Marine Remote Control 6m Extension Cable
MS-WR600EXT6

6m Extension Cable for Fusion’s Marine Remote Control (MS-WR600)

Compatible between the Fusion’s Marine Remote Control (MS-WR600) and the following models of Marine Stereo Unit:

• Marine Stereo for iPod (MS-IP600)

• Marine CD Stereo (MS-CD600)

• Marine DVD Stereo (MS-AV600)

Marine Remote Control Y Connector

Use specifically when using more tha one remote when the remotes are not hooked up in a daisy chain. The WR600Y has a "pig tail" on the back that allows the daisy chaining to occur, while the WR100Y remote does not.

Enables the connection of multiple Marine Remote Control (MS-WR600) to your 600 Series Marine Stereo. This is required to utilize Fusion’s multi-zone technology when installing Wired Remotes in each of your audio zones.

Compatible with the following models of Marine Stereo Unit:

• Marine Stereo for iPod (MS-IP600)

• Marine CD Stereo (MS-CD600)

• Marine DVD Stereo (MS-AV600)

Marine Remote Control 20m Extension Cable
MS-WR600EXT20

20m Extension Cable for Fusion’s Marine Remote Control (MS-600)
Compatible between the Fusion’s Marine Remote Control (MS-WR600) and the following models of Marine Stereo Unit:

Class D, 70W x 2 Zone Amplifier

FUSION’s Marine Zone Amplifier is designed to support the multi-zone technology. The Zone Amplifier is small, enabling discrete installation and when combined with the Marine Stereo Unit provides the platform for a True multi-zone audio system.

Why Do I Need A Zone Amplifier?
A Marine Zone Amplifier is needed if you are planning a multi-zoned system, comprising of three or four zones.

FUSION’s Marine Stereo Units have the capability to run up to four pairs of speakers. You will also need to install a Marine Zone Amplifier if your sound system has more than four pairs of speakers.

Features:

• 2 Channel

• Class D

• 70W x 2

• 2 Ohm Stable

• Water resistant design

• Conformal coated PCB

• Audio detect selectable function the amplifier turns on when audio is detected and goes to sleep / low power mode when audio is not present

• Selectable high pass/ full range setting

• Variable high pass filter

• Small and discrete size: 128 x 78 x 51mm

• High Pass Crossover: 60Hz-600Hz

• Operating Range: 10-16V DC

• Max Power Rating (Watts): D-Class 70W

• Ratings per channel: 20W RMS @ 4 ohms per channel: 33WRMS @ 2 ohms per channel

500W, 4 Channel Amplifier

Add more power to your marine speakers by connecting a FUSION Marine Amplifier to your audio system, or install with a subwoofer to increase the bass level of your music.

Generally, a 4 Channel Marine Amplifier can be used to power two pairs of Marine Speakers and a Marine Subwoofer.

Marine Amplifiers feature anti-corrosion treated PCB’s and stainless steel end panels to maximize corrosion protection.

Specifications:

• Dimensions: 220mm(W) x 330mm(H) x 57.5mm(D)

• 500W

• 4 Channel

• 65W RMS per channel @ 4 Ohms

• 95W RMS per channel @ 2 Ohms

• 200W RMS Bridged channel x 2 @ 4 Ohms and = 1%THD+N

• High Pass Crossover: 40Hz - 600 Hz @ 12dB/octave

400W, 2 Channel Amplifier

Add more power to your marine speakers by connecting a FUSION Marine Amplifier to your audio system, or install with a subwoofer to increase the bass level of your music.

Marine Amplifiers feature anti-corrosion treated PCB’s and stainless steel end panels to maximize corrosion protection.

Generally, a 2 Channel Marine Amplifier is used to power a Marine Subwoofer, increasing the level of your audio system

Specifications

• Dimensions: 220mm(W) x 260mm(H) x 57.5mm (D)

• 400W

• 2 Channel

• High Pass Crossover: 40Hz - 600 Hz @ 12dB/octave

• 65W RMS per channel @ 4 Ohms and = 1%THD+N

• 100W RMS per channel @ 2 Ohms and = 1%THD+N

• 200W RMS Bridged channel @ 4 Ohms and = 1%THD+N

Digital Marine Amplifier
Part #: MS-DA51600

The Most Efficient & Best Looking Amp To Power Audio On Your Vessel

Digital Amplification produces less heat and draws less power; making this the most efficient way to power audio on your vessel. The 1600W 5 Channel Amplifier can power 8 speakers and 1 subwoofer with ease. This Amplifier is designed to impress.

Features:

• D-Class (Digital) Amplifier

• Conformal Coated PCB

• 1 Piece Die Cast Heat Sink

• 5 Way Circuitry Protection

• Discrete Install Panel

• FUSION Low Frequency Control

• Stainless Steel Cover

Marine DVD Stereo MS-AV600

Delivering a new modern styling and enhanced remote bus technology, the 600 series is an evolution on the award winning features found in the 500 series.

Incorporating an intelligent user memory, FUSION’s latest Alpha Search Technology and extended Apple iPod support with fully integrated iPod user interface, dual mono subwoofer output and ingenious behind dash engineering all contained in a 100% aluminum chassis.

The 600 series is the next step in the evolution of marine entertainment technology.

TRUE 360° WATERPROOF DESIGN
Complies with IPX5 Waterproof standards, which includes full behind dash water protection

INNOVATIVE MULTI-ZONE CONTROL
Fully adjustable volume control in all zones of the vessel. Have loud music in the cockpit & quieter music in the saloon.

USER FRIENDLY
User interface is intuitive and simple to use, while the recessed backlit keypad is large enough to view and operate in the roughest conditions.

SUPERIOR DIE-CAST CONSTRUCTION
Engineered to withstand the harsh marine environment including salt spray, humidity and pounding seas.

SUPERIOR DISPLAY
Large, adjustable backlit LCD allows for accurate display of the iPod and Sirius interface.

TRUE INTEGRATION FOR iPod
Complete iPod integration and control is provided through a replication of the iPod menu on the stereo display allowing simple navigation and ease of use through a rotary encoder.

ADVANCED POWER SAVING
High output efficiency and low battery drain through the latest D-Class Amplifier technology.

CREATE THE ULTIMATE MARINE STEREO COMBO
The 600 Series Marine DVD Stereo and External iPod Dock (MS-IPDOCK) can be combined to provide the ultimate system flexibility and seamlessly blend into your instrument panel. This product combo enables you to utilize FUSION’s unique internal dock for iPod technology, which keeps your iPod waterproof, secure and protected from the harsh marine environment.

Features:

• Complies with IPX5 Waterproof Standard

• Direct access source control

• Electronic Skip Protection

• Fully integrated iPod user interface

• Electronic bass / treble / balance control

• 3 zone configurable

• Zone subwoofer level control

• Variable back light illumination

• Rotary encoder volume control

• 12/24 hour Clock

MS-ACSSR6 SIRIUS® ACC1 Receiver

The SIRIUSConnect Tuner is a compact component that can easily integrate with any SAT radio ready headunit and SIRIUS® Plug-and-Play receivers when paired with the correct harness.

Features:

• Compact size allows for hidden installation

• Interface cable integrates power, audio and control through a single connection

• Compatible with the next generation of SIRIUSConnect interface translators

• Does not include satellite antenna

MS-ACSRA-25 SIRIUS® SCC1 Receiver With SRA-25 Antenna

SIRIUS® Receiver

The SIRIUSConnect Tuner is a compact component that can easily integrate with any SAT radio ready headunit and Sirius Plug-and-Play receivers when paired with the correct harness.

Features:

• Compact size allows for hidden installation

• Interface cable integrates power, audio and control through a single connection

• Compatible with the next generation of Sirius Connect interface translators

• Antenna included

• Tiny! When installed only ¾"H x 2-⅜"W x 2"L

• No seperate power cable required

• Single-cable design for newer receivers

• Style SRS-1 adapter available for older, dual-input Sirius receivers

• Optional cable kits available for longer cable runs up to 90 feet

• Shakespeare limited warranty: 1 year

• 15’ low-loss cable

• Includes SM-32 Surface Mounting Kit

• Recevier and service subscription required, available separately.

• Best applications include: Boats or RVs

4" Marine 2-Way Speakers MS-FR402

FUSION’s Marine Speakers are designed and engineered from the ground up to incorporate state of the art audio innovation never seen before in marine speakers.

• Comply with ASTM Standards for UV Stability and Salt/Fog Resistance

• Comply with IP65 Waterproof and Dust Standards

6" Marine 2-Way Speakers MS-FR602

FUSION’s Marine Speakers are designed and engineered from the ground up to incorporate state of the art audio innovation never seen before in marine speakers. The 6" Marine Speakers come complete with three grille options (cloth, standard and sport) as well as three gel badge options.

• Comply with ASTM Standards for UV Stability and Salt/Fog Resistance

• Comply with IP65 Waterproof and Dust Standards

• Sold complete with three grille options in each box

7" Marine 2-Way Speakers MS-FR702

FUSION’s Marine Speakers are designed and engineered from the ground up to incorporate state of the art audio innovation never seen before in marine speakers. The 7" Marine Speakers come complete with three grille options (cloth, standard and sport) as well as three gel badge options.

• Complies with ASTM Standards for UV Stability and Salt/Fog Resistance

• Complies with IP65 Waterproof and Dust Standards

• Sold complete with three grille options in each box

Marine/Outdoor 2-Way Box Speakers MS-BX402
Great for on your boat or outside your home!

FUSION’s Marine/Outdoor Box Speakers are carefully designed and manufactured specifically for marine/outdoor use.

Featuring a unique high tech bass/mid cone, a fluid cooled titanium dome tweeter, and are constructed to be water resistant and engineered to minimize magnetic interference.

Specifications:

• Fully sealed marine box speaker (IPx5 compliant)

• Durable UV resistant plastic enclosure

• High efficiency design to reduce power drain

• Designed and tested to withstand rain, sea salt,fog and extreme temperatures

• Mounting versatility - multi fix bracket ideal for small boats where flush panel mounting is not an option

• Corrosion resistant mounting with stainless steel fixings

• Unit size: 180mm x 180mm x 140mm

• Suitable for use in both marine environment and outdoor entertainment areas

• Efficiency: 87dB

• Impedance: 4 ohms

• Max Power (Watts): 120W

• Tweeter Type: Titanium dome

• Frequency Response: 90Hz-22kHz

• Mounting Depth: 142mm

Fusion Marine 10" Subwoofer MS-SW10
Increase the bass level of your music, or improve all-around sound quality by incorporating a marine subwoofer into your audio system.
Installing a Fusion FM-402 amplifier is recommended to drive the 10" Subwoofer.

Specifications:

• Efficiency: 88dB

• Frequency Response: 30Hz-2kHz

• Magnet Structure: 60 Oz

• Power Handling: 400W (Max)

• Free Space Resonance
• Impedance: 4 Ohms

• Mounting Depth: 115mm

• Voice Coil: 2" Til

MS-FR6520
Featuring a unique poly carbon cone and removable grill for colour coding with water resistant construction.Thoroughly tested to ensure consistent and reliable performance.

Designed for optimal sound reproduction across the full audible spectrum - the human ear is most sensitive to amplitude, pitch, clarity and linearity in the 375Hz to 3kHz bandwidth.

• High Quality Poly Carbon Cone

• Water Resistant Construction 2-Way Design

• 25 Oz Magnet / 50 Oz Magnet Structure

• 1" High Temperature Aluminium Voice Coil

• 1" Mylar Dome Tweeter

• Max Power: 200W

• Frequency Response: 80-20,000 Hz

• Sensitivity: 90dB (1W/1M)

• Impedance: 4 Ohm

Marine Wired Remote Control
MS-WR600

FUSION’s MS-WR600 Marine Wired Remote Control extends the capabilities of a 600 Series Stereo by enabling local control of the audio in each zone of your vessel. Up to three remotes can be linked to the Stereo, providing true system flexibility.

Featuring a rotary encoder and large rubber buttons, the Wired Remote Control is very easy to navigate and control, even on a moving boat.

• Complies with IPX5 Waterproof Standard

• White positive alphanumeric LCD screen

• Plug & play - no external power connection required

• Zone control

• Rotary encoder

• Advanced user interface

• ’Positive feel’ rubber keypad

• Noise resistant CANBUS technology

• Mounting hardware included

• Comes with 6m (19.7ft) cable

iPod/iPhone Marine External Dock

Connect FUSION’s External Marine iPod/iPhone Dock to the Marine CD Stereo Unit (CD500, AV600 & CD600) to provide the additional benefit of an integrated housing for your iPod/iPhone. The dock connects directly to the CD500, AV600 and CD600 allowing full control and integration of your iPod through the CD Stereo Unit. The bulkhead mount dock complies with IP65 Waterproof and Dust Standards on the front of your unit, protecting your iPod/iPhone from the harsh marine environment while it charges.

2 Installation Options:

• Fully sealed bulkhead mount dock for instrument panel or exterior installation

• Wall mount dock for cabin or interior installation

• Marine CD Stereo (MS-CD500)

• Marine CD Stereo (MS-CD600)

• Marine DVD Stereo (MS-AV600)

• iPod 5^th gen (video), 30GB

• iPod 5^th gen (video), 60GB, 80GB

• iPod classic, 80GB, 120GB

• iPod classic, 160GB (2007)

• iPod classic, 160GB (2009)

• iPod touch

• iPod touch, 2^nd gen

• iPod touch, 3^rd gen

• iPod touch, 4^th gen

• iPod nano, 3^rd gen

• iPod nano, 4^th gen

• iPod nano, 5^th gen

• iPhone

• iPhone 3G

• iPhone 3GS

• iPhone 4

Marine Stereo For iPod

Delivering a new modern styling and enhanced remote bus technology, the 600 series is an evolution on the award winning features found in the 500 series.

Incorporating an intelligent user memory, FUSION’s latest Alpha Search Technology and extended Apple iPod support with fully integrated iPod user interface, dual mono subwoofer output and ingenious behind dash engineering all contained in a 100% aluminum chassis.

The 600 series is the next step in the evolution of marine entertainment technology.

Featuring World First internal iPod docking technology. Your iPod actually sits inside the Stereo, completely protected from the harsh marine elements.

TRUE 360° WATERPROOF DESIGN
Complies with IPX5 Waterproof standards, which includes full behind dash water protection

INNOVATIVE MULTI-ZONE CONTROL
Fully adjustable volume control in all zones of the vessel. Have loud music in the cockpit & quieter music in the saloon.

USER FRIENDLY
User interface is intuitive and simple to use, while the recessed backlit keypad is large enough to view and operate in the roughest conditions.

SUPERIOR DIE-CAST CONSTRUCTION
Engineered to withstand the harsh marine environment including salt spray, humidity and pounding seas.

SUPERIOR DISPLAY
Large, adjustable backlit LCD allows for accurate display of the iPod and Sirius interface.

TRUE INTEGRATION FOR iPod
Complete iPod integration and control is provided through a replication of the iPod menu on the stereo display allowing simple navigation and ease of use through a rotary encoder.

ADVANCED POWER SAVING
High output efficiency and low battery drain through the latest D-Class Amplifier technology.

Features:

• Complies with IPX5 Waterproof Standard

• Direct access source control

• Electronic Skip Protection

• Fully integrated iPod user interface

• Electronic bass / treble / balance control

• 3 zone configurable

• Zone subwoofer level control

• Variable back light illumination

• Rotary encoder volume control

• 12/24 hour Clock

• iPod touch Gen 1^st, 2^nd

• iPod classic Gen 5^th, 6^th, 7^th

• iPod nano Gen 2^nd, 3^rd, 4^th

• iPod Touch 3^rd Generation

• iPod Touch 4^th Generation

• iPod nano 5^th Generation

• iPhone 3G

• iPhone 3GS

• iPhone 4

Marine CD Stereo

Delivering a new modern styling and enhanced remote bus technology, the 600 series is an evolution on the award winning features found in the 500 series.

Incorporating an intelligent user memory, FUSION’s latest Alpha Search Technology and extended Apple iPod support with fully integrated iPod user interface, dual mono subwoofer output and ingenious behind dash engineering all contained in a 100% aluminum chassis.

The 600 series is the next step in the evolution of marine entertainment technology.

Specifications:

• Auxiliary in: Yes

• Line Out: 1 x stereo, 1 x subwoofer

• Power: D-Class 70W x 4W (max)

• Display: 2.7" FSTN transflective LCD

• Media: AM/FM Tuner, CD/CD-R / CD-RW, MP3, SIRIUS® Radio Ready (USA only)

• Complies with IPX5 Waterproof Standard

• Direct access source control

• Electronic Skip Protection

• Fully integrated iPod user interface

• Electronic bass/treble/balance control

• 3 zone configurable

• Zone subwoofer level control

• Variable back light illumination

• Rotary encoder volume control

• 12/24 hour clock

50W x 4, 2 Zone Marine Stereo

The MS-RA200 is FUSION Electronics latest offering in marine audio entertainment, packed with features and functions that actually enhance the boating experience. Specifically designed to withstand the harsh marine environment - water, wind, salt and sun. The True Marine accredited MS-RA200 Marine Stereo delivers an assurance of quality, functionality and continued performance season after season, even after extended exposure to the marine environment. The MS-RA200 features FUSION’s industry-leading user interface, iPod and iPhone connectivity and integration, USB compatibility, AM/FM tuner, VHF receiver and SIRIUS® Satellite ready.

With a face plate measuring a minute 6-³⁄₁₆" x 2-¹¹⁄₁₆" (157mm x 68mm), the compact yet feature packed MS-RA200 is the perfect solution for the trailer boat, discreet or space conscious installation.

Incorporating an intelligent user memory, FUSION’s latest Alpha Search Technology and extended Apple iPod support with fully integrated iPod user interface and dual mono subwoofer output all contained in a 100% aluminium chassis.

There are two Marine Docks compatible with the MS-RA200:

Marine Portable Media Device Dock (MS-DKIPUSB) - Featuring the World’s First Internal Dock for iPod technology, iPod video playback on a compatible monitor or television, an internal USB port for portable flash drive playback, and a second USB port on the rear of the dock, enabling the connection of a further USB flash drive*.

Marine Dock for iPod (MS-DKIP) - Offering the same internal docking technology for your iPod / iPhone and security from the marine elements that you find in the full featured MS-DKIPUSB, the MS-DKIP is perfect for those that do not require USB connectivity or iPod video playback.

Features:

• IPx5 Waterproof face

• Super compact unit 6"W x 2.5"H

• Mini SD Card input from front allows user to store MP3 files directly on SD card

• Made for iPod

• Works with iPhone

• Accredited True Marine

• Fully integrated iPod user interface

• USB connectivity - playback from portable flash drives

• Palm size design - ideal for space conscious installations

• High Quality AM/FM Tuner with RDS

• VHF receiver for on-water weather & coastguard update

• SIRIUS® satellite ready

• Dot matrix LCD display featuring variable back lighting

• Powerful 50W x 4 (Max) Amplifier

• IPx5 Waterproof rating on the front of the unit, when correctly bulk head mounted

• Innovative Multi-Zone Technology

• 2 Zone configurable for different levels of volume in different areas of the boat

• Fusion Alpha Search Technology (FAST) allows for quick navigation of your iPod data

• Electronic bass / treble / balance control

• Large rotary encoder and large rubber back lit buttons for simple operation on a moving vessel

• Subwoofer limit control

• Auxiliary input

• Zone line out (1 x stereo, 1 x subwoofer)

AM/FM/Weather Band VHF Receiver w/FSM-6520 2-Way Marine Speakers
Part #: MS-RA200KTS

Features:

• Made for iPod

• Fully integrated iPod user interface

• USB connectivity

• Palm size design

• High Quality AM/FM Tuner with RDS

• VHF receiver for on-water and coast guard update

• SIRIUS® satellite ready

• Dot matrix LCD display featuring variable back lighting

• Powerful 50W x 4 Amplifier

• IPX5 Waterproof rating when flush mounted

• Innovative Multi-Zone Technology

• 2 Zone configurable for different levels of volume in different areas of the boat

• Electronic bass/treble/balance control

• Auxiliary In

• iPod with video, 30GB, 60GB, 80GB

• iPod classic, 80GB, 120GB

• iPod classic, 160GB (2007)

• iPod classic, 160GB (2009)

• iPod touch,

• iPod touch, 2^nd Gen

• iPod nano, 2^nd Gen

• iPod nano, 3^rd Gen

• iPod nano, 4^th Gen

• iPod nano, 5^th Gen

• iPod nano, 6^th Gen

• iPhone, 4GB, 8GB, 16GB

• iPhone 3G, 8GB, 16GB

• iPhone 3GS, 16GB, 32GB

• iPhone 4, 16GB, 32GB

50W x 4, 2 Zone AM/FM/Weather Band VHF Receiver

Your Customers Will Love Fusion’s New Marine Stereo

Features:

• Made for iPod

• Fully integrated iPod user interface

• USB connectivity

• Palm size design

• High Quality AM/FM Tuner with RDS

• VHF receiver for on-water and coast guard update

• Sirius satellite ready
• IPX5 Waterproof rating when flush mounted

• Innovative Multi-Zone Technology

• 2 Zone configurable for different levels of volume in different areas
  of the boat

• Electroni bass/treble/balance control

• Subwoofer level control

• Auxiliary In

Marine Dock for iPod

IMPORTANT: MS-DKIP is only compatible with the MS-RA200 Marine Stereo.

Connect FUSION’s MS-DKIP Marine Dock for iPod to your MS-RA200 Marine Stereo to provide the additional benefit of an integrated housing for your iPod.

The dock connects directly to your MS-RA200 Marine Stereo, allowing full control and integration of your iPod through the Stereo. When bulkhead mounted the dock complies with IPX5 Waterproof Standards on the front of your unit, protecting your iPod from the harsh marine environment while it charges.

There are two installation options for the Marine Dock for iPod:

• Fully sealed bulkhead mount dock for instrument panel or exterior installation

• Wall mount dock for cabin or interior installation

• iPod 5^th gen (video), 30GB

• iPod 5^th gen (video), 60GB, 80GB

• iPod classic, 80GB, 120GB

• iPod classic, 160GB (2007)

• iPod classic, 160GB (2009)

• iPod touch

• iPod touch, 2^nd gen

• iPod touch, 3^rd gen

• iPod touch, 4^th gen

• iPod nano, 3^rd gen

• iPod nano, 4^th gen

• iPod nano, 5^th gen

  Includes sleeves compatible with the following iPhone models:

• iPhone

• iPhone 3G

• iPhone 3GS

• iPhone 4

Replacement Grille Set
Part #: MS-FR602G

Each pair of MS-FR602 speakers include a choice of three different grilles and three different gel badges.

Replacement Grille Set Includes:

• Standard Grilles - The standard grilles are factory-fitted to the speakers, and are the most rugged and offer the highest level of protection. FUSION recommends using the standard grilles in high traffic areas, or where objects are liable to be moving around or knocking into the speakers.

• Cloth Grilles - The cloth grilles are designed to enhance the internal cabin area. The cloth insert is removable, via the screws on the inside of the grille - allowing you to change the cloth to compliment the cabins decor.

• Sport Grilles - The sport grilles provide a third grille alternative for your speakers.

Replacement Grille Set
Part #: MS-FR702G

Each pair of MS-FR702 speakers include a choice of three different grilles and three different gel badges.

Replacement Grille Set Includes:

• Standard Grilles - The standard grilles are factory-fitted to the speakers, and are the most rugged and offer the highest level of protection. FUSION recommends using the standard grilles in high traffic areas, or where objects are liable to be moving around or knocking into the speakers.

• Cloth Grilles - The cloth grilles are designed to enhance the internal cabin area. The cloth insert is removable, via the screws on the inside of the grille - allowing you to change the cloth to compliment the cabins decor.

• Sport Grilles - The sport grilles provide a third grille alternative for your speakers.

iPod/iPhone Internal Dock Sleeves
Part #: AC-SL10

The Internal Dock Sleeves for iPod is a kit of all the current internal dock sleeves, for FUSION iPod inside products. This kit may be required if your FUSION iPod inside product was manufactured before the release of the latest iPod models.

The Kit contains sleeves for the following Marine Products:

• Marine Stereo for iPod (MS-IP500)

• Marine Stereo for iPod (MS-IP600)

• Marine Dock for iPod (MS-IPDOCK)

• Marine Dock for iPod (MS-IPDOCKG2)

Marine DVD/CD/AM/FM/Sirius/VHF & WX/iPhone/iPod/Aux/USB Stereo
MS-AV700

Features:

• 70W x 4 Output with inbuilt Class-D amplifier

• Daylight viewable 2.7" QVGA colour TFT LCD screen 320 x 240

• Rugged aluminium die cast chassis

• Powerful ARM 9 350 MHz processor

• IP-x5 water resistance standard front and rear,

• Ethernet Connectivity

• NMEA 2000 Connectivity

• FUSION-link capable

• 4 Zone Support - Zones are nameable

• Zones 2 - 4 can be disabled, each zone has a sub out, balance control and volume limit control

• DVD/CD(AV700 only)iPod/iPhone/AM/FM/VHF and WX/AUX/USB/Sirius

• Partner (AV700) with iPod dock (MS-IPDK or MS-IPDKUSB)

• VHF Receiver with squelch control - listen to VHF channels like Weather

• Customizable AUX screen - select from an image of a TV/DVD/Game or Portable media device

• Tone control operated by holding the encoder down - bass & treble

• Complete Control of the iPod Music Library - Fully integrated iPod user interface.

• iPod/iPhone track art displayed in colour

• Amazingly Simple Controls - Most operations are controlled by the rotary encoder.

• ID3 Tag (Title /Album/Artist) - displays embedded information from music files

• Customizable Splash Screen image - OEM customers only

• Multi language user interface - English, French, Italian, German, Spanish and Dutch

• Key and LCD adjustable Backlighting.

• 12 or 24 hour clock with alarm function

100W Cube In Slaon Speakers
MS-BX3020

Features:

• 3" paper cone impregnated with water resistant fibres

• Designed for internal use in saloons or cabins, for a full home theatre experience, connect cube speakers to the MS-AS84 active subwoofer for amplified sound.

• ABS + UV speaker enclosures to withstand the marine environment.

• Feature a Dual Pivot Design enabling a mixture of direct and reflected cabin filling sound.

• Includes rotating Mounting Brackets for easy installation into cabin locations from various different angles.

210W In Salon Active Enclosed Subwoofer
Part #: MS-AR1060

Features:

• Active Marine Subwoofer

• Super Slim Design for mounting in more locations

• In-built Class-D 4 Channel Amplifier

• Connect the Active subwoofer to the MS-BX3020 Cube speakers for an amplified home theatre experience

• 8" Subwoofer

• Durable UV resistant plastic enclosure so the finish won’t fade in the sun

• Designed to withstand the harsh marine environment and comply with international ASTM Standards for UV Stability (ASTM-D4329) and Salt/Fog Resistance (ASTM-B117)

• Remote Bass Level Control

• Linkable unit allowing for a bass surround experience

• Vertical and horizontal mounting options (Easy installation)

Full Function 700 Series Wired Remote
MS-NRX200

Features:

• Compatible with the MS-IP700/AV700

• NMEA 2000 Connectivity

• IP-X7 water resistant

• FUSION-Link capable

• Large 2.6" Monochrome FSTN LCD

• 128 x 64 pixels

• Screen is high contrast, viewable in direct sunlight

• Key and LCD adjustable Backlighting.

• STM32 Micro Processor

• Control multiple 700 Series stereo units connected to the N2K network

• NMEA 2000 Repeater - will display basic information from units connected to the N2K network

• Compact size for ease of installation on dashes

• FUSION Alpha Search Technology

Marine AM/FM/Sirius/VHF & WX/iPhone/iPod/Aux/USB Stereo
Part #: MS-IP700

The 700 Series True Marine Entertainment System is the culmination of FUSION’s engineering and design brilliance, resulting in a product with superior sound quality, controls and features never seen before. The MS-IP700 represents the perfect mix of innovation, functionality and ease of use, driven by feedback from the marketplace direct to your vessel. Nominated for a DAME design award for marine innovation, the 700 Series is not just a step ahead - it’s light years ahead.

Features:

• 70W x 4 Output with inbuilt Class-D amplifier

• Daylight viewable 2.7" QVGA colour TFT LCD screen 320 x 240

• Rugged aluminium die cast chassis

• Powerful ARM 9 350 MHz processor

• IP-x5 water resistance standard front and rear

• Ethernet Connectivity

• NMEA 2000 Connectivity

• FUSION-link capable

• 4 Zone Support - Zones are nameable

• Zones 2 - 4 can be disabled, each zone has a sub out, balance control and volume limit control

• iPod/iPhone/AM/FM/VHF and WX/AUX/USB/Sirius

• Internal USB jack for flash drive to play MP3 files (MS-IP700 only)

• Internal iPod/iPhone dock (IP700 only)

• VHF Receiver with squelch control - listen to VHF channels like Weather

• Customizable AUX screen - select from an image of a TV/DVD/Game or Portable media device

• Tone control operated by holding the encoder down - bass & treble

• Complete Control of the iPod Music Library - Fully integrated iPod user interface

• iPod/iPhone track art displayed in colour

• Amazingly Simple Controls - Most operations are controlled by the rotary encoder

• ID3 Tag (Title /Album/Artist) - displays embedded information from music files

• Customizable Splash Screen image - OEM customers only

• Multi language user interface - English, French, Italian, German, Spanish and Dutch

• Key and LCD adjustable Backlighting

• 12 or 24 hour clock with alarm function

Marine AM/FM/iPod/iPhone Ready
MS-RA50

Features:

• Super-Compact - more installation Options

• Rugged aluminium die cast chassis

• New "shallow" case back design

• AM/FM (with RDS)

• Made for iPod

• Complete Control of the iPod Music Library - Fully integrated iPod user interface.

• Amazingly Simple Controls - Most operations are controlled by the rotary encoder.

• ID3 Tag (Title /Album/Artist) - displays embedded information from music files

• Partner with iPod dock (MS-IPDOCKG2)

• Aux Input

• Single Zone, 2 Channel x 45W

• 1 x Subwoofer output

• Daylight viewable 2.3" 128 x 64 LCD

• Powerful 32-bit ARM based processor

• IP-x5 water resistance standard front and rear,

• Colour, Black with white trim

• Multi language user interface - English, French, Italian, German, Spanish and Dutch

• Key and LCD adjustable Backlighting.
