a 2D top-down view of the navigation chart for a look and feel that duplicates a traditional chart plotting presentation. Or, you can choose to pan and zoom the chart to any angle at any range scale you choose instantly. There is no 3D mode to change into and no waiting at all, because NavNet 3D operates in this 3D environment full time. This variety of chart presentations helps to improve your situational awareness by giving you unprecedented control over your charting environment.

NavNet 3Ds powerful new graphic engine brings new chart presentation options to the conventional 2D method of chart plotting. Satellite Photo Fusion is a powerful new tool, a hybrid blend of detailed satellite imagery and critical chart data. These new presentation options allow you to visually grasp your exact position in a way that was never before possible.

NavNet 3D incorporates native 3D chart architecture that allows for a full-time 3-dimensional presentation, as opposed to 2D charts that require special effects to appear 3D. There are no special modes; that limit your ability to navigate the way you want. With NavNet 3Ds true 3D environment, you can see all of the information you want with no limitations on what information you wish to view. Plan your routes and enter waypoints directly on your raster or vector native 3D charts. Radar overlay, Sirius Network Weather Receiver, AIS, plus all of your chart symbols and depth soundings; any and all of this information can be displayed at will. This is the beauty of navigating in true 3D. You have full control over the presentation all of the time.

Satellite Photo Fusion.
Satellite photography can be fused with raster or vector chart information. Land areas (zero depth) are completely opaque, so that these areas are displayed as satellite photos on the chart. As the depth increases, the satellite photography becomes more transparent so that you will know where the shallows end and the deeper water starts.

High resolution satellite photography aids in seabed classification so that you will be able to easily identify areas of sand, rock, coral or other obstructions.

Time Zero Technology Makes Chart Redraw A Thing Of The Past
High-speed processing and a powerful graphic engine deliver Time Zero technology instant, seamless chart handling with no lag or loading time. NavNet 3D Time Zero technology redefines the meaning of stress-free operation. Zoom seamlessly and continuously to whatever chart scale you desire. Instead of limiting you to a small handful of chart scales to choose from, Time Zero architecture allows you to zoom in or out to the exact magnification level you like without steps or limitations.

You can freely pan and scroll the chart by simply pressing the scroll pad. This gives you freedom to explore the chart data, allowing you to focus on a specific area ahead of or around your vessel without losing track of your position on the chart. Explore the chart data at your leisure, and then instantly return to your own ship at the touch of a single dedicated button.

FURUNO NavNet 3D Digital Solution sets a new standard.
NavNet 3D operates in a fully digital environment with its highly sensitive digital sensors for radar and fish finder. The operating structure is also digitized, delivering total fusion of hardware and software modules in its operating scheme.

NavNet 3D integrates Ultra High Definition (UHD) Digital Radar that facilitates fully automatic, high-precision Gain, Sea/Rain Clutter and Tuning control for hands-free operation and ultimate performance. UHD offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted appropriate to the pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite. One of the amazing features of Furuno UHD Digital Radar is Real Time dual range radar display, which scans and displays two different radar ranges with no lag at all. This greatly enhances your situational awareness.

You probably know about digital fish finders, but are not quite sure what the term really means. FURUNO Digital Filter fish finders feature advanced filtering capabilities and digital auto tuning which eliminate noise and deliver the ability to spot individual fish with clarity, accuracy and detail.

NavNet 3D ROTOKEY Puts a whole new spin in "User Friendly."
NavNet 3D challenges the conventional menu operating system with a whole new concept, the ROTOKEY on-screen revolving menu key. One turn of the Rotokey gives you instant access to full control of NavNet 3D. The Rotokey is designed as a part of NavNet 3Ds scaleable operating system; a short press of the Rotokey gives you access to a user-selected set of the basic functions that you will use the most, while a longer press of the key displays all of the functions available. Never leave your navigation screen to enter a menu again!

NavNet 3D provides the easiest user interface on the market with a combination of both Rotokey and familiar point-and-click cursor pad controls. The power of the point-and-click interface allows for incredibly simple operation click anywhere on the screen for context-sensitive options for that area. Click on any data box to access detailed information for that function. You can also connect a generic USB mouse to further simplify operation.

One press of the Disp button allows you to easily select the presentation you desire. Five intelligently designed hot-pages are available to you right out of the box, with the ability to save up to ten custom layouts.

The scrolling pad allows independent scrolling and panning capabilities from a dedicated omni-pad. Pan the chart and shift the radar without any screen redraw or lag. You can also control IP cameras without accessing complicated menus or changing your current presentation.

One long press of the 3D key will toggle the chart from 3D to a familiar 2D, top-down perspective. While the chart remains in its native 3D environment, only the perspective shifts there is no special mode required to shift back to 3D perspective.

Chart scaling without limitation

• Pre-loaded with NOAA raster chart library for entire U.S. coastline including Alaska and Hawaii

• TimeZero™ technology facilitates instant chart redraw, allowing zooming in and out, chart panning, changing chart display modes and other chart handling functions seamlessly and with no lag time

• Full Time 3D chart rendering. Choose a 2D top-down view of the navigation chart for a traditional chart plotting presentation, or choose to pan and zoom the chart to any angle at any range scale you choose

• Pan the chart using the scroll pad, and then instantly return to own ship at the touch of a single dedicated key

• Zoom seamlessly and continuously to whatever chart scale you desire - TimeZero™ architecture allows you to seamlessly zoom in or out to the exact magnification level you like without steps or limitations

• No "3D mode" to change into and no waiting - NavNet 3D operates in a 3D environment full-time

• Fuse satellite photography with raster or vector chart information. Land areas (zero depth) are completely opaque, so that these areas are displayed as high-resolution satellite photos on the chart. As the depth increases, the satellite photography becomes more transparent so that you will know where the shallows end and the deeper water starts, while allowing the raster or vector chart to be visible

• More than 12,000 ship’s track points and over 2,000 waypoints

• 200 planned routes, with up to 100 waypoints/route

• Preloaded tides & currents

• Engine monitoring

• Built-in ARPA processor can simultaneously acquire and track up to 30 targets (with appropriate sensor)

• AIS tracking when connected to AIS receiver

• True color depth shading utilizing bathymetric data

• Standard video input and outputs

• Extended Mode feature of Navnet 3D Black Box allows you to connect two monitors and synch the video, or ’split’ the two screens into eight different quarters to display the information you want to see most

• All the NavNet 3D radar sensors incorporate a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected

• Power for NMEA2000 sensors without the need to run cables to the main processor unit

• NMEA 2000® data is converted and distributed throughout the NavNet 3D Ethernet network

• Simple operation with a combination of both RotoKey™ and a familiar point-and-click cursor pad control

• By turning a rotary knob on the control panel, RotoKey™ will be activated, giving you full access to NavNet 3D controls

• A short press of the RotoKey™ gives you access to a user-selected set of the functions that you select upon installation from Basic, Standard, Full or Custom, while a longer press of the key displays all of the functions available ation - click anywhere on the screen for context-sensitive options for that area. Click on any data box to access detailed information for that function. A variety of features can be accessed through a familiar left or right click interface

• Connect a generic USB mouse to further simplify operation

• Highly sensitive digital sensors for radar and fish finder, delivering total fusion of hardware and software

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing esentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls
• Optional Weatherfax/Navtex receiver available
• Control up to 4 AXIS IP cameras

The world of onboard navigation systems has evolved. Furunos dedication to deliver the best marine electronics has led to the most innovative, powerful solution for onboard navigation ever.
Furunos NavNet 3D is a groundbreaking new navigation system that breathes new life into the user interface. Once you start using NavNet 3D, you will be amazed at how a system so powerful can be so simple to use. NavNet 3D comes fully loaded with groundbreaking new features that will expand your navigational horizons.

NavNet 3D uses a cutting-edge technology weve named "Time Zero." Time Zero facilitates instant chart redraw, allowing for zooming in and out, changing chart display modes and other chart handling functions seamlessly and with no lag at all. Time Zero brings you a truly seamless navigation environment you have to experience to believe.

True 3D environment for a more instinctive chart presentation.
NavNet 3D incorporates a whole new dimension into chart presentation with Full Time 3D chart rendering. You can choose a 2D top-down view of the navigation chart for a look and feel that duplicates a traditional chart plotting presentation. Or, you can choose to pan and zoom the chart to any angle at any range scale you choose instantly. There is no 3D mode to change into and no waiting at all, because NavNet 3D operates in this 3D environment full time. This variety of chart presentations helps to improve your situational awareness by giving you unprecedented control over your charting environment.

NavNet 3Ds powerful new graphic engine brings new chart presentation options to the conventional 2D method of chart plotting. Satellite Photo Fusion is a powerful new tool, a hybrid blend of detailed satellite imagery and critical chart data. These new presentation options allow you to visually grasp your exact position in a way that was never before possible.

NavNet 3D incorporates native 3D chart architecture that allows for a full-time 3-dimensional presentation, as opposed to 2D charts that require special effects to appear 3D. There are no special modes; that limit your ability to navigate the way you want. With NavNet 3Ds true 3D environment, you can see all of the information you want with no limitations on what information you wish to view. Plan your routes and enter waypoints directly on your raster or vector native 3D charts. Radar overlay, Sirius Network Weather Receiver, AIS, plus all of your chart symbols and depth soundings; any and all of this information can be displayed at will. This is the beauty of navigating in true 3D. You have full control over the presentation all of the time.

Satellite Photo Fusion.
Satellite photography can be fused with raster or vector chart information. Land areas (zero depth) are completely opaque, so that these areas are displayed as satellite photos on the chart. As the depth increases, the satellite photography becomes more transparent so that you will know where the shallows end and the deeper water starts.

High resolution satellite photography aids in seabed classification so that you will be able to easily identify areas of sand, rock, coral or other obstructions.

Time Zero Technology Makes Chart Redraw A Thing Of The Past
High-speed processing and a powerful graphic engine deliver Time Zero technology instant, seamless chart handling with no lag or loading time. NavNet 3D Time Zero technology redefines the meaning of stress-free operation. Zoom seamlessly and continuously to whatever chart scale you desire. Instead of limiting you to a small handful of chart scales to choose from, Time Zero architecture allows you to zoom in or out to the exact magnification level you like without steps or limitations.

You can freely pan and scroll the chart by simply pressing the scroll pad. This gives you freedom to explore the chart data, allowing you to focus on a specific area ahead of or around your vessel without losing track of your position on the chart. Explore the chart data at your leisure, and then instantly return to your own ship at the touch of a single dedicated button.

FURUNO NavNet 3D Digital Solution sets a new standard.
NavNet 3D operates in a fully digital environment with its highly sensitive digital sensors for radar and fish finder. The operating structure is also digitized, delivering total fusion of hardware and software modules in its operating scheme.

NavNet 3D integrates Ultra High Definition (UHD) Digital Radar that facilitates fully automatic, high-precision Gain, Sea/Rain Clutter and Tuning control for hands-free operation and ultimate performance. UHD offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted appropriate to the pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite. One of the amazing features of Furuno UHD Digital Radar is Real Time dual range radar display, which scans and displays two different radar ranges with no lag at all. This greatly enhances your situational awareness.

You probably know about digital fish finders, but are not quite sure what the term really means. FURUNO Digital Filter fish finders feature advanced filtering capabilities and digital auto tuning which eliminate noise and deliver the ability to spot individual fish with clarity, accuracy and detail.

NavNet 3D ROTOKEY Puts a whole new spin in "User Friendly."
NavNet 3D challenges the conventional menu operating system with a whole new concept, the ROTOKEY on-screen revolving menu key. One turn of the Rotokey gives you instant access to full control of NavNet 3D. The Rotokey is designed as a part of NavNet 3Ds scaleable operating system; a short press of the Rotokey gives you access to a user-selected set of the basic functions that you will use the most, while a longer press of the key displays all of the functions available. Never leave your navigation screen to enter a menu again!

NavNet 3D provides the easiest user interface on the market with a combination of both Rotokey and familiar point-and-click cursor pad controls. The power of the point-and-click interface allows for incredibly simple operation click anywhere on the screen for context-sensitive options for that area. Click on any data box to access detailed information for that function. You can also connect a generic USB mouse to further simplify operation.

One press of the Disp button allows you to easily select the presentation you desire. Five intelligently designed hot-pages are available to you right out of the box, with the ability to save up to ten custom layouts.

The scrolling pad allows independent scrolling and panning capabilities from a dedicated omni-pad. Pan the chart and shift the radar without any screen redraw or lag. You can also control IP cameras without accessing complicated menus or changing your current presentation.

One long press of the 3D key will toggle the chart from 3D to a familiar 2D, top-down perspective. While the chart remains in its native 3D environment, only the perspective shifts there is no special mode required to shift back to 3D perspective.

Chart scaling without limitation

• Pre-loaded with NOAA raster chart library for entire U.S. coastline including Alaska and Hawaii

• TimeZero™ technology facilitates instant chart redraw, allowing zooming in and out, chart panning, changing chart display modes and other chart handling functions seamlessly and with no lag time

• Full Time 3D chart rendering. Choose a 2D top-down view of the navigation chart for a traditional chart plotting presentation, or choose to pan and zoom the chart to any angle at any range scale you choose

• Pan the chart using the scroll pad, and then instantly return to own ship at the touch of a single dedicated key

• Zoom seamlessly and continuously to whatever chart scale you desire - TimeZero™ architecture allows you to seamlessly zoom in or out to the exact magnification level you like without steps or limitations

• No "3D mode" to change into and no waiting - NavNet 3D operates in a 3D environment full-time

• Fuse satellite photography with raster or vector chart information. Land areas (zero depth) are completely opaque, so that these areas are displayed as high-resolution satellite photos on the chart. As the depth increases, the satellite photography becomes more transparent so that you will know where the shallows end and the deeper water starts, while allowing the raster or vector chart to be visible

• More than 12,000 ship’s track points and over 2,000 waypoints

• 200 planned routes, with up to 100 waypoints/route

• Preloaded tides & currents

• Engine monitoring

• Built-in ARPA processor can simultaneously acquire and track up to 30 targets (with appropriate sensor)

• AIS tracking when connected to AIS receiver

• True color depth shading utilizing bathymetric data

• Standard video input and outputs

• Extended Mode feature of Navnet 3D Black Box allows you to connect two monitors and synch the video, or ’split’ the two screens into eight different quarters to display the information you want to see most

• All the NavNet 3D radar sensors incorporate a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected

• Power for NMEA2000 sensors supplied directly from the radar, allowing for flexible installation of multiple NMEA 2000® sensors without the need to run cables to the main processor unit

• NMEA 2000® data is converted and distributed throughout the NavNet 3D Ethernet network

• Simple operation with a combination of both RotoKey™ and a familiar point-and-click cursor pad control

• By turning a rotary knob on the control panel, RotoKey™ will be activated, giving you full access to NavNet 3D controls

• A short press of the RotoKey™ gives you access to a user-selected set of the functions that you select upon installation from Basic, Standard, Full or Custom, while a longer press of the key displays all of the functions available

• The power of the point-and-click interface allows for incredibly simple operation - click anywhere on the screen for context-sensitive options for that area. Click on any data box to access detailed information for that function. A variety of features can be accessed through a familiar left or right click interface

• Highly sensitive digital sensors for radar and fish finder, delivering total fusion of hardware and software

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing esentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls
• Optional Weatherfax/Navtex receiver available
• Control up to 4 AXIS IP cameras

MU150HD

The FURUNO MU150HD is a multi-purpose marine LCD that features the unmatched quality and reliability that you have learned to depend on. The MU150HD employs an extremely bright (1,000 cd/m2 ) color TFT LCD with special AR (anti-reflective) glass filter to cut down on annoying glare. With its bright colors, excellent contrast and wide viewing angles, the MU150HD monitor is perfect for any tropical sunlight or low light conditions. Furthermore, the LCDs and the glass are bonded together ensure fog free operation on open fly-bridge installations.

The MU150HD features XGA (1024 x 768) screen resolution, with a built-in scaler to accept resolution up to SXGA (1280 x 1024). It’s wide range of interface options include: 1 RGB analog, 2 DVI (Digital Video Interface) and 3 NTSC/PAL video inputs. The display may be used as either the main or remote display for a variety of marine equipment, such as Black Box Radar, Sounder, Sonar, or NavNet series. The unit can also display images from security cameras, DVD player, computers, or other peripheral devices.

Features:

The FURUNO MU190HD is a multi-purpose marine LCD that features the unmatched quality and reliability that you have learned to depend on. The MU190HD employs an extremely bright (1,000 cd/m2 ) color TFT LCD with special AR (anti-reflective) glass filter to cut down on annoying glare. With its bright colors, excellent contrast and wide viewing angles, the MU190HD monitor is perfect for any tropical sunlight or low light conditions. Furthermore, the LCDs and the glass are bonded together ensure fog free operation on open fly-bridge installations.

The MU-190HD features SXGA (1280 x 1024) screen resolution and a wide range of interface options available that include: 1 RGB analog, 2 DVI (Digital Video Interface) and 3 NTSC/PAL video inputs. The display may be used as either the main or remote display for a variety of marine equipment, such as Black Box Radar, Sounder, Sonar, or NavNet series. The unit can also display images from security cameras, DVD player, computers, or other peripheral video devices.

Standard Features:

• Crystal clear 19" marine grade monitor for use as main or remote display

• 1280 x 1024 SXGA Screen Resolution

• 1,000 cd/m2 brightness and A/R coating provides superior visibility even in direct sunlight

• Bonded LCD provides clear view in any weather conditions

• Automatic dimmer sensor adjusts the display brightness as light conditions change

• 1 RGB analog, 2 DVI (Digital Video Interface) and 3 NTSC/PAL interfaces available

• Any of the three NTSC inputs are PIP (Picture-In-Picture) capable, with adjustable size and screen location

• Table top/Ceiling or Flush Mount (Table Top/Ceiling mounting bracket is optional)

• Customizable input names for easy on-the-fly identification and switching between onboard Radar, Sonar, Sounder, Camera, etc.

• Automatic signal recognition and scaling for easy setup and installation

The MODEL 1715 is a high contrast LCD radar designed for pleasure craft and small fishing boats. Radar echoes are presented in four shades of gray on the 7" Silver Bright LCD. The Radar offers detailed pictures of coastline and targets at short ranges thanks to narrower pulse lengths and dual IF bandwidths. The antenna rotation speed automatically changes depending on the range selection for optimum target detection. The compact, waterproof display allows tabletop or panel mounting in the cockpit or on the open fly bridge.

The radar has a power saving Watchman mode. In this mode, the antenna is stopped and the transmission is off, while the screen displays nav data only. The radar wakes up at a specified time interval (5, 10 or 20 min) and operates for a minute. If a target enters the Guard Zone, an audible alarm sounds and the radar goes into its normal operating mode, canceling the Watchman mode. The alarm may also be set to work for a target leaving the Zone.

Other standard features include: EBL (Electronic Bearing Line), VRM (Variable Range Marker), TLL output (Target L/L), Cursor L/L readout, Echo Trail, Guard Zone Alarm, Anti Clutter Rain, Automatic control of tuning and sensitivity. The A/C RAIN control improves the target detection in the rain by elaborate design of the receiver.

With use of nav data inputs in NMEA 0183 format, the radar offers additional functions. Graphical and numeric waypoint information can be shown on the display. The Waypoint is indicated by a lollipop mark for easy identification on the radar display. In the TLL output function, you can use the cursor to output a specified target’s L/L to the optional GPS navigator as a mark.



Includes 10M Standard Signal Cable


Standard Features:

• High Contrast 7" Silver Bright LCD for excellent sunlight view ability

• 14 range scales from 0.125 to 24 nm

• Low power consumption in Watchman mode - only 8 W

• Dual bandwidth IF amplifier: broad band for high fidelity in short ranges, narrow band for enhanced detection in long ranges

• Variable antenna speeds with range scales for optimum performance on all ranges

• Cursor position can be read in L/L (GPS Navigator is required)

• Waypoint Lollipop On-Screen to aid in Vessel Navigation (GPS Navigator is required)

• Programmable Navigation Data repeater feature

• Zoom in to a specific area

• Reverse video feature for effective use at night

• Guard Zone Alarm

• 12 to 24 VDC, 38 W (max), 8 W (in Watchman mode)

• 115/230 VAC with optional rectifier PR-62

• 29 lbs, 1 Carton

• 13"x 21"x 28"

Small in size, the 1623 is big on power, clarity and advanced radar features. The slim-line monochrome LCD display and lightweight radome antenna make it ideal for power or sail boats as small as 17 feet.

This 2.2kW radar has a 16 nautical mile range, yet will zoom down to 1/8 nautical mile for tight navigation in harbors and inlets. The 1623 radar lets you readily identify objects, thanks to a high definition 6" Silver Bright LCD screen that clearly separates targets. Plus, the four-tone target display lets you easily differentiate between stronger and weaker echoes, helping to alert you of any danger.

Includes 10M Standard Signal Cable

Standard Features

• Waterproof, 6 Inch Silver Bright Monochrome LCD Display

• 13 User Selectable Range Scales from 1/8 to 16 N.M.

• Ergonomic design with predictable menu

• Display Resolution of 240(H) X 320(V) Dots

• Targets Displayed in up to 4 Levels of Gray Tones

• 2.2 Kilowatt Transmitter Unit

• New Tri-speed 15" radome antenna, increases RPM at short ranges for better target accuracy

• 3 Transmitter Pulse lengths and Repetition Rates

• Linear Receiver with 10 dB Noise Figure

• Automatic Receiver Tuning

• Automatic or Manual Sea-Clutter (STC) Adjustment

• Automatic or Manual Receiver Gain Adjustment

• Sector Blanking

• Rain Clutter (FTC) Control

• Echo Stretch and Interference Rejection Modes

• Watchman Mode to control the Radar system for Vessel Safety

• Reverse Video Display (White Targets and Marks on a Black Background)

• Full Screen Navigation Data Display in the Standby Mode*

• Omni Pad Control for rapid Cursor and Menu Operation

• Picture Off-Center Shift

• Electronic Bearing Line and Variable Range Marker

• Target or Echo Trails with Selectable Time Intervals

• Waypoint Lollipop On-Screen to aid in Vessel Navigation*

• Adjustable Duplex (In or Out) Radar Guard Zone Alarm

• TLL (Target Lat/Lon) output for use with plotter (must accept TLL sentence info)*

• Time offset adjustment

• [PROG] key provides menu shortcuts

• User programmable Nav Data Screens

• Ability to connect BBWGPS GPS/WAAS receiver

• Wind indication with appropriate sensor input

• 24 lbs., 1 Carton

• 12 or 24 VDC Only, 36 Watts

• Approximately 8 Watts, in Standby/Watchman Mode

• * Appropriate Nav Data Input Required.

The MODEL 1715 is a high contrast LCD radar designed for pleasure craft and small fishing boats. Radar echoes are presented in four shades of gray on the 7" Silver Bright LCD. The Radar offers detailed pictures of coastline and targets at short ranges thanks to narrower pulselengths and dual IF bandwidths. The antenna rotation speed automatically changes depending on the range selection for optimum target detection. The compact, waterproof display allows table top or panel mounting in the cockpit or on the open fly bridge.

The radar has a power saving Watchman mode. In this mode, the antenna is stopped and the transmission is off, while the screen displays nav data only. The radar wakes up at a specified time interval (5, 10 or 20 min) and operates for a minute. If a target enters the Guard Zone, an audible alarm sounds and the radar goes into its normal operating mode, canceling the Watchman mode. The alarm may also be set to work for a target leaving the =Zone.

Other standard features include: EBL (Electronic Bearing Line), VRM (Variable Range Marker), TLL output (Target L/L), Cursor L/L readout, Echo =Trail, Guard Zone Alarm, Anti Clutter Rain, Automatic control of tuning and sensitivity. The A/C RAIN control improves the target detection in the rain =by elaborate design of the receiver.

With use of nav data inputs in NMEA 0183 format, the radar offers additional functions. Graphical and numeric waypoint information can be shown on the display. The Waypoint is indicated by a lollipop mark for easy identification on the radar display. In the TLL output function, you can use the cursor to output a specified target’s L/L to the optional GPS navigator as a mark.



Includes 15M Standard Signal Cable
Standard Features:

• High Contrast 7" Silver Bright LCD for excellent sunlight view ability

• 14 range scales from 0.125 to 24 nm

• Low power consumption in Watchman mode - only 8 W

• Dual bandwidth IF amplifier: broad band for high fidelity in short ranges, narrow band for enhanced detection in long ranges

• Variable antenna speeds with range scales for optimum performance on all ranges

• Cursor position can be read in L/L (GPS Navigator is required)

• Waypoint Lollipop On-Screen to aid in Vessel Navigation (GPS Navigator is required)

• Programmable Navigation Data repeater feature

• Zoom in to a specific area

• Reverse video feature for effective use at night

• Guard Zone Alarm

• 12 to 24 VDC, 38 W (max), 8 W (in Watchman mode)

• 115/230 VAC with optional rectifier PR-62

• 29 lbs, 1 Carton

• 13"x 21"x 28"

Since its release back in 2001, FURUNO’s NavNet series has been enjoying unrivalled popularity worldwide for its high reliability, performance and expandability. It has even been voted Best Integrated Navigation System by the National Marine Electronics Association for three consecutive years. Now, NavNet vx2 is ready to carry on the tradition.

NavNet vx2 combines radar, GPS/WAAS chart plotter, fish finder, and network weather facsimile into an all-round navigation network. Its wide range of options fulfils virtually every desire you may have for navigation system.

Radar, GPS, Network fish finder, Network weather facsimile - a multistation integrated navigation network, NavNet vx2 lets you build your navigation system according to your needs. Utilizing state-of-the-art network technology, NavNet vx2 provides you with seamless data sharing and vast future expandability.

The heart of NavNet vx2 is its Ethernet-based network. Up to four displays, together with various navigational sensors, can be interconnected in addition to new MaxSea-NavNet navigational software, which adds even more features to your NavNet vx2 network. Stress-free navigation can be performed from any display unit connected to the onboard network, due to the high-speed transfer of data available.

• All display units are capable of controlling any component connected to the NavNet network

• Perfect for single or multi display installations

• Fully supports C-Map NT MAX charts

• Utilizes SD cards for chart and memory

• Fast chart drawing speed

• Straightforward Plug n Play installation with wizard style set-up

• AR-coated, high-brightness display unit for improved sunlight viewability


• Sunlight Viewable 10.4" Color VGA (640 x 480) TFT LCD Display

• AR-coated, high-brightness display unit for improved sunlight viewability.

• Automatic GST (Gain, Sea Clutter, Tuning) Receiver

• Target or Echo Trails with Selectable Time Intervals

• Commercially popular SD chart/memory card format

• Full compatibility with C-Map NT MAX charts

• Enhanced graphics with 256 color full VGA presentations

• Improved screen redraw, scroll refresh, and memory cache

• New Quick Point L/L direct entry waypoint

• 100 target AIS display with I/F module and external AIS Rx

• Simplified installation with new Network Wizard set-up

• Adjustable (In or Out) Radar Guard Zone Alarm

• Picture Off-Centering or Target Zoom Mode

• Cursor L/L Position Display **

• Watchman Mode activates the Radar for Safety and Security

• On-Screen Display of Vessel Position, Heading, etc. *

• Waypoint Lollipop On-Screen, to simplify Navigation * or **

• Full Functioning Infrared Remote Control

• Radar Overlay available with appropriate heading sensor (i.e. PG500R)

• Vessel Position Display in L/L or Loran-C TD’s

• North-Up, Course-Up or Automatic Course-Up display modes

• Plotter, Nav Data, Steering Director or Highway display modes

• Up to 8,000 points for ship’s track and marks, 999 waypoints, 35 quick points, 1 MOB, 200

• planned routes (max. 35 waypoints/route) and 1 quick route

• Add Multiple Displays by Connecting to NavNet Interface

• Add Network Sounder by Connecting to NavNet Interface
  Power Requirements:


  • 12 or 24 VDC

Since its release back in 2001, FURUNOs NavNet series has been enjoying unrivalled popularity worldwide for its high reliability, performance and expandability. It has even been voted Best Integrated Navigation System by the National Marine Electronics Association for three consecutive years. Now, NavNet vx2 is ready to carry on the tradition.

NavNet vx2 combines radar, GPS/WAAS chart plotter, fish finder, and network weather facsimile into an all-round navigation network. Its wide range of options fulfills virtually every desire you may have for navigation system.

Radar, GPS, Network fish finder, Network weather facsimile - a multistation integrated navigation network, NavNet vx2 lets you build your navigation system according to your needs. Utilizing state-of-the-art network technology, NavNet vx2 provides you with seamless data sharing and vast future expandability.

The heart of NavNet vx2 is its Ethernet-based network. Up to four displays, together with various navigational sensors, can be interconnected in addition to new MaxSea-NavNet navigational software, which adds even more features to your NavNet vx2 network. Stress-free navigation can be performed from any display unit connected to the onboard network, due to the high-speed transfer of data available.

• All display units are capable of controlling any component connected to the NavNet network

• Perfect for single or multi display installations

• Fully supports C-Map NT MAX charts

• Utilizes SD cards for chart and memory

• Fast chart drawing speed

• Straightforward Plug n Play installation with wizard style set-up

• AR-coated, high-brightness display unit for improved sunlight viewability


• Sunlight Viewable 10.4" Color VGA (640 x 480) TFT LCD Display

• AR-coated, high-brightness display unit for improved sunlight viewability.

• Automatic GST (Gain, Sea Clutter, Tuning) Receiver

• Target or Echo Trails with Selectable Time Intervals

• Commercially popular SD chart/memory card format

• Full compatibility with C-Map NT MAX charts

• Enhanced graphics with 256 color full VGA presentations

• Improved screen redraw, scroll refresh, and memory cache

• New Quick Point L/L direct entry waypoint

• 100 target AIS display with I/F module and external AIS Rx

• Simplified installation with new Network Wizard set-up

• Adjustable (In or Out) Radar Guard Zone Alarm

• Picture Off-Centering or Target Zoom Mode

• Cursor L/L Position Display **

• Watchman Mode activates the Radar for Safety and Security

• On-Screen Display of Vessel Position, Heading, etc. *

• Waypoint Lollipop On-Screen, to simplify Navigation * or **

• Full Functioning Infrared Remote Control

• Radar Overlay available with appropriate heading sensor (i.e. PG500R)

• Vessel Position Display in L/L or Loran-C TD’s

• North-Up, Course-Up or Automatic Course-Up display modes

• Plotter, Nav Data, Steering Director or Highway display modes

• Up to 8,000 points for ship’s track and marks, 999 waypoints, 35 quick points, 1 MOB, 200

• planned routes (max. 35 waypoints/route) and 1 quick route

• Add Multiple Displays by Connecting to NavNet Interface

• Add Network Sounder by Connecting to NavNet Interface
  Power Requirements:


  • 12 or 24 VDC

Since its release back in 2001, FURUNOs NavNet series has been enjoying unrivalled popularity worldwide for its high reliability, performance and expandability. It has even been voted Best Integrated Navigation System by the National Marine Electronics Association for three consecutive years. Now, NavNet vx2 is ready to carry on the tradition.

NavNet vx2 combines radar, GPS/WAAS chart plotter, fish finder, and network weather facsimile into an all-round navigation network. Its wide range of options fulfils virtually every desire you may have for navigation system.

Radar, GPS, Network fish finder, Network weather facsimile - a multistation integrated navigation network, NavNet vx2 lets you build your navigation system according to your needs. Utilizing state-of-the-art network technology, NavNet vx2 provides you with seamless data sharing and vast future expandability.

The heart of NavNet vx2 is its Ethernet-based network. Up to four displays, together with various navigational sensors, can be interconnected in addition to new MaxSea-NavNet navigational software, which adds even more features to your NavNet vx2 network. Stress-free navigation can be performed from any display unit connected to the onboard network, due to the high-speed transfer of data available.

• All display units are capable of controlling any component connected to the NavNet network

• Perfect for single or multi display installations

• Fully supports C-Map NT MAX charts

• Utilizes SD cards for chart and memory

• Fast chart drawing speed

• Straightforward Plug n Play installation with wizard style set-up

• AR-coated, high-brightness display unit for improved sunlight viewability


• Sunlight Viewable 10.4" Color VGA (640 x 480) TFT LCD Display

• AR-coated, high-brightness display unit for improved sunlight viewability.

• Automatic GST (Gain, Sea Clutter, Tuning) Receiver

• Target or Echo Trails with Selectable Time Intervals

• Commercially popular SD chart/memory card format

• Full compatibility with C-Map NT MAX charts

• Enhanced graphics with 256 color full VGA presentations

• Improved screen redraw, scroll refresh, and memory cache

• New Quick Point L/L direct entry waypoint

• 100 target AIS display with I/F module and external AIS Rx

• Simplified installation with new Network Wizard set-up

• Adjustable (In or Out) Radar Guard Zone Alarm

• Picture Off-Centering or Target Zoom Mode

• Cursor L/L Position Display **

• Watchman Mode activates the Radar for Safety and Security

• On-Screen Display of Vessel Position, Heading, etc. *

• Waypoint Lollipop On-Screen, to simplify Navigation * or **

• Full Functioning Infrared Remote Control

• Radar Overlay available with appropriate heading sensor (i.e. PG500R)

• Vessel Position Display in L/L or Loran-C TD’s

• North-Up, Course-Up or Automatic Course-Up display modes

• Plotter, Nav Data, Steering Director or Highway display modes

• Up to 8,000 points for ship’s track and marks, 999 waypoints, 35 quick points, 1 MOB, 200

• Planned routes (max. 35 waypoints/route) and 1 quick route

• Add Multiple Displays by Connecting to NavNet Interface

• Add Network Sounder by Connecting to NavNet Interface



  Power Requirements:



  • 12 or 24 VDC

Since its release back in 2001, FURUNOs NavNet series has been enjoying unrivalled popularity worldwide for its high reliability, performance and expandability. It has even been voted Best Integrated Navigation System by the National Marine Electronics Association for three consecutive years. Now, NavNet vx2 is ready to carry on the tradition.

NavNet vx2 combines radar, GPS/WAAS chart plotter, fish finder, and network weather facsimile into an all-round navigation network. Its wide range of options fulfils virtually every desire you may have for navigation system.

Radar, GPS, Network fish finder, Network weather facsimile - a multistation integrated navigation network, NavNet vx2 lets you build your navigation system according to your needs. Utilizing state-of-the-art network technology, NavNet vx2 provides you with seamless data sharing and vast future expandability.

The heart of NavNet vx2 is its Ethernet-based network. Up to four displays, together with various navigational sensors, can be interconnected in addition to new MaxSea-NavNet navigational software, which adds even more features to your NavNet vx2 network. Stress-free navigation can be performed from any display unit connected to the onboard network, due to the high-speed transfer of data available.

• All display units are capable of controlling any component connected to the NavNet network

• Perfect for single or multi display installations

• Fully supports C-Map NT MAX charts

• Utilizes SD cards for chart and memory

• Fast chart drawing speed

• Straightforward Plug n Play installation with wizard style set-up

• AR-coated, high-brightness display unit for improved sunlight viewability


• Sunlight Viewable 10.4" Color VGA (640 x 480) TFT LCD Display

• AR-coated, high-brightness display unit for improved sunlight viewability.

• Automatic GST (Gain, Sea Clutter, Tuning) Receiver

• Target or Echo Trails with Selectable Time Intervals

• Commercially popular SD chart/memory card format

• Full compatibility with C-Map NT MAX charts

• Enhanced graphics with 256 color full VGA presentations

• Improved screen redraw, scroll refresh, and memory cache

• New Quick Point L/L direct entry waypoint

• 100 target AIS display with I/F module and external AIS Rx

• Simplified installation with new Network Wizard set-up

• Adjustable (In or Out) Radar Guard Zone Alarm

• Picture Off-Centering or Target Zoom Mode

• Cursor L/L Position Display **

• Watchman Mode activates the Radar for Safety and Security

• On-Screen Display of Vessel Position, Heading, etc. *

• Waypoint Lollipop On-Screen, to simplify Navigation * or **

• Full Functioning Infrared Remote Control

• Radar Overlay available with appropriate heading sensor (i.e. PG500R)

• Vessel Position Display in L/L or Loran-C TD’s

• North-Up, Course-Up or Automatic Course-Up display modes

• Plotter, Nav Data, Steering Director or Highway display modes

• Up to 8,000 points for ship’s track and marks, 999 waypoints, 35 quick points, 1 MOB, 200

• planned routes (max. 35 waypoints/route) and 1 quick route

• Add Multiple Displays by Connecting to NavNet Interface

• Add Network Sounder by Connecting to NavNet Interface


  Power Requirements:





  • 12 or 24 VDC





Ultra High Definition (UHD™) Digital Radar


FURUNO has taken its NMEA award-winning radar technology to the next level with Ultra High Definition Digital Radar. UHD™ offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite.

The DRS2D incorporates a 2.2kW T/R within a sleek 19" radome.

Standard Features:

• 2.2kW, 24 n.m. Radar Antenna for NavNet 3D in a sleek, stylish 19" Radome

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing

• Real-time digital auto Gain/Sea/Rain controls to deliver noise-free radar presentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls

• Radome incorporates a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected. Power for these networked sensors is supplied directly from the radome itself, allowing for flexible installation of multiple NMEA 2000® sensors without the need to run cables all the way to the main processor unit

Ultra High Definition (UHD™) Digital Radar


FURUNO has taken its NMEA award-winning radar technology to the next level with Ultra High Definition Digital Radar. UHD™ offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite.

The DRS4D incorporates a 4kW T/R within a sleek 24" radome.

Standard Features:

• 4kW, 36 n.m. Radar Antenna for NavNet 3D in a stylish 24" Radome

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing

• Real-time digital auto Gain/Sea/Rain controls to deliver noise-free radar presentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls

• Radome incorporates a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected. Power for these networked sensors is supplied directly from the radome itself, allowing for flexible installation of multiple NMEA 2000® sensors without the need to run cables all the way to the main processor unit

Ultra High Definition (UHD™) Digital Radar

FURUNO has taken its NMEA award-winning radar technology to the next level with Ultra High Definition Digital Radar. UHD™ offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite.

The DRS4A incorporates a 4kW T/R and 3.5’ Open Array antenna

Standard Features:

• PSU012 Power Supply Unit is required option for use with MFD8 display when used with 6kw or 12kw open array radars

• 4kW, 48 n.m. Radar Antenna for NavNet 3D with a stylish 3.5’ Open Array

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing

• Real-time digital auto Gain/Sea/Rain controls to deliver noise-free radar presentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls

• Gearbox incorporates a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected. Power for these networked sensors is supplied directly from the gearbox itself, allowing for flexible installation of multiple NMEA 2000® sensors without the need to run cables all the way to the main processor unit

Ultra High Definition (UHD™) Digital Radar

FURUNO has taken its NMEA award-winning radar technology to the next level with Ultra High Definition Digital Radar. UHD™ offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite.

The DRS6A incorporates a 6kW T/R and 4’ Open Array antenna.

Standard Features:

• PSU012 Power Supply Unit is required option for use with MFD8

• 6kW, 64 n.m. Radar Antenna for NavNet 3D with a stylish 4’ Open Array

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing

• Real-time digital auto Gain/Sea/Rain controls to deliver noise-free radar presentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls

• Gearbox incorporates a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected. Power for these networked sensors is supplied directly from the gearbox itself, allowing for flexible installation of multiple NMEA 2000® sensors without the need to run cables all the way to the main processor unit

Ultra High Definition (UHD™) Digital Radar

FURUNO has taken its NMEA award-winning radar technology to the next level with Ultra High Definition Digital Radar. UHD™ offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite.

The DRS12A incorporates a 12kW T/R and either 4’ or 6’ Open Array antenna.

Standard Features:

• PSU012 Power Supply Unit is required option for use with MFD8 or MFD12

• 12kW, 72 n.m. Radar Antenna for NavNet 3D with choice of stylish 4’ or 6’ Open Array

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing

• Real-time digital auto Gain/Sea/Rain controls to deliver noise-free radar presentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls

• Gearbox incorporates a NMEA 2000® port to which certain NMEA2000® sensors can be directly connected. Power for these networked sensors is supplied directly from the gearbox itself, allowing for flexible installation of multiple NMEA 2000® sensors without the need to run cables all the way to the main processor unit

Ultra High Definition (UHD™) Digital Radar

FURUNO has taken its NMEA award-winning radar technology to the next level with Ultra High Definition Digital Radar. UHD™ offers crystal clear, noise-free target presentation with automatic real-time digital signal processing. Antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length. Commercial-grade radar performance is now available in the ultimate MFD navigation suite.

The DRS25A incorporates a 25kW T/R and either 4’ or 6’ Open Array antenna, and includes the PSU0013 Power Supply Unit as standard supply.

Standard Features:

• PSU013 Power Supply Unit included as standard supply

• 25kW, 72 n.m. Radar Antenna for NavNet 3D with choice of stylish 4’ or 6’ Open Array

• Ultra High Definition (UHD™) Digital Radar offers crystal clear, noise-free target presentation with automatic real-time digital signal processing

• Real-time digital auto Gain/Sea/Rain controls to deliver noise-free radar presentation

• Radar antenna rotation speed (24/36/48 rpm) is automatically shifted to the appropriate pulse length

• Simultaneous scanning technology drives our powerful dual-range radar, providing unsurpassed target detection. With each sweep of antenna, dual progressive scan transmissions are sent, received and processed to display two separate radar ranges on your NavNet 3D display simultaneously. Each radar presentation acts autonomously, allowing for manipulation of individual gain and clutter controls

• Gearbox incorporates a NMEA 2000&#reg; port to which certain NMEA2000&#reg; sensors can be directly connected. Power for these networked sensors is supplied directly from the gearbox itself, allowing for flexible installation of multiple NMEA 2000&#reg; sensors without the need to run cables all the way to the main processor unit

Transom Mount Transducer w/ Temp, 1kW (10-Pin)

• M258 Transducer with Transom Mount Bracket

• 1 kW

• 50/200 kHz

• 14x23 degree/3x5 degree Beam Angles

• Transom Mount with Temperature

• 10 Meter Cable with 10-Pin Connector

Plastic Thru-Hull, Digital Depth and Temp Sensor (7-Pin)

• 200 Watts

• 235 kHz

• Plastic Thru-Hull

• Depth and Temperature (+/ - 1 degree )

• 10-Meter Cable with 7-Pin Connector

Plastic In-Hull Transducer, 600w (10-Pin)

• 600 Watts

• 50/200 kHz

• 45/15 degree Beam Angles

• Plastic In-Hull Mount for Shoot-Through Applications

• 30 Foot Cable with 10-Pin Connector

Bronze Thru-Hull Transducer w/ Temp, 600w (10-Pin)

• 600 Watts

• 50/200 kHz

• 45/15 degree Beam Angles

• Bronze Thru-Hull with Temperature

• 30 Foot Cable with 10-Pin Connector

Plastic Transom Mount Multisensor, 600w (8-Pin)

• 600 Watts

• 50/200 kHz

• 45/11 degree Beam Angles

• Plastic Transom Mount with Temperature and Removable Speed Assembly

• 30 Foot Cable with 8-Pin Connector

Bronze Thru-Hull Multisensor w/ High-Speed Fairing Block, 600w (8-Pin)

• 600 Watts

• 50/200 kHz

• 40/10 degree Beam Angles

• Bronze Thru-Hull with Speed and Temperature

• 30 Foot Cable with 8-Pin Connector

Bronze Thru-Hull Multisensor w/ High-Speed Fairing Block, 600w (10-Pin)
